Page 3: Table Of Contents
Chapter 3 Prepare for Use………………………………..…..5 3-1 Load Batteries and Memory card…………………………...5 3-2 Turn ON/OFF the Camera………………………………..….6 3-3 Setup……………………………………………………..…..6 3-4 Using Your Digital Camera…...…………………………….13 Chapter 4 How to Install and Use the Application………...17 4-1 Installation of the Driver………………………………...18 4-2 Installation of the Application…………………………...20 Chapter 5 Specifications…………………………………...24... -
Page 4: Chapter 1 Attention
Chapter 1-Attention Please read through this manual carefully before using the camera and follow the instructions to avoid any damages that may be caused by improper operation. 1-1 Attention The software CD-ROM packaged with the camera is designed for PC only. - Page 5 1. Damp and dusty places. 2. Sealed vehicles or places exposed to direct sunlight or places subject to extremely high temperatures or heat. 3. Violently turbulent environment. 4. Locations full of smoke, oil fumes or steam. 5. Rain or snow environment. •...
-
Page 6: Chapter 2 Getting To Know Your Camera
Chapter 2-Getting to know Your Camera 2-1 Functional Parts of the Camera Self-Timer LED Flash Light Viewfinder Lens USB Jack Tripod Socket Battery Cover Viewfinder Operation LED 10. ON/OFF Button 11. Shutter Button 12. Mode Dial 13. Up Button 14. Strap Hook 15. -
Page 7: Monitor Screen Display
Monitor Screen Display Chapter 3-Prepare for Use 3-1 Load Batteries and Memory Card Open the battery cover and put in two (2) new AA alkaline batteries according to the polarity indicated on the battery door, then insert the memory card, and close the cover. -
Page 8: Turn On/Off The Camera
3-2 Turning ON/OFF the Camera To turn on the camera, press the ON/OFF button until the operation LED light comes on. To turn the camera off, press and hold the ON/OFF button for two (2) seconds. The camera will turn off automatically after 30 seconds of inactivity if not connected to the USB port. - Page 9 adjust and menu button to enter the selected item. Adjusting exposure value: EV range from -1.5 ~ 1.5. Select white balance option. Adjust sharpness option. 1.3 Resolution Press the UP or DOWN button to select the resolution, then press menu button to confirm. Super: 2304x1728 High: 2048x1536...
- Page 10 Middle: 1600x1200 Low: 1280x1024 1.4 Quality Press the UP or DOWN button to select the quality, then press menu button to confirm. Press RIGHT button to next menu… 1.5 Auto Power Off Time Press the DOWN button to set. 1.6 Date Time Press the DOWN button to set date and time.
- Page 11 DISPLAY. 1.7 Frequency Set the anti-flicker frequency if you use fluorescent light 1.8 Language Press the UP or DOWN button to select the language, then press menu button to confirm. 2. Preview Function 2.1 Erase Press the menu button to enter the erase window. Press the UP or DOWN button to select "erase one"...
- Page 12 Selecting the protect mode will protect the frame selected. If you want to unprotect the frame, select the frame, then enter erase mode and select unprotect mode. 2.2 Auto Power Off Time Press the DOWN button to set.
- Page 13 2.3 Date Time Press the DOWN button to set. When you choose DISPLAY, the date and time will show on the picture, otherwise choose NO DISPLAY. 2.4 DPOF (Digital Print Order Format) If you use DPOF for printing your images, you can select particular images and set individual quantities for each image that you want to print.
- Page 14 2.5 Rotation Press UP or DOWN button to select the rotation angle. Press menu button to enter the selected angle. 2.6 USB Press DOWN button select communication type between camera and host. Select the menu button to confirm the setting. Note: The SIDC download mode only can be used in Win dows XP with driver installed.
