- Page 1 BMIC Operators Guide Version 1 Warning: This manual contains important safety and operating information. Please read, understand and follow the instructions in the manual.
-
Page 2: Table Of Contents
Bmic Operators Guide Contents Page Introduction & Equipment List Bmic Controls & Using the Bmic LED indication Care of the Bmic Battery warning Battery replacement Charging the Bmic batteries Operator Guidance Technical Specification Warranty... -
Page 3: Introduction & Equipment List
Equipment list Bmic hand held control unit Microphone unit with cable & Tripod Unit 2 probe rods AC adapter Headphones Carry bag Instruction manual The Bmic equipment is shown below (note the AC adapter, carry bag and manual are not shown). -
Page 4: Bmic Controls & Using The Bmic
Trigger Switch Using the Bmic The Bmic is simple to operate. Select either the probe rods or the tripod unit and screw into the microphone unit. (Use the tripod foot on hard ground and use the probe rods on soft ground or when accessing water pipe fittings). -
Page 5: Battery Warning
The Bmic in use Battery Warning The Bmic contains a Nickel Metal Hydride battery which must not be used on any other equipment if removed. Only batteries supplied by Halma Water Management must be used as replacements. Do not short circuit or misuse these batteries as this may result in explosion or fire. -
Page 6: Operator Guidance
Bmic Operator Guidance: Background information for effective acoustic leak detection All acoustic leak detection methods are based on the premise that normal water passage through pipelines takes place noiselessly. When the water passage is disturbed a noise is created. Causes can include partial pipe blockages, sudden changes in pipe diameter, abrupt changes in pipe direction, pumps or meters installed in the pipeline, consumer usage or pipeline damage. - Page 7 Select the most suitable sensor device; the microphone foot for hard ground surfaces or the hand probe for soft ground. Press the trigger to operate the Bmic and adjust the headphone volume control to a comfortable listening level. Once you have listened to the noise through the headphones, release the trigger to switch off the amplifier and move the microphone foot or hand probe to the next test position.
-
Page 8: Technical Specification
Technical Specification Bmic hand held unit/sensor housing Piezoelectric high sensitivity sensor mounted in PC-ABS (polycarbonate) housing Single headphone/charger input socket with automatic sensing of device connected Connectors Amphenol military specification connectors for microphone and headphone/charger connections Charging Universal 110-240V AC charger with 12V DC output 4-pin Amphenol connectors to control unit Charge time: Overnight charge. - Page 9 Fluid Conservation Systems 1960 Old Gatesburg Road STE 150 State College, PA 16803 (800)531-5465 fluidconservation.com MAN-080-0002-A [BMIC Operators Guide - Version 1]...
