Setup and Test the Analog Output on the HI 4050 unit
The purpose of this technical note is to guide the user through the setup, testing and
calibration, if necessary, of the Analog output option on the HI 4050 unit.
This setup can be performed either through the front keypad or the online browser. These
instructions will not differentiate between the two methods.
The analog output option on the HI 4050 unit has four channels. The first and third
channels are a voltage output and the second and fourth channels are current output.
Each channel is independent from the other channels.
Setup:
OUTPUTS:
Default outputs are:
Channel 1: 0-10 V
Channel 2: 4-20 mA
Channel 3: 0-10 V
Channel 4: 4-20 mA
Each of the analog output channels allows the user to change the output range of the
channel. So the channels can be changed to be anywhere from x to y, where x is the low
output (range 0-10 V or 0-20 mA) and y is the high output (range 0-10 V or 0-20 mA).
Examples:
Channel 1: 0-5 V;
Channel 2: 0-20 mA;
Channel 3: 10-0 V; (note the reverse output levels.)
Channel 4: 4-12 mA;
INPUTS:
Default inputs are: 0-100 for all channels.
___________________________________________________________________________________
9440 Carroll Park Dr. · Suite 150 · San Diego, CA 92121-5201· 858/278-2900 ·
800/821-5831 Fax 858/278-6700 · Web www.hardysolutions.com
TECHNICAL NOTE
P
S
ROVIDING
OLUTIONS
Process Weighing
Vibration Monitoring
Local Field Service
I
:
N
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hardy Process Solutions HI 4050
Summary of Contents for Hardy Process Solutions HI 4050
- Page 1 This setup can be performed either through the front keypad or the online browser. These instructions will not differentiate between the two methods. The analog output option on the HI 4050 unit has four channels. The first and third channels are a voltage output and the second and fourth channels are current output.
- Page 2 ROVIDING OLUTIONS Process Weighing Vibration Monitoring Local Field Service The range of the inputs allowed is virtually unlimited; however, even though the outputs can be ranged in reverse order, to operate correctly, the input HIGH value must be higher than the input LOW setting. Operation: The output range will be applied relative to the input range.
- Page 3 ROVIDING OLUTIONS Process Weighing Vibration Monitoring Local Field Service 6. Verify the mapping term in the ‘Map Dest’ line shows the term for the destination you chose. 7. Scroll down to ‘Src’ (source); 8. Use the right/left arrow keys to scroll through the source mapping terms available for mapping in this manner.
- Page 4 ROVIDING OLUTIONS Process Weighing Vibration Monitoring Local Field Service Testing: Setting up the test for the analog output: There are three methods to check if the output from the analog output channel is correct: The loop back value shown on the analog output setup page; ...
- Page 5 Vibration Monitoring Local Field Service Calibration, (applies to the HI 4050 and HI 4060 units): On some occasions the output from the analog output channel is slightly off from the expected output. If this is the case, there is a method for the HI 4000 series units to re- calibrate the analog outputs.
- Page 6 ROVIDING OLUTIONS Process Weighing Vibration Monitoring Local Field Service Setup for the recalibration: As shown, the expected outputs of 4.00 and 12.00 are entered as the desired outputs. The actual outputs measured at the two points are then entered as well. Clicking on the “Recalibrate”...
