- Page 1 ™ LightSpeed Technologies FOX1-KIT 4K UHD Uncompressed Video over Fiber Optic Cable Version: V1.0 User Manual...
- Page 2 ™ LightSpeed Technologies FOX1-KIT 4K UHD Uncompressed Video over Fiber Optic Cable Version: V1.0 Important Safety Instructions 1. Do not expose this apparatus to rain, moisture, dripping, or splashing, and no objects filled with liquids, such as vases, shall be placed on the apparatus.
- Page 3 ™ LightSpeed Technologies FOX1-KIT 4K UHD Uncompressed Video over Fiber Optic Cable Version: V1.0 FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 4: Table Of Contents
™ LightSpeed Technologies FOX1-KIT 4K UHD Uncompressed Video over Fiber Optic Cable Version: V1.0 Contents Introduction......................2 Images .........................3 Features ......................3 Package Contents ....................4 Specifications .......................5 Panel Description ....................7 Encoder .......................7 Decoder .......................8 Installation ......................9 Typical Applications ....................9 HDMI 2.0 Extender ..................9 Available exclusively from Future Ready Solutions www.lightspeed-tech.com | Email: info@lightspeed-tech.com | Phone: 239.948.3789... - Page 5 ™ LightSpeed Technologies FOX1-KIT 4K UHD Uncompressed Video over Fiber Optic Cable Version: V1.0 Available exclusively from Future Ready Solutions www.lightspeed-tech.com | Email: info@lightspeed-tech.com | Phone: 239.948.3789 Page 5...
-
Page 6: Introduction
Version: V1.0 Introduction LightSpeed Technologies™ FOX1-KIT (encoder and decoder) comes in a compact size and is an economical, flexible HDMI extender solution. It allows uncompressed true 4K@60Hz video to be extended with zero frame latency at 300 meters over multi-mode fiber, and 20km over single- mode fiber with 10Gb SFP+ modules. -
Page 7: Images
™ LightSpeed Technologies FOX1-KIT 4K UHD Uncompressed Video over Fiber Optic Cable Version: V1.0 Images Models FOX1-ENC FOX1-DEC Features • Compact size and economical design • HDMI 2.0 and HDCP 2.2 compliant • Lossless distribution of most timing formats •... -
Page 8: Package Contents
™ LightSpeed Technologies FOX1-KIT 4K UHD Uncompressed Video over Fiber Optic Cable Version: V1.0 Package Contents FOX1-ENC Encoder: • 1 x FOX1-ENC Encoder • 1 x 5VDC 2A Power Adapter (with US Pins) • 1 x SFP+ multi-mode optical transceiver •... -
Page 9: Specifications
™ LightSpeed Technologies FOX1-KIT 4K UHD Uncompressed Video over Fiber Optic Cable Version: V1.0 Specifications Model FOX1-ENC FOX1-DEC Video Input Video Port 1 x HDMI 1 x SFP+ (10GBase-SR) End-to-End Time Latency Zero-frame latency Output Video Port 1 x SFP+ (10GBase-SR) -
Page 10: Encoder
™ LightSpeed Technologies FOX1-KIT 4K UHD Uncompressed Video over Fiber Optic Cable Version: V1.0 Encoder Name Description ▪ On: The device is connected to a source but doesn’t transmit any streams. ▪ Blinking quickly: The device is connected to a source and transmitting SYSTEM LED streams. -
Page 11: Decoder
™ LightSpeed Technologies FOX1-KIT 4K UHD Uncompressed Video over Fiber Optic Cable Version: V1.0 Panel Description Decoder Name Description ▪ On: The device is connected to a display but doesn’t receive any streams. ▪ Blinking quickly: The device is connected to a display and is receiving SYSTEM LED streams. -
Page 12: Installation
™ LightSpeed Technologies FOX1-KIT 4K UHD Uncompressed Video over Fiber Optic Cable Version: V1.0 INSTALLATION Typical Application HDMI 2.0 Extender Features: • 4K Video transmission • Zero latency from end to end • Maximum extension distance is 300 meters over...
