SIGNAL CABLE DESCRIPTION (CONTINUED)
Mini Din Pin
Assignment
Function of the Audio
Cam A
Cam B
Cam C
Cam R
Cam A + Cam B
Cam C+ Cam R
Cam A+ Cam R
Cam R+ Cam B
Cam A + Cam C
Cam C+ Cam B
Cam R / Cam AB
Quad
AV
1. Cam Out: Composite video loop out signal to recorder, monitor or other device.
2. Live Video/Audio Out: On screen video/audio signal loop out to recorder, monitor or other device.
Issued October 2018
Signal Cable Description
USER MANUAL
* Type 1 (Standard):
1. Video
2. -------
3. Audio
4. +12V
5. GND
6. -------
AWT07MLEDT
Audio from Cam A
Audio from Cam B
Audio from Cam C
Audio from Cam R
Audio from Cam A
Audio from Cam R
Audio from Cam R
Audio from Cam R
Audio from Cam A
Audio from Cam C
Audio from Cam R
Audio from Cam R
Audio from AV
