- Page 1 THE WHISTLER GROUP, INC. CORPORATE HEADQUARTERS 13016 N. Walton Blvd. Bentonville, AR 72712 TEL (479) 273-6012 FX (479) 273-2927 www.whistlergroup.com P/N 260021, ©The Whistler Group, Inc 2006 Installation Instructions Laser/Radar Detector www.whistlergroup.com...
-
Page 2: Table Of Contents
• Interconnecting Cable: 20’ • Control Panel Cables: 3’ Specifications are subject to change without notice. TABLE OF CONTENTS Topic Tools Required Whistler Components Mounting Brackets Mounting Fasteners Installation of Radar Antenna Installation of Temperature Probe Installation of Laser Antenna... -
Page 3: Mounting Brackets
MOUNTING BRACKETS WHISTLER FUZION COMPONENTS INTRODUCTION... -
Page 4: Mounting Fasteners
MOUNTING FASTENERS Bolt #10-32 x 1-1/4" Lock Washer Sheet metal Screw #6 x 3/4" Hook and Loop Fastener 4" Cable Tie Bolt #10-32 x 1/2" Flat Washer Sheet metal Screw #4 x 5/8" Mountable Cable Tie Interface Cable Lock Washer MOUNTING FASTENERS Reference Description/Use... -
Page 5: Installation Of Radar Antenna
INSTALLATION OF RADAR ANTENNA General Information The radar antenna is waterproof and designed to be mounted at the front of your vehicle. In most vehicles the best mounting location is directly below or behind the bumper. Radar signals will pass through non-metallic materials such as fiberglass and plastic, however, be sure to mount the receiver away from any metal, as it will block the receiver’s antenna. - Page 6 INSTALLATION OF RADAR ANTENNA The Small L Brackets are fastened to the Large L Bracket using the #10-32 x 1/2" bolts, #10-32 nuts and lock washers. To fasten the Large L or Small L Brackets to your vehicle, mark the supporting structure through the appropriate holes in the brackets, then drill the holes in the supporting structure with a 13/64"...
-
Page 7: Installation Of Laser Antenna
INSTALLATION OF RADAR ANTENNA Mount the antenna to the vehicle such that the ANTENNA window is facing the road surface, sky, right or left of the vehicle, and the reflector has an unobstructed view of the road ahead. Mounted in this position, radar signals are reflected into the ANTENNA window. -
Page 8: Installation Of Control Panel
Laser antenna mounted to rearview mirror with Hook & Loop Fasteners. INST ALLA TION OF CONTROLPANEL The Fuzion remote is designed to fit into standard 2 1/16” gauge housings. This unit is perfect to complement other gauges in a pillar pod or install in its own gauge housing. - Page 9 INST ALLA TION OF CONTROL PANEL PWR - 12 Volt Connection AUX - LED, Tone Voice Module Output LAS - Laser Module Input ANT - Radar Receiver Input 3. Laser Port 2. Auxiliary Port 1. Power Port INST ALLA TION OF CONTROL PANEL Antenna Cable Connection The stereo connector on the end of the antenna cable plugs into ANT.
-
Page 10: Installation Of Voice Module
• Look for cuts in the cable If difficulties occur which cannot be solved by information in this Troubleshooting Guide, please call Whistler Customer Service at 1-800-531-0004 or visit our FAQ page at www.whistlergroup.com, before returning your unit for service.
