TABLE OF CONTENTS TABLE OF CONTENTS ... i DIGITAL TELEVISION TRANSITION NOTICE ... 1 AVISO RELATIVO A LA TRANSICIÓN A TELEVISIÓN DIGITAL ... 1 IMPORTANT INFORMATION ... 2 Warnings ... 2 NOTICES ... 3 FCC COMPLIANCE STATEMENT ... 4 IMPORTANT SAFETY INSTRUCTIONS ... 5 Circuit Overload ...
TABLE OF CONTENTS CABLE TV (CTV/DTV) CONNECTION ... 17 EXTERNAL DEVICE CONNECTIONS ... 18 POWER CONNECTION ... 20 CONNECTING AC POWER ... 20 INITIAL SETUP ... 20 BASIC OPERATIONS ... 21 TURNING THE POWER ON AND OFF ... 21 ADJUSTING THE VOLUME ... 21 CHANGING CHANNELS ...
DIGITAL TELEVISION TRANSITION NOTICE DIGITAL TELEVISION TRANSITION NOTICE This device contains a digital television tuner, so it should receive digital over the air TV programming, with a suitable antenna, after the end of full-power analog TV broadcasting in the United States on June 12, 2009. The nationwide switch to digital television broadcasting will be complete on June 12, 2009, but your local television stations may switch sooner.
IMPORTANT INFORMATION IMPORTANT INFORMATION Warnings To reduce the risk of fire or electric shock: • Do not expose this product to rain or moisture. • Do not remove the rear cover. There are no user-serviceable parts inside. Refer all servicing requirements to qualified service personnel. •...
NOTICES Important Notices Concerning Power Cord Selection The specific power cord for this LED TV is enclosed and has been selected according to the country of destination. Use the enclosed power cord to prevent electric shock. Observe the following guidelines if it is necessary to replace the original cord set, or if there is no cord set enclosed.
• If the interference persists even after performing the above measures, consult the Westinghouse Service Center or an experienced radio/TV technician for assistance. FCC Warning To assure continued FCC compliance, use a grounded power supply cord and the provided shielded video interface cable with bonded ferrite cores.
IMPORTANT SAFETY INSTRUCTIONS Make sure to note and follow all warnings and instructions marked on the LED TV. Observe the following safety instructions. • Read these instructions. • Keep these instructions. • Heed all warnings. • Follow all instructions. • Do not use this apparatus near water.
IMPORTANT INFORMATION Circuit Overload Do not overload wall outlets, extension cords, or power strips. This can result in a fire or electronic shock. Power Cord Protection Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them.
Do not place heavy objects on the LED TV, audio/video cables, or power cord. • If the LED TV emits smoke, abnormal noise, or a strange odor, immediately turn it off and contact the Westinghouse Service Center by: – Logging on to www.wde.com. –...
IMPORTANT INFORMATION ANTENNA INSTALLATION SAFETY Outdoor Antenna Grounding If an outside antenna or cable system is connected to the LED TV, be sure the antenna or cable system is grounded to prevent voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANS/NFPA 70, provides information on proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
CLEANING THE LED TV • Make sure the LED TV is turned off and the power cord is disconnected from the power outlet. • Never spray or pour any liquid directly onto the screen or the case. To clean the screen: 1 Wipe the screen with a clean, soft, lint-free cloth.
PACKAGE CONTENTS PACKAGE CONTENTS 26” LED TV Unit LED TV Base Power Cord AC Adapter Screws for Base M4x18 *4pcs M5x16 *1pc Cover neck Base Remote Control (with 2x AAA batteries) C.C. Favorite Enter Input YPbPr1 HDMI1 Video1 YPbPr2 HDMI2 Video2 RMT-11 User Manual...
CONTROL PANEL Item Description 1. MENU Displays the LED TV setup screen. • Adjusts the volume during playback. 2. Volume +/- • Selects an item on a menu screen. • Switches the channel during TV viewing. 3. Channel +/- • Selects an item on a menu screen. •...
