Summary of Contents for Ducky Origin

  • Page 1 User Manual...
  • Page 2: Table Of Contents

    目 錄 Ducky Origin 非背光規格 指示燈亮度調整 回復出廠設定 Windows Lock功能 滑鼠控制功能 DIP指撥開關功能 鍵位切換 Ducky Macro V2.1 Ducky Macro V2.1 設定區域的範圍 Ducky Macro V2.1 指定「多媒體鍵功能」設定輸入指令 Ducky Macro V2.1 Windows常見功能快捷鍵 Ducky Macro V2.1 指定「鍵盤按鍵功能」設定輸入指令 Ducky Macro V2.1 使用範例 熱插拔使用說明 免責說明...
  • Page 3 Key Switch Function Ducky Macro V2.1 Ducky Macro V2.1 Setting Section Ducky Macro V2.1 Multimedia Function Keys Ducky Macro V2.1 Windows Common Function Keys Ducky Macro V2.1 Keyboard Button Function Keys Ducky Macro V2.1 Set Up Example Hot-swap Set-up Example...
  • Page 4: Ducky Origin 非背光規格

    Ducky Origin 非背光 100% 美規 型號: DKOR2308A/DKOR2308I 種類:機械式結構 ■ 軸體:機械軸 ■ 鍵帽材質:PBT 或 ABS ■ 印字技術: ■ 二色成形 或 雷射雕刻 或 熱昇華 產地:台灣 ■ 100% 歐規 100% ■ 尺寸:450 x 140 x 40 mm ■ 重量:1250g 確切規格每個地區可能會有所不 同,詳細請詢問各地代理商。...
  • Page 5: 指示燈亮度調整

    指示燈亮度調整 指示燈亮度提升 Fn + Alt + ↑ 指示燈亮度降低 Fn + Alt + ↓ 回復出廠設定 註: 左Windows鍵 + 右Windows鍵 美規、歐規 壓住3秒後,鍵盤或指示燈會閃3下表示回復。...
  • Page 6: Windows Lock功能

    開啟 / 關閉 Windows 鍵功能 註: Fn + 任一Alt + 任一Windows鍵 DIP1指撥開關為ON,壓住3秒後,全鍵盤會閃3下表示切換完成 (預設為開啟Windows鍵功能)。...
  • Page 7: 滑鼠控制功能

    滑鼠控制功能 滑鼠功能示意圖 100%(Full Size) Mouse 開啟 / 關閉(預設): 100%(Full Size) → Fn + Alt + Number Lock 提示: 最右邊的M指示燈亮起, 代表開啟滑鼠功能。...
  • Page 8: Dip指撥開關功能

    DIP1 Windows Windows 關閉 鍵鎖定功能 開啟 鍵鎖定功能 OFF ( 預設 DIP2 N-Key Rollover任意全鍵輸出 6-Key Rollover任意6鍵輸出 對Mac及Linux裝置有用 OFF ( 預設 DIP3 Ducky VID 可自定 註: OFF ( 預設 切換每一次的DIP的On與 DIP4 Windows Windows 預設為右 鍵 右 鍵替換為 Off,鍵盤就必須重新 Menu 鍵 插 拔 , 功 能 才 會 生...
  • Page 9: 鍵位切換

    鍵位切換 1. 適用按鍵 : Fn/Alt/Ctrl/Windows/Caps Lock 2. 操作方式 : ● 按住 Fn + Alt + k 達 5 秒,Esc、左Ctrl、左Win鍵、左Alt、右Alt、右Win鍵、Fn、 右Ctrl及Caps Lock鍵皆會亮起,燈色分別為粉、紅、橙、黃、綠、藍、靛、紫、 白。 ● 除Esc、Caps Lock鍵外,其餘7個按鍵只要同時或依序按下任意2顆,即可交換其鍵 位。(燈色也會跟著交換) ● 按1下後Caps Lock鍵將改變其功能,順序為Caps Lock (白燈) ->Fn(靛燈) ->左Ctrl (紅燈)依序循環。(Caps Lock會依據功能來亮燈) ● 再按Caps Lock鍵1下來恢復Caps Lock鍵功能。(Caps Lock鍵將亮白燈) ●...
  • Page 10: Ducky Macro V2.1

