TABLE OF CONTENTS Warranty Water Filter ..........24-25 ................Product Record Care and Cleaning ........26-27 ..............Important Safety Instructions Connecting the Water Line ..... 28-30 ......Troubleshooting Guide....... 31-35 Electrical & Grounding Requirements ....Parts and Features Diagnostics ............36 ............
*Warranty coverage applies to door bins, drawer bins and basket bins. Defects must be vHULoed by a Sears authorized service representative. For warranty coverage details to obtain free repair or replacement, visit the web page: www.kenmore.com/warranty All warranty coverage applies for only 90 DAYS from the sale date if this appliance is ever used for other than private household purposes.
PRODUCT RECORD items of information available whenever you contact Sears concerning your product. Model No.___________________ Date of Purchase ___________________ Serial No.___________________ Save these instructions and attach your sales receipt for future reference. IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Safety Messages Your safety and the safety of others are very important.
Page 5
Keep packing materials out of the reach of children. Packaging material can be dangerous for children. appliance into a damaged wall outlet. Do not put hands, feet or other objects into the air Do not install the refrigerator in a damp or dusty vents or bottom of the refrigerator.
Page 6
WARNING Unplug the power plug immediately in the event of a gasoline, away from the refrigerator. blackout or thunderstorm. This appliance is not intended for use by persons (including children) with reduced physical, sensory refrigerator. Call a service agent. or mental capabilities, or lack of experience and Do not store glass containers or soda in the freezer knowledge, unless they have been given supervision compartment.
ELECTRICAL & GROUNDING REQUIREMENTS TO CONNECT ELECTRICITY USE OF EXTENSION CORDS WARNING: Do not use extension cords or ungrounded WARNING (two-prong) adaptors. Because of potential safety hazards under certain conditions, the use of an extension Electrical Shock Hazard cord is not recommended. However, if you still elect to use an extension cord, it is absolutely necessary that it FOR PERSONAL SAFETY, this appliance must be be a UL-listed (USA), 3-wire grounding type appliance...
PARTS AND FEATURES Diagnostics Use this page to become more familiar with the parts and features of your refrigerator. NOTE: 7KLV JXLGH FRYHUV VHYHUDO GLçHUHQW PRGHOV 7KH UHIULgerator you have purchased may have some or all of the items listed below. The locations of the features shown below may not match your model. Custom Cube Icemaker* Shelves Ice Bin...
REFRIGERATOR INSTALLATION WARNING WARNING Excessive Weight Hazard: Excessive Weight Hazard: Your refrigerator is heavy. When moving the Use two or more people to move and install the refrigerator for cleaning or service, be sure to protect refrigerator. Failure to do so can result in back or Always pull the refrigerator straight out when other injury.
REFRIGERATOR INSTALLATION PRIOR TO USE INSTALLATION The refrigerator should always be plugged into its own 1. Clean your refrigerator thoroughly and wipe individual properly grounded electrical outlet rated for dust that accumulated during shipping. 115 Volts, 60 Hz, AC only, and fused at 15 or 20 amperes. This provides the best performance and also prevents 2.
REFRIGERATOR INSTALLATION REMOVING AND REPLACING THE DOORS WARNING WARNING Electrical Shock Hazard Disconnect the electrical supply to the refrigerator Excessive Weight Hazard: before installing. Failure to do so could result in serious Use two or more people to remove and install the injury or death.
Page 12
REFRIGERATOR INSTALLATION REPLACING THE REFRIGERATOR DOOR REPLACING THE FREEZER DOOR 1. Set the freezer door onto the middle hinge pin. 1. Lower the door onto the bottom hinge pin. Place the hinge pin of the middle hinge bracket inside of the hinge pin insert on top of the door. Hold the door in place and align the middle hinge bracket with the holes in the refrigerator housing.
REFRIGERATOR INSTALLATION REVERSING THE DOORS 3. Loosen the handle mounting fastener with a ¼” hex WARNING wrench. ELECTRICAL SHOCK HAZARD Before you begin, either unplug the refrigerator or turn Rç Fastener power at the circuit breaker or fuse box. Failure to do so could result in death or serious injury.
