SATATYA Dome IP-Camera
The Persistent Vision
Safety Instructions
Cautions
Avoid placing cables too close to magnetic or high voltage devices,
Ÿ
to reduce undesirable image noise.
Do not mount the camera with the lens facing the sun or bright light
Ÿ
to prevent damage to the sensor.
Do not expose the camera to temperatures below or beyond its
Ÿ
operating temperature.
Do not mount the camera near a radiator or a heater.
Ÿ
WARNING
In the use of the product, you must be in strict compliance with
Ÿ
the electrical safety regulations of the region and nation.
Do not connect several devices to one power adapter as it may
Ÿ
cause over-heating or fire hazard.
Turn off power supply before making electrical connections.
Ÿ
LED
CLASS1 (Category Rs1)
Never look at the transmit laser while the power is on. Never look
Ÿ
directly at the fiber ports and the fiber cable ends when they are
powered on.
Use of controls or adjustment to the performance or procedure
Ÿ
other than those specified herein may result in hazardous laser
emission.
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SATATYA and is the answer not in the manual?

Questions and answers

Summary of Contents for Matrix SATATYA

  • Page 1 SATATYA Dome IP-Camera Safety Instructions The Persistent Vision Cautions Avoid placing cables too close to magnetic or high voltage devices, Ÿ to reduce undesirable image noise. Do not mount the camera with the lens facing the sun or bright light Ÿ...
  • Page 2: Table Of Contents

    Please read this guide first for correct installation and retain it for future reference. The information in this guide may change from time to time. However, Matrix Comsec reserves the right to make changes in product design and specifications without prior notice.
  • Page 3: What Your Package Contains

    3MP Camera Variants Camera Variants Type of Lens Focal Length Standard Premium The SATATYA Dome Camera is available in Standard and Fixed 2.8mm MIDR30FL28CWS MIDR30FL28CWP Premium variants which are available in 2MP as well as 3MP . The variants are listed in the table.
  • Page 4: Installation

    Installation Step 3: Installing Mounting Template Before you start: Stick the Mounting template at the exact location of camera Ÿ Please make sure: installation. The location can be ceiling or wall. Ÿ The device in the package is in good condition and all the Drill three holes through the markings provided on the Mounting Ÿ...
  • Page 5 Step 4: Taking off the cable Step 5: Mounting the Camera For External Cabling: Take off the enclosure top by removing 3 screws using screw driver. Ÿ Take the cable out through the cable guide, sideways to the Ÿ See Figure4. camera.
  • Page 6 Step 6: Adjusting Camera Angle Loosen the screws on both sides of lens to adjust the camera angle. See Figure6. A. PAN Movement For PAN movement you can move the camera to 45 degrees each side. see Figure7. To capture other side view, turn the body and mount to other side.
  • Page 7 -5° 70.0° Figure:9 Figure:8 Step 7: Place the Gasket and Top Cover After installing the camera at the desired location and position, Ÿ place the Gasket at the enclosure bottom. Finally align the enclosure top and fix it with the 3 screws. See Ÿ...
  • Page 8: Accessing Reset Switch And Sd Card Slot

    Accessing Reset Switch & SD Card Slot IP66 Protection Accessory Installation 1. By default your camera contains the LAN connector fitted by IP66 If you forget the IP address or login credentials of camera then the protection accessory. camera can be reset to factory default settings using the reset switch. The Reset switch is located as shown in Figure12.
  • Page 9 6. Insert male RJ45 connector into female connector part. Then tighten the middle part by rotating in clockwise direction. IP66 accessory LAN Connector Do not remove the “O” ring from its place. 4. Loosen the tail end of the IP66 accessory by rotating it in anticlockwise direction.
  • Page 10: Powering The Camera

    Powering the Camera Network Configuration To view and configure the camera via LAN (Local Area Network), you need • Connect the Ethernet cable to LAN port and Power cable to the to connect the network camera in the same subnet with your PC. Then 12V DC power supply.
  • Page 11: Accessing Via Web Browser

    Accessing via Web Browser The IP cameras are supported by Microsoft Windows Operating System. IMPORTANT In Internet Explorer you can access the camera with Matrix ActiveX plugin. In other browsers you need to install Quicktime or VLC plugin. Steps: Run the web browser as administrator, enter IP address of the Ÿ...
  • Page 12: Technical Specification

    Technical Specification Specification Standard Specification Standard Premium Premium Hardware Storage Power Supply 12V @2A 12V @2A SD Card Reset Switch Software Power Cosumption Max. 6W Max. 6W Motion Detection, Motion Detection, View Tamper, Ethernet View Tamper, IVA Events Trip Wire, Trip Wire, Audio IN Zone Intrusion,...
  • Page 13 At the end of product life cycle; batteries, soldered boards, metal components and plastic components must be disposed through recyclers. If you are unable to dispose-off the products or unable to locate e-waste recyclers, you may return the products to Matrix Return Material Authorization (RMA) department.