    Ducky Macro V2.1 Step1. 選取要錄製的Profile 切換至第1組設定 原始鍵盤功能(預設值) 切換至第2組設定 切換至第3組設定 切換至第4組設定 可自定義按鍵Macro功能 切換至第5組設定 切換至第6組設定 註:當切換完後,CapsLock 或指示燈會閃爍該設定值數字的次數。 Step2. 進入錄製模式 按住 Fn + Alt + Tab 3 秒進入錄製模式,進入後 Caps Lock 或指示燈會慢速閃爍。 Step3. 按下按鍵 按下想要錄製的按鍵,按下後,該按鍵會亮起(非背光版本則不會),CapsLock 或指示燈會 快速閃爍。 Step4. 輸入想要的按鍵設定 輸入想要設定的按鍵功能。 Step5. 結束錄製或是錄製其他按鍵 按下 Fn + Alt + Tab 達1秒結束 Macro 錄製,或是按下 Fn + Alt 繼續錄製其他按鍵。...
  • Page 11: Ducky Macro V2.1 設定區域的範圍

    Ducky Macro V2.1 無法設定Macro功能的按鍵 可設定Macro的按鍵(以美規為例) 設定區域的範圍 原始鍵盤層 Fn + ESC Fn + F1~F12 Fn + PrtSc Fn + ScrLk Fn + Pause Fn + 0~9 ●白色按鍵為可設定的區域,灰色按鍵為不可設定的區域。 Fn + Ctrl Fn + Alt Fn層 Fn + Windows Fn + ↑ ↓ ← →...
  • Page 12: Ducky Macro V2.1 指定「多媒體鍵功能」設定輸入指令

    Ducky Macro V2.1 指定「多媒體鍵功 Fn + Windows鍵 + 下方按鍵 能」設定輸入指令 音量靜音 搜尋 音量變大 上一頁 音量變小 下一頁 播放 / 暫停 滑鼠左鍵 停止 滑鼠右鍵 下一首 滑鼠中鍵 上一首 滑鼠游標向上 計算機 滑鼠游標向下 我的電腦 滑鼠游標向左 瀏覽器首頁 滑鼠游標向右 郵件 滑鼠滾輪向上捲動 多媒體程式 滑鼠滾輪向下捲動 清除單一個設定檔的Macro設定 任一個Windows鍵 + 空白鍵3秒...
  • Page 13: Ducky Macro V2.1 Windows常見功能快捷鍵

    Ducky Macro V2.1 Windows 常見 功能快捷鍵 Ctrl + C Windows鍵 + D 複製選取的項目 顯示桌面 Ctrl + X Windows鍵 + M 剪下選取的項目 將所有視窗最小化 Ctrl + V Windows鍵 + L 貼上選取的項目 鎖定電腦或切換使用者 Ctrl + Z Windows鍵 + R 復原動作 開啟 [執行] 對話方塊...
  • Page 14: Ducky Macro V2.1 指定「鍵盤按鍵功能」設定輸入指令

    Ducky Macro V2.1 指定「鍵盤按鍵功 Fn + Shift鍵 + 下方按鍵 能」設定輸入指令 提示 Pro le 值 燈光模式 : 波浪模式 Pro le 1 燈光模式 : 循環模式 Pro le 2 燈光模式 : 雨滴模式 Pro le 3 燈光模式 : 漣漪模式 Pro le 4 燈光模式 : 隨機單點亮模式...
  • Page 15: Ducky Macro V2.1 使用範例

    Ducky Macro V2.1 情境A 想要將Z設定成Q輸出 使用範例 操作方式: 按住 Fn + Alt + Tab 達3秒鐘 → 按下Z → 按下Q → 按下 Fn + Alt → 按住 Fn + Alt + Tab 達1秒 在 Windows 系統下,想要按下Z就能顯示桌面 情境B 操作方式: 按住 Fn + Alt + Tab 達3秒鐘 → 按下Z → 按住Windows鍵 + D → 按下 Fn + Alt →...
  • Page 16: 熱插拔使用說明

    熱插拔使用說明 使用範例 使用拔鍵器拔出鍵帽 拔軸器將軸拔出 步驟一 步驟二 校對針腳與孔位 垂直輕按並定位軸體 步驟三 步驟四...
  • Page 17: 免責說明

    免責說明 ●進行熱插拔軸體時,請確保穩住鍵盤,再將軸體拔起。 ●插入軸體時請確保方向正確,並且不會過度用力而損壞軸體與 PCB 電路板。 ●當有任何液體侵入鍵盤等硬體設備導致損壞,將喪失保固。 ●任何的鍵盤改裝,都將使保固失效。 保固期為從我們官方供應商購買日起一年 https://www.duckychannel.com.tw/en/location/global 任何關於產品的退貨流程等問題,請您聯繫所購買的供應商會協助您處理。...
  • Page 18: Ducky Origin Non-Backlit Specs