Page 14
REFRIGERATOR INSTALLATION 7. Using 10mm or 13 / 32 inch socket wrench, remove the WKUHH EROWV DQG OLIW Rç WKH WRp hinge. Set parts aside. Top Hinge 3U\ Rç WKH FRYHU RQ WKH WRS OHIW VLGH RI WKH UHIULJHUDWRU to uncover the screw holes.
Page 15
REFRIGERATOR INSTALLATION 3. Loosen the handle mounting fastener with a ¼” hex wrench. Fastener 4. Unscrew the plug button with y RXU oQJHUV by rotating it 7. Loosen and remove the two bolts and use the phillips head counterclockwise; it will loosen and fall free. screwdriver to remove the middle hinge bracket from the refrigerator housing.
Page 16
REFRIGERATOR INSTALLATION 9. Using a 13 / 32 ’’ socket wrench with a 2-Inch extension 13 . Reverse the Door Closer/Stop by flipping it over. Place and a screwdriver, loosen the two bolts and one screw, the hinge pin bracket, and the hinge pin insert keeping and remove the bottom hinge from the right side of the same orientation on the opposite door side, then the housing.
Page 17
REFRIGERATOR INSTALLATION REFRIGERATOR INSTALLATION 17. Insert the decorative screw into the outer hole on the 5. Rotate the handles. The freezer handle will move to the right side of the housing. Attach the cover on the right refrigerator door, and the refrigerator handle will move to freezer door.
REFRIGERATOR INSTALLATION LEVELING 8. Install the refrigerator handle by ajusting the handle the set screws with a 3/32” hex wrench. door closing. Your refrigerator has two front leveling screws - one on Screw Wrench adjust the refrigerator’s tilt using the instructions below: 1.
USING YOUR REFRIGERATOR FOOD STORAGE GUIDE STORING FROZEN FOOD Wrap or store food in the refrigerator in airtight and NOTE: Check a freezer guide or a reliable cookbook moisture-proof material unless otherwise noted. This for further information about preparing food for prevents food odor and taste transfer throughout the freezing or food storage times.
USING YOUR REFRIGERATOR WATER DISPENSER (On some models) WARNING To dispense cold water, push on the dispenser switch with a glass. Personal Injury Hazard DO NOT place or hands on the automatic ice making mechanism while the refrigerator is plugged in. Dispenser Switch Icemaker...
USING YOUR REFRIGERATOR REFRIGERATOR SHELVES PANTRY DRAWER (on some models) The glass shelves in your refrigerator are adjustable to To Remove the Pantry Drawer: meet your individual storage needs. Remove the door bins before removing or replacing the Adjusting the shelves to ot items of diçHUHQt heights will pantry drawer make the exact item you want easier.
USING YOUR REFRIGERATOR HUMIDITY CONTROLLED CRISPERS Removing the Crisper Cover 1. Remove both crisper drawers. The crispers provide fresher tasting fruit and vegetables by letting you easily control humidity inside the drawer. 2. Remove the crisper glass. You can control the amount of humidity in the moisture- 3.
NOTE: To purchase a replacement oOWHr, visit your local If the is removed and not replaced, it is necessary to Sears store, or call 1-844-553-6667. reinstall the substitute cap to prevent water leaks from the You may also purchase online at www.kenmore.com housing.
Page 25
Product distributed in the United States by Transform SR Brands Management LLC, Hoffman Estates, IL 60179 U.S.A.
CARE AND CLEANING INSIDE WALLS (allow freezer to warm up so WARNING the cloth will not stick) To help remove odors, you can wash the inside of the refrigerator with a mixture of baking soda and warm water. Mix 2 tablespoons of baking soda to 1 quart of ZDWHU J VRGD WR OLWHU ZDWHU %H VXUH WKH EDNLQJ VRGD is completely dissolved so it does not scratch the surfaces of the refrigerator.
Page 27
CARE AND CLEANING POWER INTERRUPTIONS WHEN YOU MOVE When you are moving your refrigerator to a new home, 1. If the power will be out for 24 hours or less, keep all follow these steps to prepare it for the move. refrigerator doors closed to help foods stay cold and frozen.
