WiebeTech RTX100-Q User Manual

WiebeTech RTX100-Q User Manual

Wiebetech rtx100-q storage enclosures: user guide

Advertisement

Features

TrayFree™ technology! RTX-100-Q doesn't force you to install your hard drives into trays. Simply
slide in a SATA drive and shut the door.
Bay is lockable for added security.
RTX100H-Q is all-metal. The all-metal constructed enclosure also comes with 2 LEDs for power
and access.
Built-in shock absorption helps protect your hard drives. The specially-designed SATA drive
interface is built to withstand thousands of drive insertions.
Quadruple connectivity! RTX100-Q is compatible with four different interfaces: eSATA, FireWire
800, FireWire 400 (via included converter cable) and USB.
Sturdy aluminum case provides excellent heat dissipation and rugged durability.

Before Installation

1.
Check the accessories with your RTX100-Q. Please contact WiebeTech if any parts are missing
or damaged. The box should contain the following items:
R T X 1 0 0 - Q U s e r ' s M a n u a l
RTX100-Q™
USER'S MANUAL
Revised January 24, 2008
FireWire cables
USB cable
eSATA cable
Accessories
RTX100-Q unit
eSATA cable
FireWire 800 to 800 cable
FireWire 800 to 400 cable
USB cable
AC Power Cord
Key
Manual and Warranty Information
Quantity
1
1
1
1
1
1
1
(on CD)
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RTX100-Q and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for WiebeTech RTX100-Q

  • Page 1: Before Installation

    • Before Installation Check the accessories with your RTX100-Q. Please contact WiebeTech if any parts are missing or damaged. The box should contain the following items: R T X 1 0 0 - Q U s e r ’ s M a n u a l...
  • Page 2: Rear Panel

    Your RTX100-Q is now ready to use! Turn on the power switch on the back of the unit. If your drive is already formatted, you can begin using it right away. New hard drives will need to be formatted before they can be used.
  • Page 3: Usage With Macintosh Computers

    Option key during startup. A screen should appear that allows you to select the volume you wish to use. This is useful if you wish to boot from your RTX100-Q only some of the time. Usage with Windows Computers Compatibility The RTX100-Q is compatible with Windows XP and Vista.
  • Page 4: Technical Specifications

    Dimensions: Warranty: RTX100-Q & TrayFree are trademarks of WiebeTech LLC. Other marks are the property of their respective owners. © 2008 WiebeTech LLC. All rights reserved. FCC Compliance Statement: “This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.”...

This manual is also suitable for:

Rtx100h-q