    ■ Keycap Material: PBT or ABS ■ Printing Method: Double-Shot or ■ Laser engraved or Dye-Sublimation Origin Of Production: Taiwan ■ 100% Full size ■ Size: 450 x 140 x 40 mm ■ Weight: 1250g For more information on the specs...
  • Page 19: Indicator Light Brightness Adjustment

    Indicator light brightness adjustment Increase brightness Fn + Alt +↑ Decrease brightness Fn + Alt +↓ Reset Back to Factory Defaults Note: Hold for 3 seconds. The US ANSI and EU ISO layout Left Windows key + Right Windows key keyboard’s backlit will flash 3 times to indicate the keyboard have been reset.
  • Page 20: Windows Key Lock Feature

    Open / Close Windows Function (Windows Key Lock) While DIP 1 is ON, press and hold Fn + any Alt keys + any Windows key for 3 seconds, the keyboard’s backlit will flash 3 times to indicate the keyboard that have been turned ON / OFF(The default setting is ON).
  • Page 21: Mouse Function

    Mouse Function Mouse function diagram 100%(Full Size) Mouse ON/ OFF (default setting): Full Size → Fn + Alt + Number Lock Note: The corner right indicator “M” key will light up upon activation.
  • Page 22: Dip Switch Functions

    OFF (Default) DIP2 NKRO Mode 6 Key Rollover - Useful for Mac and Linux devices OFF (Default) DIP3 Ducky Vendor ID (VID) User de ned VID Note : OFF (Default) You can input the ideal VID in both situation, but DIP4...
  • Page 23: Key Switch Function

    Key Switch Functions 1. Applicable keys: Fn/Alt/Ctrl/Windows/Caps Lock 2. Operation: ● Press Fn + Alt + k for 5 seconds. DIP1 ● Until the Esc, L_Ctrl, L_Win, L_Alt, R_Alt, R_Win, Fn, R_Ctrl, and Caps Lock keys are all lighting up. The colorways are respectively pink, red, orange, yellow, green, blue, indigo, purple and white.
  • Page 24: Ducky Macro V2.1

    Ducky Macro V2.1 Step1. Profile Selections Switch to profile 1 Factory settings (Default) Switch to profile 2 Switch to profile 3 Customize Macro Key Switch to profile 4 Features Switch to profile 5 Switch to profile 6 Note: Once the profile is selected then the Caps Lock or indicator lights will blink in the amount of selected profile number.
  • Page 25: Ducky Macro V2.1 Setting Section

    Ducky Macro V2.1 Unable to set Macro function Keys can be set to Macro (US ANSI keyboard as example) Setting Section Default Layer Fn + ESC Fn + F1~F12 Fn + PrtSc Fn + ScrLk Fn + Pause Fn + 0~9 ●...
  • Page 26: Ducky Macro V2.1 Multimedia Function Keys

    Ducky Macro V2.1 Multimedia Fn + Windows Key + Keys below Function Keys Mute Search Volume up Previous page Volume down Next page Play / Pause Mouse Left Click Stop Mouse Right Click Next playlist Mouse Middle Click Previous playlist...
  • Page 27: Ducky Macro V2.1 Windows Common Function Keys

    Ducky Macro V2.1 Windows Common Function Keys Ctrl + C Copy select item Windows + D Desktop Ctrl + X Cut select item Windows + M Minimized all windows Ctrl + V Paste select item Lock computer or change user...
  • Page 28: Ducky Macro V2.1 Keyboard Button Function Keys

    Ducky Macro V2.1 Keyboard Button Function Keys Fn + Shift + Keys below Prompt Pro le value Backlit mode : Wave mode (Default) Pro le 1 Backlit mode : Color Cycle mode Pro le 2 Backlit mode : Rain Drop mode...
  • Page 29: Ducky Macro V2.1 Set Up Example

    Ducky Macro V2.1 Example A Configure the key “Z”to “Q” output. Set Up Example Operation method: Windows + M Press Fn + Alt + Tab for 3 seconds → Press Z → Press down Q → Press Fn + Alt →...
  • Page 30: Hot-Swap Set-Up Example

    Hot-swap Set-up Example Use key puller to pull out the key caps Use switch puller to pull out the switches Step 2 Step 1 Align switch pins with the holes Gently push the switch in Step 3 Step 4...
  • Page 31: Disclaimers

    Disclaimers ●When swapping out switches, please make sure to secure the keyboard in place and then pull the switch out. ●Please ensure the correct pin direction and avoid applying excessive force to prevent damaging the PCB and switch during inserting switches. ●Products that have been exposed to liquid damage will not be under warranty coverage.
  • Page 32 www.duckychannel.com.tw...

This manual is also suitable for:

Dkor2308aDkor2308i