CONNECTING THE WATER LINE BEFORE YOU BEGIN WHAT YOU WILL NEED v Copper Tubing, ¼ in. outer This water line installation is not covered by the refrigerator diameter, to connect the refrigerator warranty. Follow these instructions carefully to minimize the to the water supply.
Page 29
CONNECTING THE WATER LINE INSTALLATION INSTRUCTIONS NOTE: Commonwealth of Massachusetts Plumbing Codes 248CMR shall be adhered to. Saddle valves are illegal and their use is not permitted in Massachusetts. WARNING Consult with your licensed plumber. Electrical Shock Hazard 5. TIGHTEN THE PIPE CLAMP When using any electrical device (such as a power Tighten the clamp screws until the sealing washer drill) during installation, be sure the device is battery...
Page 30
CONNECTING THE WATER LINE 8. FLUSH OUT THE TUBING 10. TURN THE WATER ON AT THE SHUTOFF VALVE Tighten any connections that leak. Turn the main water supply on and out the tubing until the water is clear. 6KXW WKH ZDWHU Rç at the water valve after about one quart of water has been through the...
TROUBLESHOOTING GUIDE UNDERSTANDING SOUNDS YOU MAY HEAR Your new refrigerator may make sounds that your old one did not make. Most of the new sounds are normal. Hard surfaces, like the walls and cabinets, can make the sounds seem louder than they actually are. The following describes the kinds of sounds you may hear and what may be causing them.
Page 32
TROUBLESHOOTING GUIDE Problem Possible Causes Solutions Lights do not work. The power supply cord is unplugged. Firmly plug the cord into a live outlet with proper voltage (refer to Electrical & Grounding Requirements). An LED light has malfunctioned. Before proceeding to replace LED, unplug the refrigerator or turn power at the circuit breaker or fuse box.
Page 33
TROUBLESHOOTING GUIDE Problem Possible Causes Solutions Doors will not close The refrigerator is not level. See the Leveling and Door Alignment section. completely. Food packages are blocking the door open. Rearrange food containers to clear door and door shelves. The ice bin, crisper cover, pans, shelves, door Push bins all the way in and put crisper cover, bins or baskets are out of position.
Page 34
TROUBLESHOOTING GUIDE Problem Possible Causes Solutions Refer to the Understanding Sounds You May The refrigerator The sounds may be normal for your Hear section for more information. seems to make too refrigerator. much noise. The icemaker is not New installation. Wait 12 to 24 hours after icemaker producing ice or not installation for ice production to begin.
Page 35
TROUBLESHOOTING GUIDE Problem Possible Causes Solutions Temperature is too The air vents are blocked. Cold air circulates Locate air vents by using your hand to sense warm or there is from the freezer to the fresh food section and move all packages that block interior moisture and back again through air vents in the wall vents and restrict...
PARTS AND FEATURES DIAGNOSTICS ™ Diagnostics (on some models) Should you experience any problems with your refrigerator, it has the capability of transmitting data via your telephone to the Diagnostics team . This gives you the capability of speaking directly to our trained specialists. The specialist records the data transmitted from the machine and uses it to analyze the issue, providing a fast, effective diagnosis.
Page 37
ÍNDICE Garantía Filtro de agua ..........59-60 ............Registro del Producto ........Cuidado y limpieza ........61-62 Instrucciones importantes sobre Conexión de la tubería de agua .... 63-65 seguridad ........... 40-42 Guía para la solución de problemas ..66-70 Requisitos eléctricos y de conexión a Diagnostics ............71 tierra ..............
4. Daño o falla de este electrodoméstico causado por la instalación no realizada por agentes de servicio autorizado de Sears, que incluye el hecho de que la instalación no se haya realizado según los códigos eléctricos, de gas o de plomería .
En el espacio siguiente, anote la fecha de la compra, el modelo y el número de serie del producto. Encontrará el modelo refrigerador. Tenga esta información a mano siempre que se ponga en contacto con Sears en relación con su producto.
