nature of the input source:
If you are connecting your instrument, set the switch to INST
If you are connecting a hardware audio device that delivers line level signal, set the switch to
LINE
If you are connecting an amp, set the switch to AMP
If after setting the 3-way IN LEVEL switch - correctly in accordance with your signal requirements -
OPUS displays a clipping signal , please then use the INPUT PAD to further attenuate your source
signal.
3. Line Out Routing
OPUS' LINE OUT ROUTING is accessible through the MENU directly via the pedal's screen:
First, from the Preset Window on OPUS' OLED display, push the right encoder to enter the Main
Menu
Then, navigate to the "Global" Menu (indicated by a cog icon) using the right encoder to scroll
through the sections and push the right encoder to enter this menu.
Once inside the Global Menu, scroll to "Line Out Routing" using the right encoder
You can then use the right encoder to select where in OPUS' DSP architecture the signal for the
¼-inch Line output is fed:
NO PROCESSING: The LINE output sends the dry input signal from OPUS without any
processing. Please note, this non-processed signal still passes through OPUS' DSP and
therefore features the same latency as the signal feeding the XLR DI output. The latency
can be configured in the AUDIO PERFORMANCE menu.
AFTER TSM AMPLIFIER: The LINE output sends the signal after the PREAMP, POWER AMP
and NOISE GATE within OPUS
AFTER CAB SIM: The LINE output sends the signal post the volume levels of the DynIR
cabinet emulation microphone channels within OPUS
AFTER POST FX: The LINE output sends the signal featuring all DSP processing within
OPUS. With this setting, the LINE and DI outputs send the same processed signal
Please be advised, you can also set the LINE OUTPUT ROUTING via the SETUP menu in Torpedo
Remote, accessible from the main window via the EDIT menu. The different options are listed in the
drop down menu next to LINE OUT ROUTING.
Top Tip: In addition, it is important to note that the LINE OUT level is directly affected by the PRESET
and VOLUME levels regardless of any DSP-centric processing that is applied.

4. Audio Performance

Within this menu item, the indicated latency is the summative latency of the whole device, measured
from the input to the output. Even at the highest setting, the latency is low enough not to be noticed
when playing. However, latency is cumulative and can add up when using several digital products; as
a result, this can lead to a point where it becomes noticeable. In that case, lowering this setting can
