aldes InspirAIR Top 300 Assembly Instructions Manual
Hide thumbs Also See for InspirAIR Top 300:

Advertisement

Quick Links

InspirAIR
®
Top
www.aldes.com
Notice d'installation
Assembly instructions
Installationsanleitung
Montagehandleiding
Instrucción de instalación
Istruzioni di montaggio
Инструкция по применению
FR
EN
DE
NL
ES
IT
RU

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the InspirAIR Top 300 and is the answer not in the manual?

Questions and answers

Summary of Contents for aldes InspirAIR Top 300

  • Page 1 Notice d’installation Assembly instructions Installationsanleitung Montagehandleiding Instrucción de instalación Istruzioni di montaggio ® InspirAIR Инструкция по применению www.aldes.com...
  • Page 2: Table Of Contents

    1. FOREWORD Thank you for choosing an ALDES product. We recommend that you read this document carefully and follow the instructions provided to ensure optimal operation of your equipment. Our liability as a manufacturer shall not be affected due to incorrect use, lack of or unsuitable servicing or incorrect installation. To ensure continuous improvement in the quality of our products, ALDES reserves the right to amend any product details published in this document at any time.
  • Page 3: Mechanical Risks

    2.2. Mechanical risks Always connect the air ducts to the unit before plugging in its power supply. This ensures that the motors cannot be touched when the unit is running. 2.3. Electrical risks The apparatus must not be powered on and operated by the end user as long as the product's protective channel and front panel are not fixed appropriately. 3.
  • Page 4: Installation Instructions

    4. INSTALLATION INSTRUCTIONS 4.1. Transport/unpacking On receipt of the product, verify its condition and record any remarks for the attention of the delivery company on the delivery slip. The delivery includes at least: - The unit and a wall fastening system - Documentation - A connector to fix the water trap to the unit (the water trap is sold as an accessory) Remove the banding from the product.
  • Page 5: Wall Fixing

    4.4. Wall fixing Wall fixing is the recommended mounting method for the unit. The fastening anchors must be adapted to the support wall and designed to withstand a load of 120 kg. Torx 20 4.4.1. Fastening Premium models - Fix the guide strip to the wall ( ) (the cardboard packaging includes a template for drilling the wall to the correct dimensions).
  • Page 6: Aeraulic Connections From The Unit

    4.6. Aeraulic connections from the unit We recommend using the following to connect the InspirAIR ® Top 450: - Flexible plastic ducting type Algaine D.200 with female connector RF D.150 (11093065) + RCC D160/200 (11098186) or galvanised or Alflex rigid ducts When installing the internal heating coil, it is mandatory to use galvanised ducts on the edges of the coil (see internal preheating coil instructions).
  • Page 7: Connecting Condensates

    Connections must be made with seal connectors as below: (the water trap kit and the elbow are accessories) 5. STARTING/ADJUSTMENTS 5.1. Starting The product must without fail be configured by one of these two interfaces: - Aldes InspirAIR ® remote control - Aldes Configurator...
  • Page 8: Structure Of Inspirair ® Remote Control Menus

    ® remote control (11023480 - InspirAIR ® remote control or 11023479 - InspirAIR ® remote control) as well as via the configuration software Aldes Configurator available on the https://services.aldes.com/logiciels site. Installer Assistant reboot Settings Language Country of inst. Date and hour Regulation mode Config.
  • Page 9 L0-L1-L2-L3. The use of this assistant outside of France is not recommended by Aldes. To set an unbalance of the supply air compared to extract air. This unique % will be taken in account on each Imbalance level L0 to L3.
  • Page 10: Scheme

    3) Power the product back on 4) Wait for the LED to turn green or about 30 s 5) Remove USB key The USB key must only contain the update file supplied by Aldes. 6. MAINTENANCE 6.1. Filter replacement Filters must be changed regularly depending on use conditions and the machine's environment. The installer can configure the filter timer from nine to twelve months.
  • Page 11: Cleaning The Heat Exchanger

    6.2. Cleaning the heat exchanger We recommend servicing the heat exchange very two years using the following procedure: Switch off the power. Open the filter flap. Remove the two screws holding the door. 4’. Tilt the door forwards and lift it. Remove the heat exchanger plug.
  • Page 12: Servicing

    7.1. General warranty terms and conditions Refer to the general terms and conditions on the www.aldes.fr site. The system must be installed by a qualified professional in compliance with best practices, the standards in force and the recommendations in our instructions. The system must be used normally and regularly serviced by a specialist.
  • Page 13: Erp

    8. ErP ® 8.1. InspirAIR Top 300 Supplier brand Aldes Aldes Aldes InspirAIR ® Top 300 InspirAIR ® Top 300 InspirAIR ® Top 300 Designation Classic Premium Premium ERV References 11023473 11023474 11023477 Energy class - Average climate Average climate - SEC - Specific energy consumption (kWh/(m...
  • Page 14: Inspirair ® Top 450

    8.2. InspirAIR ® Top 450 Supplier brand Aldes Aldes Aldes ® ® ® InspirAIR Top 450 InspirAIR Top 450 InspirAIR Top 450 Designation Classic Premium PREMIUM ERV References 11023476 11023478 11023478 Energy class - Average climate Average climate - SEC - Specific energy consumption (kWh/(m...
