Vulcan-Hart LG400 Specifications

LG400 Shown
SPECIFICATIONS:
45 - 50 lb. capacity free standing model gas fryer, Vulcan-Hart
Model No. LG400. Stainless steel front and door. Set of four
6" nickel plated steel legs adjustable to 7". Stainless steel fry
tank with four heat exchanger tubes and a "V" shaped large
cold zone. 1 1 / " full port ball type drain valve. Twin fry
4
baskets with plastic coated handles. 120,000 BTU/hr. input.
Behind the door snap action millivolt thermostat control
adjusts from 200° to 400°F.
Overall dimensions: 15 / "w x 30
1
2
CSA design certified. NSF listed.
SPECIFY TYPE OF GAS WHEN ORDERING.
Natural Gas
Propane Gas
SPECIFY ALTITUDE:
Natural Gas for above 2000 ft
Propane Gas for above 3500 ft.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32928 (4-08)
/ "d x 36 / "h.
1 1
4 4
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
LG400
FREE STANDING ECONOMY GAS FRYER
STANDARD FEATURES
Stainless steel fry tank, 45 - 50 lb. capacity.
Large cold zone area.
1 / " full port ball type drain valve.
1
4
Stainless steel front and door.
G90 high grade galvanized non corrosive finish sides and
back.
Door liner for added stability.
Set of four nickel plated legs adjustable to 7".
Twin fry baskets with plastic coated handles.
120,000 BTU/hr. input.
Behind the door snap action millivolt thermostat control ad-
justs from 200° to 400°F with standing pilot.
Millivolt System - Requires no electric hook-up.
Hi-limit shut-off protector shuts off gas combination valve and
standing pilot.
Built in flue deflector.
Nickel plated tube rack.
Earth magnet to secure closed door.
Easily removable stainless steel basket hanger for cleaning.
Vulcan-Hart (Vulcan) warrants the LG400 Gas Fryer to be
free of defects in materials and workmanship for a period of
1 year from the date of original installation.
Stainless steel fry tank will be warranted for 1 year. If tank is
found to have a leak and is verified by an authorized service
agency, the entire LG400 fryer will be replaced. Replace-
ment fryer will be warranted for the balance of the original
warranty.
ACCESSORIES
Casters 6" adjustable to 7", 2 locking, 2 non-locking
Stainless steel tank cover.
Grease protector strips.
Single large basket - 13"w x 13
Set of twin baskets - 6
Set of tri baskets - 4 /
1
4
FRYMATE - VX15 add-on Frymate™ Dump Station.
Flexible gas hose with quick disconnect.
C.S.I. Section 11420
1 / "d x 5 1 / "h.
4 2
/ "w x 13 / "d x 6"h.
1 1
2 4
"w x 13 / "d x 5 / "h
1 1
4 2
