- Page 1 Specifications are subject to change without notice. IP Network Terminal www.dsppatech.com DSP9136 DSP9136E User Manual Guangzhou DSPPA Audio Co. Ltd. Address:No.1 Xiahe Rd,Jianggao,Baiyun,Guangzhou,China Post Code:510450 Tel:+86-20-37166501 Website:www.dsppatech.com Guangzhou DSPPA Audio Co., Ltd...
- Page 2 Precautions for safety Contents Warning: In order to reduce the risks in electric shock or damage to equipment, Preface please conform to the following requirements: Product Introduction Features ● Do not insert the power plug of the device into the power grid without Information connecting the system line.
- Page 3 ● Can play background music, emergency paging and alarm signals from the host Size Height Width Depth Model ● Support control and play through management software DSP9136 ● Priority level: 100V input>Network audio source>local MIC/AUX/built-in audio DSP9136E source Unit: mm ● RMS 2×10W. www.dsppatech.com Guangzhou DSPPA Audio Co., Ltd...
- Page 4 Right speaker negative side Switch Internal positive side Power Input (Support POE① function) (DC) Internal negative side Note: 1. Priority level: 100V input ＞Network audio ＞Local MIC /AUX/Built-in audio 2. ① only applies to DSP9136E www.dsppatech.com Guangzhou DSPPA Audio Co., Ltd...
- Page 5 Finally, fix the product to the wall as shown in the figure below. Check whether the installation is reliable and stable and connect product according to actual need. (Please refer to connection diagram). www.dsppatech.com Guangzhou DSPPA Audio Co., Ltd...
- Page 6 HTTP, HTTPS, FTP, DNS, DDNS, RFC3261, RTP, agreements Other RTSP, RTCP, UPnP Power Input 16V/2.5~3.0A DC POE+(IEEE 802.3at) Size (H×W×D) 35×125×100mm Net Weight 0.8kg 0.5kg Packing List Component Quantity Network Decode Player The power adapter(* Only DSP9136 provides User manual www.dsppatech.com Guangzhou DSPPA Audio Co., Ltd...