TERMINALS TERMINALS Y - L - R DC IN TUNER Item 1. DC in 2. TV tuner 3. Composite AV input 4. Audio in 5. VGA 6. Audio out 7. SPDIF audio out 8. HDMI 1/2 9. USB Service port L - R AUDIO IN Function...
REMOTE CONTROL Item 1. Mute 2. Power 3. Backlight 4. MTS 5. CC Z Z Z C.C. Favorite 6. Sleep z 7. Channel keys 8. Favorite 9. Enter ENT 10. Menu Enter 11. Return 12. Arrow keys 13. Enter Input 14.
REMOTE CONTROL OPERATION REMOTE CONTROL OPERATION INSTALLING THE REMOTE CONTROL BATTERIES CAUTIONS: • Only use AAA batteries. • Do not mix new and old batteries. This may result in cracking or leakage, which may pose a fire risk or lead to personal injury. •...
LED TV BASE CAUTION: The LED TV unit may be too heavy for one person to lift. If this is the case, make sure to ask for assistance in handling the LED TV to prevent physical injury and/or damage to the unit. INSTALLING THE LED TV BASE 1 Open the LED TV carton box.
LED TV BASE REMOVING THE LED TV BASE If you intend to repack the LED TV unit (for shipping or storage) or you want to change the installation to a wall mount option, you must first remove the LED TV base.
ANTENNA CONNECTION OUTDOOR ANTENNA CONNECTION Cable TV lead in VHF, UHF or VHF/UHF combination antenna 75 ohm coaxial cable (round) 300 ohm twin-lead (flat) Separate VHF/UHF Antenna VHF Antenna UHF Antenna 300 ohm twin-lead 300 ohm twin-lead 75 ohm coaxial cable CABLE TV (CTV/DTV) CONNECTION The unit has a TV tuner (75 ohm coaxial cable connector) located on the rear I/O panel for easy cable hookup.
EXTERNAL DEVICE CONNECTIONS • A position on the RF switch (not supplied) – You can view all unscrambled channels by using the TV's channel keys. • B position on the RF switch (not supplied) – You can view the scrambled channels via the converter/descrambler by using the converter's channel keys.
Page 23
The following diagram shows the external device connections. Antenna / Cable system 3.5 mm stereo mini Antenna cable / jack cable Cable TV line Y - L - R DC IN TUNER AC adapter Home video game system Power outlet DVD player EXTERNAL DEVICE CONNECTIONS Audio amplifier...
POWER CONNECTION POWER CONNECTION CONNECTING AC POWER IMPORTANT: The LED TV is designed to be powered via an AC adapter. Use ONLY the AC adapter included in the package. Turn off all connected devices before plugging the AC adapter into the power outlet. Connect the power cord of the AC adapter to the LED TV then to a proper AC outlet.
BASIC OPERATIONS TURNING THE POWER ON AND OFF Turning on the power Press on the control panel or on the remote control to turn on the LED TV. Turning off the power Press on the control panel or on the remote control to turn off the LED TV. The LED behavior will depend on the enabled Power settings.
BASIC OPERATIONS CHANGING CHANNELS Follow the instructions below to change channels. Using the Ch Buttons Browse channels Input To browse through the available channels, press Ch the remote control or on the control panel. YPbPr1 HDMI1 Video1 Using the Channel Keys Selecting channel Favorite To change to a certain channel, key in the channel number using...
Using the Input Key Select source using Input Key Input 1 Press Input. YPbPr1 HDMI1 Video1 2 A list of supported video sources is displayed. 3 Press 4 Press ADJUSTING THE DISPLAY FORMAT The input source can sometimes affect the way images are displayed on-screen. You can adjust the display format to view the image properly.
SETUP MENUS SETUP MENUS SETUP MENU OPERATION Use the setup menus to configure the various operational settings of the LED TV. Displaying the setup menu screen Press on the remote control or MENU on the control panel to display the setup menu screen.
PICTURE Use the Picture sub-menus to configure the display quality. Press on the remote control or MENU on the control panel to display the setup menu screen then select Picture to display the Picture sub-menu. The following options are available: Brightness, Contrast, Saturation, Video Presets, Sharpness, Color temperature, Hue, and Reset.
