Network Wireless Zone Explanation Terminal

Description

The system provides wireless zone explanation function to meet the needs for amplification of live
explanation, and shares the broadcasting speakers for sound reinforcement without being affected by the
broadcasting, enabling seamless and smooth switching among the explanation areas, allowing the on-site
docent to switch his explanation freely while walking from one area to another, and truly realizing the
explanation effect of "sound starts from the arrival of people and stops at their departure; sound moves
along with people, as if shadowing them".
The system features a variety of functions such as broadcasting, timing playback, paging and fire alarm of
the network public address system, as well as automatic zone explanation.

Features

 With all functions of the network system such as background music playback, timing broadcast, paging
and fire alarm.
 The system shares the broadcasting speakers for sound reinforcement of live explanation without being
affected by the broadcasting, enabling seamless and smooth switching among the explanation areas,
allowing free switching of explanations of the on-site docent while walking from one area to another.
 Adopt UWB technology for accurate detection, and calculate the distance from the people to the base
station through the flight time of the electromagnetic wave from the tag to the base station, with an
export@dsppa.com
/
www.dsppatech.com
MAG6301 MAG63PL
Network Wireless Zone Explanation System
MAG6301
MAG63PL
Positioning Tag
The specifications will be subject to change without prior notice.
Copyright © Guangzhou DSPPA Audio Co., Ltd. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAG6301 and is the answer not in the manual?

Questions and answers

Summary of Contents for DSPPA MAG6301

  • Page 1 The specifications will be subject to change without prior notice. Copyright © Guangzhou DSPPA Audio Co., Ltd. All rights reserved.
  • Page 2 Maximum Frequency Deviation ±45 KHz Audio Response 140Hz-12KHz(±3dB) Comprehensive S/N Ratio >70dB Comprehensive Distortion ≤1% Operating Temperature -10℃-+40℃ export@dsppa.com www.dsppatech.com The specifications will be subject to change without prior notice. Copyright © Guangzhou DSPPA Audio Co., Ltd. All rights reserved.
  • Page 3 0℃~70℃ Operating Humidity 0 to 95%, no condensation Protection Level ip67 Product Dimensions 110×65×10mm Net Weight Charging Voltage export@dsppa.com www.dsppatech.com The specifications will be subject to change without prior notice. Copyright © Guangzhou DSPPA Audio Co., Ltd. All rights reserved.
  • Page 4 10 Infrared Frequency Pairing Window (IR) Used for infrared frequency pairing with the handheld microphone. 11 Working Indicator export@dsppa.com www.dsppatech.com The specifications will be subject to change without prior notice. Copyright © Guangzhou DSPPA Audio Co., Ltd. All rights reserved.
  • Page 5 Press and hold the button to power it on/off. Buzzer There will be a beeping sound for power-on/off. export@dsppa.com www.dsppatech.com The specifications will be subject to change without prior notice. Copyright © Guangzhou DSPPA Audio Co., Ltd. All rights reserved.
