- Page 1 TM Series 15.6” Wide LCD Touchscreen Monitor Model “G” Model “H” Instruction Manual Model: TMG-156FH01-01 TMH-156FH01-01 DMC Co. Ltd. https://www.dush.co.jp/english/ TM Series Instruction Manual 23A4A4-00006E-2...
- Page 2 Please note, specifications described in this manual are subject to change without prior notice. Copyrights and Trademarks ■ The copyright of this instruction manual is rightfully owned by DMC Co., Ltd. ■ Reproduction and/or duplication of the product and/or this manual, in any form is strictly prohibited.
- Page 3 Warnings Warnings for Design Designing switches that might cause human injuries and/or property damage on the touchscreen is strictly prohibited. Unintended output signals due to malfunction of the main unit and/or cables can lead to serious injuries. Design the system so that switches that perform critical operations are equipped on devices other than the TM itself.
- Page 4 Cautions Cautions for Disposal When disposing the product, please treat it as industrial waste. Precautions for Safe Use Do not press the display with strong pressure or hard objects. It may break the display and cause injuries. Please use this product within the specified ambient temperature and humidity range. If not used properly within the specified range, it may cause malfunctions.
- Page 5 Handling of Projected Capacitive Touchscreens (TMG) 1) Changes in the surrounding environment and/or elements that change the electric field, such as capacitors with large capacitance, power supply units, metals, and other materials with high dielectric constants are near, it may affect the coordinate detection. Keep as much distance as possible from those unstable elements mentioned above when designing.
-
Page 6: Table Of Contents
Table of Contents Features ........................1 Features ............................2 Line-Up ............................3 Product Configuration ..................... 4 Names and Functions of Each Parts ....................5 Options............................. 6 Installing the TM ..........................8 Wiring ............................. 10 OSD.......................... 14 OSD Menu (Factory Default Setting) ..................... 15 Touch Screen Properties .................. -
Page 7: Features
Features Features Chapter Contents Features ....................2 Line-Up ...................... 3 TM Series Instruction Manual... -
Page 8: Features
Features Features ■ Front surface a full flat design. ■ Slim type chassis. ■ Supports HDMI video signal as a series. ■ USB3.0 Upstream Port with shock-resistant “Standard Type B” connector. ■ A lineup of projected capacitive touchscreens: TMG Series -Supports five-point touch ■... -
Page 9: Line-Up
Features Line-Up Specification Model LCD size Touchscreen type Video Input USB (Host I/F) USB3.0 Type-B 15.6 inch TMG-156FH01-01 Projected capacitive HDMI (USB2.0 Type-B wide connectable) USB3.0 Type-B 15.6 inch TMH-156FH01-01 Analog resistive※ HDMI (USB2.0 Type-B wide connectable) ※ Analog resistive touchscreen used in TM supports gesture operations such as flick, pinch in, pinch out, and rotate. -
Page 10: Product Configuration
Product Configuration Product Configuration Chapter Contents Names and Functions of Each Parts ............5 Options ...................... 6 Installing the TM ..................8 Wiring ...................... 10 TM Series Instruction Manual... -
Page 11: Names And Functions Of Each Parts
Product Configuration Names and Functions of Each Parts TMG-156FH01-01，TMH-156FH01-01 ⑤ ④ ① ③ ② Part Name Function USB3.0 Standard Type-B Connector USB Host I/F ① (USB2.0 Type-B connectable) Power Input Input power. (12VDC) ② Image Input (Digital) HDMI connector ③ FG Terminal Connects to Field GND. -
Page 12: Options
Product Configuration Options “AC adaptor (with/without screw-lock)”, “Self-standing stand” are available as option. 2.2.1 AC Adaptor (with screw lock) Model: ATS065T-P120B15210 (customized model) Manufacturer: Toki Trading Ltd. ・AC Adaptor 1 unit ・AC cord 1pc <Note> Warranty coverage: Coverage within the AC adaptor manufacturer’s warranty. Make sure the power cord provided conforms to the standards specified for the country or region in which it will be used. - Page 13 Product Configuration 2.2.3 Self-Standing Stand Model: SWST-01-001 Items included 2.2.3.1. ・Stand (arm) 1unit ・Stand (base) 1 unit 1pc screw for assembly included. ・VESA mounting screw 4pcs ・List of included items 1copy Assembly Instruction 2.2.3.2. 1) Remove the screw attached to the arm. 2) Put together the arm and the base.
-
Page 14: Installing The Tm
Product Configuration Installing the TM 2.3.1 Installing Conditions (Precautions) • To install the TM, use the M4 screw holes (VESA Standard 100mmx 100mm) provided in the VESA box. • When installing using a commercially available arm or stand, be sure to select one that can withstand the weight of the TM. - Page 15 Product Configuration 2.3.3 Installing “VESA Standard” Arm The TM can be installed to a commercially available arm and/or stand. Parts to be used for installation shall meet the UL1678 standards. Please refer to the manual of the arm for installation procedures. Installing hole dimensions are as follows (VESA Standard 100mm x 100mm) Use M4 screws with tightening torque of 0.7 to 0.8N-m Please select the M4 screws so the penetration depth of the screw is 8mm or less from the...
