3. Block diagram

4. Technical Data

AMP / INST / LINE IN
Input Impedance
User's manuals - https://wiki.two-notes.com/
39/41
On / Off 0 - 1
Instrument 0 - 1
Dry / Wet 0 - 127 0 = 0% ; 63 = 50% ; 127 = 100%
Body 0 - 127 0 = 0% ; 63 = 50% ; 127 = 100%
Thickness 0 - 127 0 = 0% ; 63 = 50% ; 127 = 100%
Brilliance 0 - 127 0 = 0% ; 63 = 50% ; 127 = 100%
On / Off 0 - 1
Preset 0 - 11
Type 0 - 1
Dry / Wet 0 - 127 0 = 0% ; 63 = 50% ; 127 = 100%
Size 0 - 127 0 = 0% ; 63 = 50% ; 127 = 100%
Echo 0 - 127 0 = 0% ; 63 = 50% ; 127 = 100%
Color 0 - 127 0 = 0% ; 63 = 50% ; 127 = 100%
Preset Level 0 - 107 "
Master Volume 0 -100
Master Mute 0 - 1
Preset 0 - 99
Input/Output
1/4" Jack balanced (TRS)
AMP
LINE
INST.
0 = Off ; 1 = On
0 = Guitar ; 1 = Bass
0 = Off ; 1 = On
0 = Studio A ; 1 = Studio B ; 2 = Basement...
0 = Room ; 1 = Ambience
0 = Mute ; 1-100 = Level
0 = Off (no mute) ; 1 = On (mute)
0 = Preset #1 ; 1 = Preset #2...
160kΩ unbalanced / 300kΩ balanced
37kΩ unbalanced / 55kΩ balanced
1MΩ unbalanced
