Fort ECSPHB Quick Start Manual

General

Our products are designed to comply with the
recommended codes and practice, and is to be installed and
serviced by competent persons in accordance with the
relevant regulations.
Contents
The Smart hub is supplied separately and as part of
a kit, please check the packaging to ensure all
required accessories are included.
The Smart hub is supplied with a power adapter,
the accessories with the required batteries and
screw pack.

Installation

For best performance the final installation site of
the hub will be at the central point of the system.
Connect the supplied power adapter to the hub and
apply power, the hub will operate after 60secs.
Connection button
Power adapter input
Power switch
HUB LED Indications
Red Flashing/Fixed: System Armed
Blue Flashing/fixed: System armed in home mode
Green Flashing/fixed: System disarmed
Red/Blue/Green fixed: Connected to the server
Red/Blue/Green Blink Slowly: Wi-Fi network disconnected
Green Blink Fast: Wi-Fi network settings EZ mode
Blue Blink Fast: Wi-Fi network settings AP mode
White fixed: RF connection mode
Smart Security Hub
ECSPHB
USB Interface
SIM card slot
(Full size)
Elite Security Products
Redditch B98 8YN

Preparation For Use

Ensure that the smart phone is connected to the same Wi-
Fi network that you would like to attach the device.
Ensure that you have a mobile device running iOS 8 or higher
or Android 4.1x or higher and a 2.4GHzWi-Fi connection.
Download the ClickSmart+ App on
your mobile device from the App Store
or Google Play.
Sign in or Register following the
instructions on the ClickSmart+ App.

Adding Accessories

If the hub has been supplied as part of a kit the accessories
will be pre-paired for convience. For additional accessories;
PIR
1. Select your ESP Hub in the ClickSmart+ app, click on
"Accessories" along the bottom, then click on "Detectors"
at the top, then click on "+ Add", finally press the test
button on the back of the PIR.
2. The control panel will beep once to acknowledge the
connection, or twice if this PIR has already been paired.
Door/Window Contact
1. Select your ESP Hub in the ClickSmart+ app, click on
"Accessories" along the bottom, then click on "Detectors" at
the top, then click on "+ Add", finally seperate the magnet
from the transmitter.
2. The control panel will beep once to acknowledge the
connection, or twice if this Door Contact has already
been paired.
Remote Control
1. Press once on the "Connection Button" on the your ESP Hub
2. Press "Arm" on the Remote control
3. The control panel will beep once to acknowledge the connec-
tion, or twice if this Remote Control has already been paired.
Siren
1. Press the "Connection Button" on your siren for one second.
The LEDs should illuminate, the siren is now in connection
mode for 20 seconds.
2. Press "ARM" or SOS" on your control panel (not VIA a remote
control). you should hear one beep; the siren is now connected.
Products bearing this mark
are compatible with the Clicksmart+ APP
