Changing the dosing scale ...........22 Connecting the suction hose .........24 Installation tips ............27 Connecting the external injection (IE) kit......29 Automatic additive anti-siphoning system ......31 STARTING UP THE DOSATRON ........33 Using for the first time ..........33 Use ..............34 Adjusting the dosing (without pressure)......35 Dosing principle............35 By-pass option ............36...
Page 4
Cleaning and refitting the suction valve ......53 Replacing the motor piston (without pressure) .....54 TROUBLESHOOTING ..........55 WARRANTY ..............59 APPENDICES ............61 Graphs ..............61...
Over time, this DOSATRON will prove itself to be a most faithful ally. A few regular maintenance operations will guarantee operation in which the word “breakdown” will no longer be heard.
Page 6
This document does not form a contractual engagement and is for information purposes only. DOSATRON INTERNATIONAL reserves the right to modify its devices at any time. CE Conformity Statement Document No. DOCE06050103 This Dosatron is in compliance with the European Directive 2006/42/CE.
Technology Unique technology that incorporates all dosing functions. Installed on the water supply line, the DOSATRON uses water pressure as the only power source. When activated, it draws in the concentrate, doses it to the desired percentage, and mixes it with the motive water. The resulting solution is then propelled downstream.
Marking/Identification Specifications MARKING Your dosing pump has 3 main marking zones, allowing it to be identified in detail: • A 2-line engraving on the side of the top cover with the exact part number of the device on the first line and the serial number on the second line. fig 2 / 11...
Page 12
3 • A QR code - simply scan it with your smartphone and download the DOSATRON application. This gives you access to a wide range of resources and information about your dosing pump. fig 4 / 12...
CODIFICATION OF THE PART NUMBER PART No..........Serial No........Example Dosatron Range Additive line WL: Water Line Dosing indication Certification N: Drinking water standard IE: External injection option BP: Manual By-pass option Dosing Seal type VF: Acidic fluid...
Connection (NPT/BSP male gas fittings): ..Ø40 x 49mm [1 1/2”] Hydraulic motor capacity (every two clicks of the piston): approx.1.7L [0.449US Gallons] ATTENTION! The DOSATRON is not pre-set, please refer to the paragraph on Adjusting the dosing (without pressure), page 35 DIMENSIONS Diameter: cm [“]...
Connection(NPT/BSP male gas fittings): ....... Ø40 x 49mm [1 1/ 2”] Hydraulic motor capacity(every two clicks of the piston): approx.1.7L [0.449US Gallons] ATTENTION! The DOSATRON is not pre-set, please refer to the paragraph on Adjusting the dosing (without pressure), page 35 DIMENSIONS Diameter:cm[”]...
Page 16
PACKAGE WEIGHT: Approx. 5.5 kg [~ 12.1 US lbs] / 16...
• If the system is located at a higher level than the DOSATRON itself, there is a possible risk of water and concentrate flowing back into the DOSATRON.
Page 18
Water with a high particle content If the water has a high abrasive particle content which could cause premature wear of the Dosatron, it is essential to install an upstream filter (e. g 130 microns - 120 mesh or finer).
Page 19
Installation location • The DOSATRON and the dosing additive must be accessible at all times. Their installation must under no circumstances present a pollution or contamination risk. • It is recommended that all water pipes are marked showing that the water contains additives and with the wording: “CAUTION! Non-potable water”...
INSTALLING THE DOSOTRON ATTENTION! THE INSTALLATION SHOULD BE CARRIED OUT WITHOUT TOOLS Remove the protective caps which block the openings in your DOSATRON, before connecting it to the water supply line. fig 5 Make sure you follow the direction of fluid flow as shown by the arrow on the pump body (see the bubble in the figure above).
Page 21
• a suction hose with a strainer. The mounting bracket enables the DOSATRON to be mounted on a wall. Insert the DOSATRON dovetails into the mounting bracket. Scan the QR code below with your smartphone. It will allow you to download the DOSATRON application, register your device and access a wide range of resources and information about your dosing pump.
