Predator 70143 Quick Start Manual

STOP
Check total Start-up watts amount
before plugging in any equipment.
WATTAGE ESTIMATE TABLE
Running
Equipment
Total Running Watts
(must be less than 3900 Gasoline • 3600 LPG)
Largest Additional Start-up Watts
Total Startup Watts needed for all loads
(must be less than 5000)
Check total Start-up watts amount before plugging in any equipment.
1. Add up the Running Watts for all items you would like to use at any given time.
2. Make sure that this total is under the 3600 (LPG) or 3900 (gasoline) rated wattage of the generator.
3. Find the single highest starting watts for the selected items and add to the total.
4. Make sure that this total is under the 5000 maximum rated wattage of the generator.
5. Plug in and turn on products from largest wattage to smallest.
WATTAGE ESTIMATE CHART
EMERGENCY
ADDITIONAL
RUNNING
DEVICE
START-UP
WATTS
Watts WATTS
Refrigerator / Freezer 700 1500
Radio 100 0
HOUSEHOLD
ADDITIONAL
RUNNING
DEVICE START-UP
WATTS
WATTS
Computer w/ Monitor 800 0
Electric Clothes Dryer 5500 500
Electric Range 2100 0
Electric Water Heater 2000 0
Light Bulb - 100 Watts 100 0
Microwave - 1000 Watts 1000 200
Sump Pump - 1/2 HP 1000 1100
Television - 27" 400 0
Washing Machine 1100 1100
Well Pump - 1/2 HP 1000 1000
IF ANY CIRCUIT BREAKERS TRIP:
1. Make sure that ALL circuit breakers are reset
before starting the generator again.
2. Adjust the plugs so the loads are
shared across outlet circuits.
To check the wattage amount:
Typical Product Watts
Check your appliance for actual ratings.
JOB SITE RECREATION
ADDITIONAL
RUNNING RUNNING
DEVICE DEVICE
START-UP
WATTS WATTS
WATTS
Air Compressor - 1/2 HP 1000 1000 AM/FM Radio 100
Table Saw - 10" 1700 1300 Electric Grill 1700
Belt Sander - 3" 1200 1200 Inflator Pump 50
Hand Drill - 1/2" 600 600 CD/DVD Player 100
Halogen Work Light 1000 0 Box Fan - 20" 200
Reciprocating Saw 900 900 Coffee Maker 600
LAWN & GARDEN HEATING & COOLING
ADDITIONAL
RUNNING RUNNING
DEVICE START-UP DEVICE
WATTS WATTS
WATTS
Hedge Trimmer 400 400 Central AC - 10,000 BTU 1500
Pressure Washer Furnace Fan - 1/2 HP
1200 1200 900
Lawn Mower 1200 1200 Space Heater 1800
Edger 1000 1000 Window AC - 10,000 BTU 1200
Note: Wattage listed are estimates for that type of equipment only.
Check nameplate wattages on all loads before connecting to generator.
Evenly distributed
over outlets:
ESC Switch
ADDITIONAL Engine Start Switch
START-UP
WATTS
0
Power Switch
0
100
CO Sensor Light
0
200
AC Circuit Breakers
0
AC Receptacles
Ground Terminal
ADDITIONAL
START-UP
WATTS
DC Circuit Breaker
3000
1400
Overload Reset
0
600
To prevent serious injury:
READ MANUAL BEFORE USE.
10i
70143
Fuel Cap
Fuel Gauge
LPG/Propane Inlet
Fuel Selector Switch
USB Port
Digital Display
Starter Handle
DC Receptacle
Parallel Ports
