- Page 1 Bulletin 160 SSC™ Remote Keypad FRN 1.x User Manual...
- Page 2 In no event will Rockwell Automation be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment. The examples and diagrams in this manual are included solely for illustrative purposes.
-
Page 3: Table Of Contents
Table of Contents Introduction Drive Compatibility ............. . . 1-1 Related Publications . -
Page 5: Drive Compatibility
Chapter Introduction The Remote Keypad can be used to change drive parameter values, monitor operating conditions, and control drive operation. Important: The four-character Remote Keypad display requires an extra keystroke in order to display a current parameter value. See feature 4 on page 1-5 and step 4 on page 3-1. -
Page 6: Remote Programming Adapter
Introduction Remote Programming Adapter The Remote Programming Adapter (160-RPA) allows the Remote Keypad to interface with a Bulletin 160 Series C drive. If your drive is equiped with a Ready/Fault Indicating Panel (160-B1) or a Program Keypad Module (160-P1), you must remove these modules and install a Remote Programming Adapter in order to use the Remote Keypad. -
Page 7: Grounding
Introduction Grounding It is required that the Remote Programming Adapter be earth grounded to improve noise immunity and to guard the Remote Keypad against hazardous DC bus potential voltages. ATTENTION: A hazard of electrical shock exists if the Remote Programming Adapter is not tied to earth ground. Failure to provide an earth ground connection can result in severe personal injury or death. -
Page 8: Connector Cable
Introduction Connector Cable A cable is used to connect the Remote Keypad to the Bulletin 160 Series C drive. The Keypad can be connected and disconnected when the drive is under power. Important: If P46 - [Input Mode] is set to 2 or 6, disconnecting the Remote Keypad will cause the drive to fault. -
Page 9: Features
Introduction Features The figure and table below identify and describe the Remote Keypad display, status indicators, and keys. Remote Keypad Features Figure 1.6 ATTENTION: The keypad control circuitry includes solid- state components. If hazards due to accidental contact with moving machinery or unintentional flow of liquid, gas or solids exist, an additional hardwired stop circuit is required... -
Page 10: Display Description
Introduction Display Description The keypad has a four-character LED display which shows parameter numbers, parameter values, and fault codes. The keypad monitors its connection to the drive. If this connection fails due to electrical noise or a hardware failure, the following is displayed. -
Page 11: Keypad Initialization Sequence
Introduction Keypad Initialization Sequence When the Remote Keypad is connected to the drive, and power is applied, the following is displayed for approximately two seconds. After two seconds have elapsed, the keypad will display the current value of the last Display Group parameter selected. In this example, P01 - [Output Frequency] is at 0.0 Hertz. - Page 12 Introduction End of Chapter...
-
Page 13: Installation
Chapter Installation ATTENTION: To guard against electrical shock, disconnect all power sources before installing or removing. Prepare Mounting Location • Select a mounting location that is less than 5 meters away from the drive. Connection cables are available in 1, 3, and 5 meter lengths. •... -
Page 14: Mount The Remote Keypad
Installation Mount the Remote Keypad Installation and Torque Sequence Figure 2.2 Temporary Torque Final Torque 0.3 N-m 0.6 N-m (2.7 in-lb) (6 in-lb) No Gap... -
Page 15: Control The Drive
Chapter Control the Drive Enable Keypad Control to Start the Drive The following steps also serve as a programming example. 1. With the Remote Keypad installed and connected to the Bulletin 160 Series C drive, power up the drive. The Remote Keypad always powers up in the Display mode. While in this mode you may view all read only drive parameters, but not modify them. -
Page 16: Stop The Drive
Control the Drive Stop the Drive Use the Stop key to command the drive to stop. The Stop key functions in all drive input modes whether or not the keypad is selected as the drive’s control source. ATTENTION: The keypad control circuitry includes solid-state components. -
Page 17: Troubleshooting
Chapter Troubleshooting ATTENTION: Only personnel familiar with the drive and associated machinery should plan or implement the installation, start- up, and subsequent maintenance of the system. Failure to comply may result in personal injury and/or equipment damage. ATTENTION: Ensure that you disconnect line power and wait three minutes before installing or removing the Ready/Fault Indicating Panel or Program Keypad Module. -
Page 18: Resolving Problems
Troubleshooting DRAFT – 7/19/99 Resolving Problems Description Cause Action Display is blank. No power to drive. Verify that the drive is under power. Connection failure. Verify that both ends of the connector cable are secure. Replace components one at a time in this order until problem is resolved: •... -
Page 19: Technical Specifications
Appendix Technical Specifications Dimensions 34.23 128.6 (1.35) (5.06) 11.5 (0.45) 168.2 (6.62) (in) Ambient Conditions • Operating temperature: 0˚ C to 50˚ C (32˚ F to 122˚ F) • Storage temperature: -40˚ C to 85˚ C (-40˚ F to 185˚ F) •... -
Page 20: Maintenance
Technical Specifications Maintenance Use only a soft cloth dampened with water to clean the keypad. ATTENTION: Hazard of electric shock, injury or death. Do not clean the keypad when it is plugged into a drive. Unplug cable from drive before cleaning. The RPA requires no maintenance or cleaning. - Page 21 Publication 0160-5.28ML – September, 1999 P/N 194308 (01) Copyright 1999 Rockwell International Corporation. All rights reserved. Printed in USA.
