- Page 1 FLOOR POLISHER MODELS: BDS 43/175 C-10090910 BDS 51/175 C-10090920 BDS 51/175-300 C-10090940 Operating Instructions (ENG) 86390940-A 12/09/13...
- Page 2 MACHINE DATA LOG/OVERVIEW Model: Date of Purchase: Serial Number: Sales Representative: Address: Phone Number: Warranty Registration Thank you for purchasing a Kärcher product. Warranty registration is quick and easy. Your registration will allow us to serve you better over the lifetime of the product. To register your product go to: www.karchercommercial.com/WarrantyRegistration.aspx For customer assistance:...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Machine Data Log......2 Table of Contents ......3 HOW TO USE THIS MANUAL How to use this Manual..... 1-1 SAFETY Important Safety Instructions .... 2-1 Hazard Intensity Level...... 2-3 Grounding Instructions 120V.... 2-5 Safety Label Location ....... -
Page 4: How To Use This Manual
HOW TO USE THIS MANUAL This manual contains the following sections: The OPERATIONS section is to familiarize the operator with the operation and function of the HOW TO USE THIS MANUAL machine. SAFETY OPERATIONS The MAINTENANCE section contains preventive MAINTENANCE maintenance to keep the machine and its PARTS LIST components in good working condition. -
Page 5: Safety
SAFETY IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precaution must always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE. To reduce the risk of fire, electric shock, or injury: Use only indoors. Do not use outdoors or expose to rain. Use only as described in this manual. - Page 6 CONSIGNES IMPORTANTES DE SÉCURITÉ Lors de l'utilisation d'un appareil électrique, il faut toujours observer des précautions élémentaires,qui comprennent parmi celles-ci : LISEZ BIEN L'ENSEMBLE DES CONSIGNES AVANT D'UTILISER CET APPAREIL. Pour réduire les risques d'incendie, d'électrocution ou de AVERTISSEMENT blessure : Utilisez-le exclusivement dans des endroits fermés.
-
Page 7: Hazard Intensity Level
SAFETY The following symbols are used throughout this guide as indicated in their descriptions: HAZARD INTENSITY LEVEL There are three levels of hazard intensity identified by signal words – WARNING and CAUTION and FOR SAFTEY. The level of hazard intensity is determined by the following definitions: WARNING –... - Page 8 DEGRÉS DE RISQUES EN CAS DE DANGER Les symboles ci-dessous sont utilisés à travers ce manuel comme illustré dans leurs descriptions : DEGRÉS DE RISQUES EN CAS DE DANGER Il existe trois degrés de risques identifiés par les termes signalétiques –AVERTISSEMENT et ATTENTION et POUR VOTRE SÉCURITÉ.
-
Page 9: Grounding Instructions 120V
SAFETY Grounding Pin GROUNDING INSTRUCTIONS 120V GROUNDING CONNECTION THIS PRODUCT IS FOR COMMERCIAL USING AN ADAPTOR USE ONLY. Grounded Outlet ELECTRICAL: Metal Screw FIGURE A In the USA this machine operates on a 15 amp nominal 120V, 60 hz, A.C. power circuit. The Adaptor amp, hertz, and voltage are listed on the data Tab for Grounding... -
Page 10: Safety Label Location
SAFETY SAFETY LABEL LOCATION NOTE: These drawings indicate the location of safety labels on the Machine. If, at any time, the labels become illegible contact your authorized representative for prompt replacement. EMPLACEMENT DE L'ÉTIQUETTE DE SÉCURITÉ REMARQUE : Ces dessins indiquent l'emplacement des étiquettes de sécurité sur la machine. - Page 11 NOTES: 86390940 FLOOR POLISHER BDS...
-
Page 12: Technical Specifications
CONSTRUCTION duty rubber bumper, tubular steel adjustable handle with die cast aluminum handle housing MOTOR 1.5HP 115V induction BDS 43/175 C, BDS 51/175 C 1.75 HP 115V 175/300RPM BDS 51/175-300C BRUSH/PAD SPEED 175 rpm BDS 43/175 C, BDS 51/175 C... -
Page 13: Handle Installation
HANDLE INSTALLATION WHEN INSTALLING THE HANDLE ASSEMBLY, CHECK ORIENTATION OF THE CORD ASM AND CORD HOOK. MOTOR PLUG RECEPTACLE MOTOR PLUG PIVOT DECK HOLE ASSEMBLY (SEE NOTE) The handle must be installed by qualified personnel. Read all instructions thoroughly. The machine is shipped with handle unassembled. La poignée doit être installée par du personnel qualifié. -
Page 14: Controls
OPERATION NOTE: It is incorrect to make it lock CONTROLS opposite from the way it was assembled by applying more force to the nut. 1. Safety Lock – Prevents unintended operation of the machine. The pivot pin is off center in relationship to the axis of the handle. -
Page 15: Machine Operation
OPERATION MACHINE OPERATION NOTE: The machine is equipped with a circuit breaker to protect the motor in the event an overload condition occurs. The circuit breaker is located on the handle. Push the reset button to restart the machine. If the breaker trips For indoor use only. - Page 16 NOTES: 86390940 FLOOR POLISHER BDS...