Page 40
Mantenga los materiales de empaque fuera del alcance de los niños. Los materiales de empaque pueden ser peligrosos para los niños. Corren riesgo de enchufe el electrodoméstico en un tomacorriente de pared dañado. No instale el electrodoméstico en un lugar húmedo No coloque las manos, los pies u otros objetos o polvoriento, donde el aislamiento de las piezas en la ventilación de aire ni en la parte inferior...
Page 41
ADVERTENCIA MANTENIMIENTO Desenchufe el cable de alimentación antes de limpiar o reparar el electrodoméstico. No use secadoras eléctricas para secar el interior del producto. Las luces del refrigerador y el compartimento del congelador son luces LED para interiores, y un técnico No prenda velas para remover el olor interno del producto.
REQUISITOS ELÉCTRICOS Y DE CONEXIÓN A TIERRA PARA CONECTAR LA ELECTRICIDAD USO DE CABLES ALARGADORES ADVERTENCIA: No use cables alargadores o ADVERTENCIA adaptadores sin conexión a tierra (de dos clavijas). Debido a los posibles peligros de seguridad que se pueden Riesgo de descargas eléctricas producir bajo ciertas condiciones, no se recomienda el uso de un cable alargador.
COMPONENTES Y CARACTERÍSTICAS Diagnostics Use esta página para familiarizarse con los componentes y características del refrigerador. NOTA: Esta guía cubre varios modelos distintos. El refrigerador que ha adquirido puede tener algunos o todos los componentes que se enumeran a continuación. Es posible que las ubicaciones de las características que se indican no coincidan con su modelo. Estantes Fábrica de Hielo Automática * Cajón Pantry...
INSTALACIÓN DEL REFRIGERADOR ADVERTENCIA ADVERTENCIA Riesgo de peso excesivo: Riesgo de peso excesivo: Su refrigerador es muy pesado. Al desplazarlo para su El desplazamiento e instalación del refrigerador deben limpieza o mantenimiento, asegúrese de proteger el suelo. realizarse entre dos o más personas. Si no se respeta esta Siempre debe tirar del refrigerador en línea recta cuando advertencia, se podrán producir lesiones en la espalda o los desplace.
INSTALACIÓN DEL REFRIGERADOR ANTES DE USAR INSTALACIÓN 1. Limpie el refrigerador a fondo y quite todo el El refrigerador debe estar siempre enchufado a su toma polvo acumulado durante el transporte. de corriente individual conectada a tierra adecuadamente con una tensión nominal de 115 voltios, 60 Hz, sólo CA, 2.
INSTALACIÓN DEL REFRIGERADOR REMOVIENDO Y REEMPLAZANDO PUERTAS ADVERTENCIA ADVERTENCIA Riesgo de descargas eléctricas v Desenchufe el suministro eléctrico al refrigerador Riesgo de peso excesivo: antes de realizar la instalación. Si no se respeta esta advertencia, pueden producirse lesiones graves e El desplazamiento e instalación de las puertas del incluso la muerte.
Page 47
INSTALACIÓN DEL REFRIGERADOR VOLVER A COLOCAR LA PUERTA DEL REFRIGERADOR VOLVER A COLOCAR LA PUERTA DEL CONGELADOR 1. Coloque la puerta en el Pivote de la Bisagra Inferior. 1. Coloque la puerta del congelador en el pivote de la bisagra central.
INSTALACIÓN DEL REFRIGERADOR PUERTAS REVERSIBLES $pRMH HO WRUQLOOR GH PRQWDMH FRQ XQD OODve Allen de ¼”. ADVERTENCIA Tornillo de Montaje PELIGRO DE CHOQUE ELÉCTRICO Antes de comenzar, desenchufe el refrigerador o desconecte la corriente de electricidad en el cortacorriente o caja de fusibles.
Page 49
INSTALACIÓN DEL REFRIGERADOR 7. Usando la llave tubular de 10mm o de pulgadas, quite los l l i s i b o i r a un lado. Bisagra Superior 12. Levante la tapa que está en el lado izquierdo de la parte superior del rHIULJHrador parD HQFRQWUDU ORV RULoFLRV de los tornillos.
