Crown K Series Operation Manual
Crown audio operation power amplifier k series
Hide thumbs
Also See for K Series:
- Reference manual (42 pages) ,
- Operation manual (20 pages) ,
- Reference manual (40 pages)
Table of Contents
Advertisement
Operation Manual
Obtaining Other Language Versions: To obtain information in another language about the use of this product, please contact your
local Crown Distributor. If you need assistance locating your local distributor, please contact Crown at 574-294-8000.
This manual does not include all of the details of design, production, or variations of the equipment. Nor does it cover every possible
situation which may arise during installation, operation or maintenance.
The information provided in this manual was deemed accurate as of the publication date. However, updates to this information may have
occurred. To obtain the latest version of this manual, please visit the Crown website at www.crownaudio.com.
Trademark Notice: Crown, Crown Audio, BCA and Amcron are registered trademarks of Crown International. Other trademarks are the
property of their respective owners.
©2005 by Crown Audio
K Series
2
Some models may be exported under the name Amcron.
®
, Inc. 1718 W. Mishawaka Rd., Elkhart, Indiana 46517-9439 U.S.A. Telephone: 574-294-8000
K1
K2
®
102010-8
4/05