Ø 40 x 49 mm [1 1/2”]. Make sure that the water flows in the same direction as the arrows (water flow direction) on the device. Whenever possible, install the DOSATRON high enough to be able to read and adjust the dosing on the graduated scale in % or ratio.
Page 23
fig 9 fig 10 — Ensure that the centring pins are — Manually retighten the fixing nut aligned with the groove in the pump on the injection assembly. body. If necessary, to see the pins better, unscrew dosing adjustment sleeve to the middle of its travel.
CONNECTING THE SUCTION HOSE The DOSATRON is supplied with a suction hose (to be adjusted as required) which allows it to be used with a large capacity container. This hose must be fitted with the strainer and ballast. NOTA: Maximum suction height: 4 m [13 ft]...
Page 25
D9WL2 - Unscrew the nut at the bottom of Push the hose into the barbed fitting the injection assembly and thread as far as it will go and screw the nut the suction hose through the nut. by hand. - Assemble the strainer on the other end of the hose using the same method - Immerse the strainer into the...
Page 26
D9WL5 - Pass the suction hose through the - Push the hose all the way onto the clamp. suction valve fitting, position the clamp over the middle of the fitting and tighten it. - Assemble the strainer on the other end of the hose using the same method - Immerse the strainer into the...
INSTALLATION TIPS The DOSATRON must be assembled in by-pass as shown below. An in-line assembly is possible but not recommended because it does not enable the dosing pump to be easily isolated for maintenance (necessary to cut off the water supply).
Page 28
To prolong the service life of the DOSATRON, we recommend fitting an upstream filter (e.g 130 microns - 120 mesh, depending on your water quality). This precaution is essential if the water contains impurities or particles, especially when using water from a well or surface water The filter is recommended and required for the warranty to be valid.
CONNECTING THE EXTERNAL INJECTION (IE) KIT Your DOSATRON D9WL3000IE comes with an external injection connection port. Remove the protective caps from the connection ports on both your DOSATRON and your external injection kit. ATTENTION! No tools should be used. fig 17...
Page 30
First remove the suction Install the external injection components as valve pre-installed on shown in the diagram below the dosing pump fig 18 fig 19 / 30...
AUTOMATIC ADDITIVE ANTI-SIPHONING SYSTEM - It automatically restores the atmospheric pressure in the installation in the event of accidental depressurisation (e. g. when the dosing the dosing pump outlet is lower than the inlet). - When putting the machine into service, remove the red cap. fig 20 / 31...
Slowly open the fast priming valve located downstream of the DOSATRON. • Let the DOSATRON run until the additive to be dosed rises in the injection assembly (you will be able to see it through the transparent tube), then close the fast priming valve.
To accelerate the priming, set the dosing level to maximum. Once the DOSATRON is primed, drop the pressure to zero and adjust to the required dosing value (please refer to the paragraph on...
ADJUSTING THE DOSING (WITHOUT PRESSURE) ATTENTION! No tools should be used. The dosing adjustment must be carried out with no pressure in the system • Turn off the water supply and allow the pressure to drop to zero. • Unscrew the dosing locking nut. •...
BY-PASS OPTION The upper part of the DOSATRON can be equipped with a by-pass function (optional): • By-pass set to ON, the DOSATRON operates and the additive is drawn up. • By-pass set to OFF, the DOSATRON stops and does not draw up the additive.
FEET OPTIONS If necessary, or if your DOSATRON cannot be fitted to the wall, the D9 DOSATRON range can be installed on feet using the 8EQ001 kit: • Insert each foot in the corresponding holes on the bracket supplied with the dosing pump and the bracket included in the kit •...
(shown below) with a silicone- based lubricant. 2.If your DOSATRON has not been used for a certain period of time, remove the motor piston and soak it in lukewarm water (<40 ° C) for a few hours before starting it up again.
DRAINING THE DOSATRON In order to perform thorough maintenance on the DOSATRON, or to protect it from frost, it may be necessary to drain it. • Turn off the water supply and allow the pressure to drop to zero. •...
Precautions section, page NOTA: Before dismantling, and to avoid any contact with the injected additives, turn on the DOSATRON and allow it to draw in clear water in order to rinse the injection assembly. D9WL3000 / D9WL3000IE •...