Page 50
INSTALACIÓN DEL REFRIGERADOR $pRMH HO WRUQLOOR GH PRQWDMH FRQ XQD OODve allen de ¼”. Tornillo de Montaje 4. Desatornille el botón decorativo con sus dedos rotándolo en $pRMH \ TXLWH ORV WRUQLOORV \ XVH HO GHVWRUQLOODGRU SKLOOLSV SDra contra de las manecillas del reloj quitar el soporte de bisagra central del marco del refrigerador coloque las partes a un lado...
Page 51
INSTALACIÓN DEL REFRIGERADOR INSTALACIÓN DEL REFRIGERADOR 13 . Voltee el retenedor de puerta girandolo sobre si mismo. 9. Utilizando una llave tubular de 10mm o de pulgadas con Mueva el soporte de insercion de bisagra y el pivote de insercion manteniendo la misma orientacion en el lado Inferior del lado derecho del marco.
Page 52
INSTALACIÓN DEL REFRIGERADOR 5. Rote las jaladeras. La jaladera del congelador muevala del lado derecho del marco. Ponga la tapa en el lado al refrigerador, y la jaladera del refrigerador muevala al derecho. La tapa se ajusta a la fuerza. congelador.
INSTALACIÓN DEL REFRIGERADOR 8. Instale la jaladera del refrigerador ajustando las huellas de NIVELACIÓN la jaladera para que encajen con los sujetadores de montaje. Para evitar la vibración, la unidad debe de estar nivelada. Apriete los tornillos con una llave Allen de pulgadas.
USO DEL REFRIGERADOR CONFIGURANDO LOS CONTROLES FLUJO DE AIRE BLOQUEO DEL DISPENSADOR (En algunos modelos) Para obtener temperaturas estables, el airH GHEH pXLU Presione el botón “WATER LOCK” para bloquear el entre las secciones del congelador y refrigerador. Como se dispensador (luz del botón encendida).
USO DEL REFRIGERADOR GUÍA PARA EL ALMACENAMIENTO DE ALIMENTOS ALMACENAMIENTO DE ALIMENTOS CONGELADOS Envuelva o almacene los alimentos en el refrigerador dentro NOTA: Consulte una guía de congelación o un libro de de materiales herméticos y antihumedad, a menos que se cocina para obtener más información sobre la indique lo contrario.
USO DEL REFRIGERADOR DISPENSADOR DE AGUA (En algunos modelos) ADVERTENCIA Para dispensar agua fría, empuje el interruptor del dispensador con un vaso . Peligro de lesiones personales NO coloque sus dedos o manos en el mecanismo automático de hacer hielo mientras el refrigerador está enchufado.
USO DEL REFRIGERADOR ESTANTES DEL REFIGERADOR CAJÓN PANTRY Los estantes en su refrigerador son ajustables para Para remover el cajón pantry: cumplir con sus necesidades de almacenamiento. Todos los estantes en esta unidad son de cristal. Retire los recipientes de la puerta antes de retirar o re- emplazar el cajón de despensa.
USO DEL REFRIGERADOR CAJÓN CON CONTROL DE HUMEDAD Para Sacar La Tapa Del Compartimiento De Verduras: Los cajones para verduras mantienen el sabor y la 1. Saque ambas gavetas del compartimiento. frescura de la fruta y la verdura al permitir controlar 2.
NOTA: La tapa de sustitució debe guardarse para un futuro. Si el es removido y no se reemplaza, es local de Sears al 1-844-553-6667 necesario reinstalar la tapa de sustitución para prevenir También puede comprar vía internet en www.kenmore.com fugas de agua.
Page 60
NOTA: Para comprar un ÀOWro de reemplazo, YLVLWH su tienda 3URGXFWR GLVWULEXLGR HQ ORV (VWDGRV 8QLGRV GH $PpULFD local de Sears, llame al 1-844-553-6667. por Transform SR Brands Management LLC Hoffman 7DPELpQ SXHGH FRPSUDU YtD LQWHUQHW HQ ZZZNHQPRUHFRP (VWDWHV ,/ 86$...
