Installation Instructions
30" Drop-In
Electric Range
IMPORTANT:
Read and save these instructions.
Part No. 3191799 Rev. A
Quick Reference
Table of Contents:
Pages
1
Product dimensions
1
Cabinet opening dimensions
1
Before you start
2
Electrical requirements
2
3
Installation steps
If you need assistance:
Check your Use and Care Guide for a toll-free number to call or call
the dealer from whom you purchased this appliance. The dealer is
listed in the Yellow Pages of your phone directory under
"Appliances — Household — Major — Service and Repair."
Call when you:
Have questions about range installation or operation.
Need to obtain the name and number of an authorized service
company.
When you call, you will need:
The range model number:
The range serial number:
Both numbers are listed on the model/serial rating plate, located on
the oven door or on the oven frame.
IMPORTANT:
Installer: Leave Installation Instructions with the homeowner.
Homeowner: Keep Installation Instructions for future reference.
Save Installation Instructions for local electrical inspector's use.