-
Page 15: Using Your Digital Camera
3-4 Using Your Digital Camera 1. Taking Pictures Press the shutter button down and when you hear a distinct beeping sound, the snapshot is finished. At the same time, the number on the monitor screen will decrease by one. 2. Self-Timer Press the menu button, change to SELF-TIMER mode, then press the menu button to confirm. - Page 16 when required. Press the shutter button to take a picture and the flash will operate according to the flash option chosen. 5. Using Digital Zoom In REC modes, you can use digital zoom. Press the UP button to zoom in and press the DOWN button to zoom out. 6.
- Page 17 Windows 98SE, please install the camera driver first, then connect the camera in preview mode. The computer will find a new device like USB mass storage device and install the device driver auto. After the driver is installed, the camera will be recognized as a removable FLASH DISK.
- Page 18 Then select Options as Preview. If you want to change the imaging size, select the Video Capture Pin then change the Output Size.
-
Page 19: Chapter 4 How To Install And Use The Application
Chapter 4-How to Install and Use the Accompanying Application Insert the accompanying CD into the CD-ROM drive and the Install Dialogue Box will appear automatically. -
Page 20: Installation Of The Driver
4-1 Installation of the Driver Pressing the Install Driver button will install the camera driver. - Page 21 Turn on the camera in recording mode and connect it to the computer. The computer will find a new device and automatically install the device driver. If the computer prompt needs a file path, search it with the path C:\WINDOWS\SETUP533. When installation is finished, go...
-
Page 22: Installation Of The Application
to Control Panel\System\Hardware\Device Manager and check the Imaging Device\Icatch (IV) Still Camera Device and Icatch(IV) Video Camera Device is OK. 4-2 Installation of the Application Press the Install Photo Express button to install the Application software <Ulead Photo Express 4.0>. The <Language select>... - Page 23 "Software License Agreement" dialogue box appears, asking whether you accept this agreement. Click <Yes> to accept it. <English>, then click <OK>. "Welcome" interface appears. Click "Next" button,...
- Page 24 "User Information Interface" appears. Type in the username and company information, and then click "Next." "Choose Destination Location" interface appears and according to the language instruction, choose installation route (Optional). Click "Next.”...
- Page 25 The interface changes into "Select Program Folder" and click "Next." "Start to Copy Files" appears, click "Next" to start copying files and at the same time, the copying progress bar appears on the screen.
-
Page 26: Chapter 5 Specifications
Chapter 5-Specifications • 3 in 1 mode: Digital Still Camera Mode: Image Capture. PC Camera Mode: Video Capturing/Conferencing. Camcorder Mode: Video Clips. • Sensor: 3.1 Mega Pixel CMOS Sensor, Image Enhancement up to 4.0 Mega Pixel using built-in firmware* • Lens: F=3.0 f=8.35 •... - Page 27 • Image Resolution: Super(2304x1728)*/High(2048x1536)/Medium(1600x1200)/ Low (1280x1024) for Image Capture. VGA (640x480)/QVGA (320x240) for PC camera mode. QVGA (320x240)/QCIF(192x144) for Video Recording Mode. • Memory: Internal 16 MB SDRAM • External SD Card (8MB-1GB) • Self-Timer: 10 sec. • ZOOM: 8x Digital Zoom. •...
-
Page 28: Chapter 6 Q&A Section
Chapter 6- FAQ 6-1 Camera Will Not Turn On • Battery is not properly installed – remove and reinstall the batteries. • Insufficient battery voltage. Do not use old batteries or batteries with mixed battery life. It is not recommended to use rechargeable batteries with lower voltage. - Page 29 XP can you download picture from the Photo Express, the USB mode shall be set to SIDC. It is always recommended to disconnect your digital camera from your computer safety unplug button on your desktop to ensure that the USB port is released for...
- Page 30 next-time interface. • Flash disk does not display images recorded. The camera will load two removable flash drives on your computer under MSDC mode. The first drive is the external SD or MMC cartridge and the second drive is the recorded images saved in the built-in memory of the camera.