CUIDADO Y LIMPIEZA PAREDES INTERIORES (deje que el congelador se caliente ADVERTENCIA para que el trapo no se quede pegado) Para ayudarle a eliminar los olores, puede lavar el interior del refrigerador con una mezcla de bicarbonato sódico y agua templada. Mezcle 2 cucharadas soperas de bicarbonato sódico (unos 26 g) en 1 litro de agua.
Page 62
CUIDADO Y LIMPIEZA CUANDO SE MUDA INTERRUPCIONES DE ALIMENTACIÓN Cuando vaya a trasladar su refrigerador a una nueva casa, 1. Si la interrupción de la corriente durará 24 horas o siga estos pasos para prepararlo para la mudanza. menos, mantenga todas las puertas del refrigerador cerradas para que los alimentos permanezcan fríos y 1.
CONEXIÓN DE LA TUBERÍA DE AGUA ANTES DE EMPEZAR QUÉ NECESITARÁ v Tubería de cobre, de ¼ de pulgada Esta instalación de la tubería de agua no está cubierta por de diámetro, para conectar el la garantía del refrigerador. Siga estas instrucciones con refrigerador al suministro de agua.
Page 64
CONEXIÓN DE LA TUBERÍA DE AGUA INSTRUCCIONES DE INSTALACIÓN 5. APRIETE LA ABRAZADERA PARA TUBOS Apriete los tornillos de la abrazadera hasta que ADVERTENCIA la arandela de sellado comience a hincharse. NOTA: Tenga cuidado de no sobreapretar la Riesgo de descargas eléctricas abrazadera, ya que podría romper la tubería.
Page 65
CONEXIÓN DE LA TUBERÍA DE AGUA CONEXIÓN DE LA TUBERÍA DE AGUA 8. DRENE LA TUBERÍA ABRA LA VÁLVULA DE PASO Apriete todas las conexiones que tengan fugas. Gire el suministro principal de Vuelva a poner la cubierta de acceso al compresor. agua hacia la derecha y drene la tubería hasta que el agua esté...
Page 66
GUÍA DE SOLUCIÓN DE PROBLEMAS DESCRIPCIÓN DE LOS SONIDOS QUE SE PUEDEN ESCUCHAR Es posible que su nuevo refrigerador haga ruidos que el antiguo no hacía. La mayoría de los nuevos sonidos son normales. Las duras, como el suelo, las paredes y los muebles, pueden hacer que los sonidos parezcan más fuertes de lo que realmente son.
Page 67
GUÍA DE SOLUCIÓN DE PROBLEMAS Problema Causas posibles Soluciones Las luces no El cable de alimentación no está (QFKXIH oUPHPHQWH el cable en una toma de corriente con funcionan. enchufado. el voltaje adecuado (consulte Requisitos eléctricos y de conexión a tierra). Se ha fundido una bombilla.
Page 68
GUÍA DE SOLUCIÓN DE PROBLEMAS Problema Causas posibles Soluciones Consulte la sección Nivelación y alineación de las puertas. Las puertas El refrigerador no está nivelado. no se cierran Hay paquetes de alimentos Reorganice los contenedores de alimentos para liberar la completamente.
GUÍA DE SOLUCIÓN DE PROBLEMAS Problema Causas posibles Soluciones Consulte la sección Descripción de los sonidos que se El refrigerador parece Los sonidos podrían ser normales pueden escuchar para obtener más información. que hace demasiado para su refrigerador. ruido. La máquina de hielo La instalación es nueva.
Page 70
GUÍA DE SOLUCIÓN DE PROBLEMAS Problema Causas posibles Soluciones La temperatura es Los conductos de ventilación del aire Con la mano, busque los conductos de ventilación demasiado cálida o están bloqueados. El aire frío circula del aire para sentir el de aire y mover todos los hay una acumulación desde el congelador hacia la sección...
PARTS AND FEATURES DIAGNOSTICS ™ Diagnostics (en algunos modelos) Si tiene algún problema con su refrigerador, puede transmitir datos a través de su teléfono al centro de servicios. Esto le otorga la capacidad de hablar directamente con nuestros especialistas capacitados. El especialista registra los datos transmitidos desde su máquina y los utiliza para analizar el problema, brindándole un diagnóstico rápido y efectivo.
