w2602 BK lCD tV
QuICK
ConnECt
G U i D e
ConGrAtulAtIons on pur-
chasing a HD-ready LCD TV!
This Quick Connect Guide will
help you get started in 3 easy
steps. On the back you will
find information to maximize
your LCD TV experience. For
complete installation, usage
instructions, and safety pre-
cautions please refer to the
User's Manual.
Westinghouse Digital Electronics
1
ConnECt thE
PowEr
Use the enclosed AC power
cable to connect the AC
power to the power input on
the LCD TV.
KEYPAD
2
ConnECt thE
ConnECt A DVD
tunEr
PlAYEr
Connect either analog cable
Connect a DVD player to
or TV antenna wire to the
the component YPbPr input
cable ready NTSC tuner
(Red, Green, Blue) and the
input labeled "ANT" on the
corresponding component
connection panel.
audio inputs.
Note: this step can be skipped if
you do not use these options.
Refer to the table on the back for
connection to satellite set top box
or digital cable.
s-Video/AV Inputs
VGA/YPbPr/DVI Inputs
Antenna
3
GO!
Press Power on the keypad
to turn on the LCD.