-
Page 16: Wiring
Product Configuration Wiring Be sure no power is supplied when wiring and connecting to avoid the risk of electrical shocks. Do not turn the power on until all connections have been made. Prepare the cables to be used according to the specifications. 2.4.1 Wiring of Power Supply ■Compliant DC plug specifications... - Page 17 Product Configuration 2.4.2 Wiring Procedure (1) You will need a “USB Cable” and a “Video Interface Cable” in order to connect to a computer. (2) Make sure that the TM and the computer to which it is connected are not powered. (3) Connect the TM and the computer as show in in below diagram.
- Page 18 Product Configuration 2.4.3 Rotating the VESA Box The VESA box at shipment from the factory is oriented so the image interface is in the longitudinal direction. Video interface can be rotated and changed by the customer. ■Rotating the VESA Box (1) Turn off the power of the main unit and disconnect any peripheral devices connected to the (2) Place the main unit on a flat and stable surface, such as a desk, with the display side facing down.
- Page 19 Product Configuration Rotate the box 90 degrees clockwise so that the position marks on the body side and the position marks on the box side are aligned. Box side Position mark Unit side Position mark [Caution] Rotating more than 90 degrees may cause disconnections or damages. Attempting to forcibly remove the VESA box may break or damage the wires.
-
Page 20: Osd
OSD (On Screen Display) should be used with default factory setting. OSD cannot be changed by the customer. Chapter Contents OSD Menu (Factory Default Setting) ............15 TM Series Instruction Manual... -
Page 21: Osd Menu (Factory Default Setting)
OSD Menu (Factory Default Setting) Menu Adjustment Factory Default Contents range Setting Brightness Screen brightness adjustment 0 ～ 100 Contrast 0 ～ 100 Screen contrast adjustment Sharpness Screen sharpness adjustment 0 ～ 4 Gamma Gamma value adjustment 5800K 6500K 7500K Color temperature adjustment Color Temp 6500K... -
Page 22: Touch Screen Properties
Touch Screen Properties Touch Screen Properties Please download the “Touchscreen Driver (DMT-DD) “from the following URL https://www.dush.co.jp/english/download/driver-app/ Chapter Contents System Requirements ................17 Installation ....................18 Setting ..................... 22 Calibration ....................27 * “Touchscreen Driver (DMT-DD)” V2.14 or later version is recommended. * Please refer to the documents included in the “DMT-DD”... -
Page 23: System Requirements
Touch Screen Properties System Requirements 4.1.1 System Configuration Supported OS: Microsoft® Windows® 10/11 (32bit/64bit) Home Edition or higher. 4.1.2 Installation Requirements Software Microsoft® .Net Framework 4.6 must be installed. Hardware Requires about 10MB of free space in the system drive and data file storage space. Installation location is as follows For 32bit: System Drive¥Program Files¥DMT-DD For 64bit: System Drive¥Program Files (x86) ¥DMT-DD... -
Page 24: Installation
Touch Screen Properties Installation 4.2.1 Installing “Touchscreen Setting Tool (DMT-DD)” (1) Decompress the driver zip file downloaded to your computer. *Do not connect TM to a computer via USB before installation. (2) Double-click "DMT-DDSetup.msi" or "DMT-DDSetup_ms.msi" inside the folder. (3) The setup wizard will start. Click [Next] to begin the installation. (4) Review the license terms and select "I agree,"... - Page 25 Touch Screen Properties (5) Click [Next] at “Confirm installation”. (6) The following dialog may appear multiple times during installation. Click [Install] (7) Click [Close] to complete the installation. TM Series Instruction Manual...
- Page 26 Touch Screen Properties 4.2.2 Installing the Touchscreen Driver (1) Connect TM and the computer with an USB cable. The driver will be installed automatically when the USB cable is connected with the DMT- DD installed. Start the “Touchscreen Driver” from the [DMT-DD] shortcut on the desktop. - The setting tool requires administrator privilege to install drivers and etc.
- Page 27 Touch Screen Properties (5) The below dialog will appear at initial installation. Click [Install]. (6) The below window will appear. Click [OK] and restart your computer. (7) After restarting your computer, start “DMT-DD”. If the [USB Port] is changed to [TP Driver], the driver installation is complete. TM Series Instruction Manual...
-
Page 28: Setting
Touch Screen Properties Setting 4.3.1 Monitor Setting The below must be performed when using in a dual-display environment. (1) Click [Monitor Setting] and open the below screen. (2) Click [Refresh Monitor] and refresh the connected monitor. (The number of icons displayed will change depending on the number of monitors connected.) (3) Click [Monitor Configuration] and a dialog, “Confirm keyboard connection”... - Page 29 Touch Screen Properties (7) Press [Enter] after confirming the driver in red underline had appeared as shown above. If there are multiple monitors, screen displayed in (4) will be appear (8) Enter [Enter] on the last monitor and the setup is complete. If you wish to cancel during the process, press the “ESC”...