-
Page 17: Maintenance
MAINTENANCE SCRUB BRUSHES FINISHED FLOORS NOTE: All original equipment brushes are Nylon Polish is the softest brush. It will gently equipped with “Perform Alert”. This feature will clean finished tile or terrazzo floors without tell the operator when it is time to replace the removing floor finish or floor material. -
Page 18: Machine Troubleshooting
MACHINE TROUBLESHOOTING PROBLEM CAUSE SOLUTION Machine will not run Circuit breaker tripped in Check and reset. building. Power switch failure Test switch for continuity and replace if necessary. Tripped circuit breaker Reset. Faulty power cord Replace. Fuse in motor blown Replace (Dual speed only) CAUTION: To reduce the risk... - Page 19 PARTS 5- 0 86390940 FLOOR POLISHER BDS...
-
Page 20: Brush/Pad Driver Group
BRUSH/PAD DRIVER 1 1 A-1C 2A-2J 86390940 FLOOR POLISHER BDS... - Page 21 BRUSH/PAD DRIVER SERIAL NO. PART NO. PRV NO. DESCRIPTION NOTES: FROM 86000120 02218 PAD DRIVER, 17" POLISHER 86284290 02217 PAD DRIVER, 19” HS 86284300 02219 PAD DRIVER, 20" POLISHER 86000140 02242 BRUSH, 17" NYL. POL. W/CLT.PLT BRUSH, 17" NYL.SCRUB 86283800 02240 W/CLT.PLT 86000130...
- Page 22 ELECTRICAL 86390940 FLOOR POLISHER BDS...
- Page 23 ELECTRICAL SERIAL NO. REF PART NO. PRV NO. QTY DESCRIPTION NOTES FROM 86002010 14942 BOOT, 3/8 CIRCUIT BREAKER 86198450 20005 CLAMP, 5/16 NYLON 86369090 CORD SET, ST, 14/50', YLW 86216920 23206 CORDSET, 14/3 X 52 IN, SJT, BLK 86288450 70689 SCR, M4.8 X 10 HHTF TYPE B 86136780 70801...
-
Page 24: Deck
DECK 9A-9D 2A-2B 86390940 FLOOR POLISHER BDS... - Page 25 REF PART NO. PRV NO. QTY DESCRIPTION NOTES FROM 86214930 03111 AXLE, MAIN POLISHER 2A 86216340 14372 BUMPER, EXTRUSION 41.0" BDS 43/175 C BDS 51/175 C, 2B 86216350 14373 BUMPER, EXTRUSION 50.8" BDS 51/175-300 C 86216600 27871 CAP, EXTRUSION 86221860...
-
Page 26: Handle
HANDLE 86390940 FLOOR POLISHER BDS... - Page 27 HANDLE SERIAL NO. REF PART NO. PRV NO. QTY DESCRIPTION NOTES FROM 86215130 14344 BAR, HANDLE ADJUST 86366010 BUMPER, FLOOR MACHINE 86004070 36196 GRIP, POLISHER HANDLE 86218440 38290 HANDLE, POLISHER 86005150 51326 LOCK, SAFETY HANDLE 86005160 51327 LEVER, SWITCH 86136350 57274 NUT, M6 HEX FINISH 86136360...
-
Page 28: Motor
MOTOR DUAL SPEED ONLY 86390940 FLOOR POLISHER BDS... - Page 29 MOTOR SERIAL NO. REF PART NO. PRV NO. QTY DESCRIPTION NOTES FROM BDS 43/175 C, 86378300 MOTOR, ASM, 1.5 HP 120VAC BDS 51/175 C BDS 43/175 C, 86217490 27884 COVER, MOTOR BDS 51/175 C 86223690 70702 SCR, M5 X .8 X 15MM BLK...
-
Page 30: Wiring-120V
WIRING-120V CORD SET -CB1 120V AC 15A -SWITCH -SWITCH -MOTOR SERIAL NO. PART NO. PRV NO. DESCRIPTION NOTES: FROM WIRE, 125MM, BLK/14, 86311830 76029X76029 86390940 FLOOR POLISHER BDS 5-11... -
Page 31: Suggested Spare Parts
COUPLING, MTR/GEAR BOX 86135540 27352 BDS 51/175-300 C PLSHER 86223390 67488 RECTIFIER, 50A 600V BRIDGE BDS 51/175-300 C 86312460 BREAKER, 14A, VDE CIRCUIT BDS 51/175-300 C BDS 43/175 C 86377960 COUPLING, SHEAR BDS 51/175 C 5-12 86390940 FLOOR POLISHER BDS...
