Jabra Pro 9450 Mono
How do I connect my Jabra wireless headset with the Jabra
Link 14201-30 to my desk phone so I have remote call control
using my headset?

Connection:

1. Connect the AC adapter that is supplied with the headset to the
headset base. Connect the other end to an electrical outlet.
2. Connect the Jabra Link 14201-30 EHS cable with the red band to the
AUX interface on the headset base. Connect the end with the blue
band to the headset base socket that is marked with a phone icon.
3. Connect the single end of the Jabra Link 14201-30 EHS cable to the
USB interface on the desk phone.

Configuration:

1. Ensure the USB headset function on the desk phone is enabled. Refer
to your phone or IT support for assistance.
2. Follow the setup instructions for your Jabra wireless headset. If the
headset base requires manual configuration, set the Electronic Hook
Switch setting to "DHSG" and set the dial tone switch to position
"A".
3. Make a call to the headset. If the volume of your voice is too loud or
quiet to the person you are calling, adjust the headset microphone
volume until you achieve the optimum level.