- Page 30 Touch Screen Properties 4.3.2 Touch Setting The below screen will be displayed only when OS later than Windows7 is used. (1) Click [Touch Setting] and open the following window. (2) Click [Open] of [Tablet PC Setting] to open Windows standard setting. (3) Click [Setup] under [Configuration] and the following screen will appear.
- Page 31 Touch Screen Properties 4.3.3 Touch Format Touch data mode can be set for the driver selected in the combo box. (1) Click [Standard setting] and select the [Touch Input Setting] tab. (2) Set the [Touch Data Mode] of [Touch Format] as below. -Serial Mode: Outputs touch data in serial format -Hybrid Mode: Outputs touch data in parallel format Select Hybrid Mode.
- Page 32 Touch Screen Properties 4.3.5 Multi-Touch Setting When using multi-touch, set “Touch Output” by the following procedure. (1) Start [Touchscreen Properties] (2) Open [Configuration file] via [Basic Settings] (3) Select [Touch.mfd] and click [Register] 4.3.6 Rotating Touch Coordinates The XY coordinates output by touch operation can be rotated 0, 90, 180 and 270 degrees. TM Series Instruction Manual...
-
Page 33: Calibration
Touch Screen Properties Calibration The touchscreen operation may become unstable depending on the installation environment due to the characteristics of the touchscreen. In order for the touchscreen to be used correctly, please perform calibration after installation. 4.4.1 Projected Capacitive Touchscreen ［TP Offset］-Sensitivity calibration (1) Start [DMT-DD] (2) Open [Touch screen Maintenance] via [Basic Setting] >... - Page 34 Touch Screen Properties 4.4.2 Resisitive Touch Screen ［4 Point Correction］or [9 Point Correction]- Coordinate Calibration (1) Start [DMT-DD]. (2) Choose the [Software Setting] via [Basic Setting]. (3) Click and place a check in the box next to [Use EEPROM] under [EEPROM] and click [Entry].
- Page 35 Touch Screen Properties 4.4.3 Gesture Correction (DO NOT PERFORM) When gesture operation is not responding smoothly, it may improve with [Gesture Correction]. [Gesture Correction] is performed at factory shipment and does not need to be performed. If [Gesture Correction] is performed, touch operation may not operate normally. TM Series Instruction Manual...
-
Page 36: Maintenance
Maintenance Maintenance Chapter Contents Maintenance .................... 31 TM Series Instruction Manual... -
Page 37: Maintenance
Maintenance Maintenance 5.1.1 Caring for Display If the display surface or the frame becomes dirty, wipe with a soft cloth soaked in mild neutral detergent and wrung tightly. Use of thinner, organic solvents, and strong acidic detergents are prohibited. 5.1.2 Periodic Check To keep the product in its best condition, please check periodically. -
Page 38: Troubleshooting
Troubleshooting Troubleshooting If symptoms persist after taking corrective actions, consult your distributor or contact us (refer to ”7.3 Inquires“). Chapter Contents Display Display ..................33 Touchscreen .................... 34 TM Series Instruction Manual... -
Page 39: Display
Troubleshooting Display Symptoms Causes/ Measures ・Screen not displayed ・Make sure the power cord is inserted securely. ・Make sure the image signal cable is connected properly. ・Make sure the power of the computer is on. ・Check and see if the computer image output is correct. ・Afterimages appear ・Afterimages can be seen if the same image is displayed for a long period of time. -
Page 40: Touchscreens
Troubleshooting Touchscreens Symptom Causes and Measures ・Cursor position is not correct ・Unplug and plug the USB cable connected to the computer. ・Cursor jumps ・Make sure the FG (Frame GND) of the TM and the FG (Field GND) of the power supply are connected. ・Place a check in the checkbox of EEPROM. -
Page 41: Others
Others Others Chapter Contents Warranty and Repair ................36 Production Discontinuance ..............37 Inquiries ....................38 TM Series Instruction Manual... -
Page 42: Warranty And Repair
7.1.3 Repair Inquiries If you need have any questions regarding repairs for DMC products, please contact us and we will be glad to help. When doing so, please confirm the issue or the symptom beforehand. Also, when shipping us... -
Page 43: Production Discontinuance
Others Production Discontinuance In the event of production discontinuance, an announcement will be made six months prior to the last possible order reception date. TM Series Instruction Manual... -
Page 44: Inquiries
URL: https: //www.dush.co.jp/english/ This product and document are protected by the copyright law. Photocopying, duplicating, reproducing, and modifying of this product or document in part or by whole is prohibited. Copyright(C) 2023 DMC Co., Ltd. All Rights Reserved TM Series Instruction Manual...