Page 42
D9WL2 • Unscrew the nut at the bottom of the injection assembly • Remove the hose from the suction valve fitting by pulling it downwards. • Reassemble in the reverse order. If necessary, please refer to Connecting the suction hose, page fig 32 fig 33 / 42...
Page 43
D9WL5 • Unscrew the hose clamp. • Remove the hose from the suction valve fitting by pulling it downwards. • Reassemble in the reverse order. If necessary, please refer to Connecting the suction hose, page fig 34 fig 35 / 43...
Precautions section, page NOTA: Before dismantling, and to avoid any contact with the injected additives, turn on the DOSATRON and allow it to draw in clear water in order to rinse the injection assembly. • Turn off the water supply and allow the pressure to drop to zero.
REPLACING THE INJECTION SEALS Frequency: at least once a year. Contact DOSATRON, or a dealer to select the appropriate seal kit for your dosing pump. Dismantle the injection assembly in accordance with the instructions in the Removing/Refitting the injection assembly section, page ATTENTION! Do not use metal tools or utensils.
Page 46
Replace the dosing piston: • Using a 6 mm open-ended spanner, rotate the plunger piston a quarter turn and disengage it from the motor. • Insert the new plunger piston with its seal into the housing provided on the motor and lock it in place with a quarter turn using the 6 mm spanner. / 46...
Page 48
D9WL2 / D9WL5 Replace the suction valve: • Unscrew the suction valve locking nut. • Release the suction valve by pulling it through the middle of the injection assembly Replace the dosing pump body O-ring: • Completely unscrew the dosing locking nut •...
Precautions section, page NOTA: Before dismantling, and to avoid any contact with the injected additives, turn on the DOSATRON and allow it to draw in clear water in order to rinse the injection assembly. • Turn off the water supply and allow the pressure to drop to zero.
Page 51
D9WL2 / D9WL5 • Turn the dosing piston through a quarter turn anticlockwise to unlock it and release it from the piston motor. • Reassemble in the reverse order. fig 47 / 51...
Precautions section, page NOTA: Before dismantling, and to avoid any contact with the injected additives, turn on the DOSATRON and allow it to draw in clear water in order to rinse the injection assembly. If used in hard water, we recommend descaling the external injection assembly, at intervals to be confirmed on site.
Precautions section, page NOTA: Before dismantling, and to avoid any contact with the injected additives, turn on the DOSATRON and allow it to draw in clear water in order to rinse the injection assembly. • Turn off the water supply and allow the pressure to drop to zero.
Precautions section, page NOTA: Before dismantling, and to avoid any contact with the injected additives, turn on the DOSATRON and allow it to draw in clear water in order to rinse the injection assembly. • Turn off the water supply and allow the pressure to drop to zero.
Restart the motor piston seized. by hand. Presence of air in the Bleed air out of the DOSATRON. system. Your DOSATRON does not start, or it stops 1. Reduce flow, restart. working. Overflow. 2. Check that the motor valve seals are fitted.
Page 56
SYMPTOM CAUSE SOLUTION Dosing 1.Check the that the injection assembly nuts are correctly tightened. 2.Check the condition of Air tightness problem. the suction hose. 3.For IE (external injection) versions, check the condition of the injection hose. Suction valve seal worn Clean or replace it.
Page 57
SYMPTOM CAUSE SOLUTION Leaks Leaks near the fixing Damaged, incorrectly Correctly position or nut under the pump positioned or missing replace it. body. dosing body seal. Leaks between the Dosing pump body seal Correctly position or adjustment sleeve and damaged, incorrectly replace it.
Warranty DOSATRON INTERNATIONAL S.A.S. agrees to replace any part recognised as defective when new for a period of twelve months from the date of purchase by the initial purchaser. To obtain the replacement under the warranty, the device or spare part must be returned with proof of initial purchase to the manufacturer or authorized distributor.
Page 60
KNOW YOUR FLOW A SIMPLE METHOD THE DOSATRON IS COMPOSED OF: As it moves back and forth, the motor piston clicks: A volumetric piston hydraulic motor driving: a dosing piston 2 clicks = 1 motor Once in the up Once in the...
