M42 Bucket Elevators
Assembly, Operation, and Maintenance Manual
This manual applies to:
Bucket elevator capacities: 8000–20,000 BPH (283–708 m
Read this manual before using product. Failure to
follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
3
/h)
Part Number: 10230018 R10
Revised: January 26, 2024
Original Instructions