Page 30
SETUP MENUS Saturation Use Saturation to adjust the color intensity. Adjusting Saturation 1 Use the keys to select Saturation and press 2 Press the keys on the remote control to adjust the saturation level. 3 Press to save and exit the screen. Video Presets Use this sub-menu to select one of four preset view options optimized for different viewing conditions.
Adjusting Video Presets 1 Use the keys to select Video Presets and press 2 Press the keys on the remote control to select the desired option. 3 Press to save and exit the screen. Sharpness Use Sharpness to adjust the sharpness or softness of the display. Adjusting Sharpness 1 Use the keys to select Sharpness and press...
Page 32
SETUP MENUS Adjusting Color Temperature 1 Use the keys to select Color temperature and press 2 Press the keys on the remote control to select the desired option. 3 Press to save and exit the screen. Use Hue to adjust the balance of the red, green, and blue colors in the display. Adjusting Hue 1 Use the keys to select Hue and press...
AUDIO Use the Audio sub-menus to configure the audio quality. These settings apply to the LED TV speakers only. Any connected audio devices are not affected. Press on the remote control or MENU on the control panel to display the setup menu screen then select Audio to display the Audio sub-menu.
Page 34
SETUP MENUS Balance Use Balance to adjust the sound balance between the L/R speakers. Adjusting Balance 1 Use the keys to select Balance and press 2 Press the keys on the remote control to adjust the balance level. 3 Press to save and exit the screen.
Page 35
Audio Preset Use this sub-menu to select one of four preset audio options optimized for different sounding conditions. The following options are available: • Rock: Sets the equalizer to the Rock mode. • Pop: Sets the equalizer to the Pop mode. •...
Page 36
SETUP MENUS Adjusting TruSurround HD 1 Use the keys to select TruSurround HD and press 2 Press the keys on the remote control to select On or OFF. 3 Press to save and exit the screen. Reset Select Yes on this sub-menu to reset all audio-related settings. Reset...
VIEW MODE Use the View Mode sub-menu to select the aspect ratio of the display. Press on the remote control or MENU on the control panel to display the setup menu screen then select View Mode to display the View Mode sub-menu. The following options are available: Standard, Fill, Overscan, and 1:1 Mode.
SETUP MENUS • 1:1 Mode: Matches the incoming resolution exactly to the pixels without any scaling. • Standard: Picture is displayed in its original size. • Fill: Picture is displayed to cover the entire screen. H. Position Use this sub-menu to adjust the horizontal position of the display. V.
TV PROGRAM Use the TV Program sub-menus to manage the channel list, language sound, and to scan for available TV channels in your area. Press on the remote control or MENU on the control panel to display the setup menu screen then select TV Program to display the TV Program sub-menu. The following options are available: Skip List, Channel Edit, MTS, Auto Search, and Manual Add.
SETUP MENUS Channel Edit Use Channel Edit to assign a name to a channel. Channel Name Edit Editing Channel Names 1 Use the keys to select Channel Edit and press Name Edit screen appears. 2 Use the keys to select the desired channel and press the Edit Name screen.
Use MTS to select multichannel television sound. The following options are available: • Mono: Allows mono output (useful when stereo is noisy or inconsistent). • Stereo: Allows stereo sound for superior TV viewing experience. • SAP: Allows second audio program from the speakers while watching a scene in the original program.
SETUP MENUS Manual Add Use Manual Add to add channels manually. Channel Add Adding Channels Manually 1 Use the keys to select Manual Search and press Add screen appears. 2 Use the Channel keys on the remote control to enter the channel number and select Enter.
SETTINGS Use the Settings sub-menus to configure the LED TV operational setup and view the current firmware version. Press on the remote control or MENU on the control panel to display the setup menu screen then select Settings to display the Settings sub-menu. The following options are available: Date and Time, Closed Captions, Parental Control, OSD Timeout, OSD Language, Power settings, Reset All, and Version.
SETUP MENUS Adjusting Date and Time 1 Use the keys to select Date and Time and press 2 Use the keys to select Date or Current Time and press 3 Use the keys to select a date or time segment. 4 Use the keys to adjust the value.
• Font: Can be set to As Broadcaster, Style 1, Style 2, Style 3, Style 4, Style 5, Style 6, or Style 7. • Size: Can be set to As Broadcaster, Small, Medium, or Large. • Font Color: Can be set to As Broadcaster, Black, White, Green, Blue, Red, Cyan, Yellow, or Magenta.
Page 46
SETUP MENUS The following options are available: • Rating: Select ON/OFF to hide or display the hidden submenu. • Block Unrated: Select ON/OFF to block/unlock all unrated programs. Adjusting Rating and Block Unrated 1 Use the keys to select Rating or Block Unrated and press 2 Use the keys to select ON or OFF.
Page 47
Adjusting TV Rating 1 Use the keys to select TV Rating and press 2 Use the repeatedly to block or unblock. You can also select Lock All to block all or Unlock All to unblock all. 3 Press to save and exit the screen. •...
Page 48
SETUP MENUS Adjusting MPAA Rating 1 Use the keys to select MPAA Rating and press 2 Use the repeatedly to block or unblock. 3 Press to save and exit the screen. • Canada English: Use this sub-menu to select the classification categories (based on Canadian ratings) of allowable TV programs and movies.
Page 49
2 Use the repeatedly to block or unblock. 3 Press to save and exit the screen. • Canada French: Use this sub-menu to select the ratings of allowable TV programs and movies. These ratings are based on the classification categories determined by La Régie du cinéma du Québec.
Page 50
SETUP MENUS • Channel Block: Channel Block allows you to block channels. Adjusting Channel Block 1 Use the keys to select Channel Block and press 2 Use the keys to select the desired channel and press repeatedly to block or unblock. 3 Press to save and exit the screen.
OSD Timeout Use OSD Timeout to adjust the OSD duration on the screen: 10 sec, 20 sec, or 30 sec. Adjusting OSD Timeout 1 Use the keys to select OSD Timeout and press 2 Press the keys on the remote control to select 10 sec, 20 sec, or 30 sec.
SETUP MENUS Power Settings Use this sub-menu to configure power-related settings for the LED TV. The following options are available: • VGA port -DPMS: Use this setting to enable or disable VGA port -DPMS. • Backlight: Use this setting to select the backlight mode: Bright Room, Medium Room, or Dark Room.
Page 53
SETUP MENUS Version Use this sub-menu to view the LED TV’s serial number and firmware version. Version...
WALL MOUNT OPTION WALL MOUNT OPTION The LED TV has been fitted with VESA FPMPMI compliant mounting holes. These 200 x 100 mm mounting holes allow the unit to be mounted on a wall. Use the four M4 x L10 mm screws to wall mount the LED TV. WALL MOUNT INSTALLATION REMINDERS •...
TROUBLESHOOTING Problem Corrective Action • • No power Power is suddenly Make sure the sleep timer is turned off. turned off. Use Reset All in Settings menu to reset your Forgotten PIN password. • Remote control • does not work. •...
Page 56
TROUBLESHOOTING Problem Corrective Action • No picture or the No Signal message appears when a • VGA cable is connected. • Picture is cut off or appear in a sidebar Press screen. • • Poor image quality • in TV mode (cutoff picture, snowy images).
Page 57
Speakers option is set to Off in Audio menu. NOTES: If the problem condition persists even after performing the recommended corrective actions, contact us by: • Logging on to www.wde.com • Contacting the Westinghouse Customer Service at (800) 701-0680 or e-mail us at service@wde.com TROUBLESHOOTING...
SPECIFICATIONS SPECIFICATIONS Item Specification Model Name LD-2655VX Active Area (Diagonal, mm) Resolution Brightness (Nits, typ) Panel Contrast Ratio (min) Response Time (min) Aspect Ratio Display color • • • Audio/Video Input/Output • Terminals • • • Speaker Out 10W (2 channels)
Page 59
Item Specification Power Consumption <1W (Standby, Watts) Dimensions (WxHxD) Physical Specifications Weight (Net) Weight (Gross) NOTES: • These product specifications are subject to change without user notification. • Do not set your computer graphics card to exceed the unit’s refresh rates;...
