VuPoint DC-ST15-VP User Manual

User's Manual
DC-ST15R-VP / DC-ST15B-VP / DC-ST15O-VP
•
Specification
3 in 1 Digital Camera:
Image Sensor:
Resolution:
Color:
Lens:
Capture Range:
Memory:
Capacity:
POWER:
Computer Interface:
Note:
The quantity of compressed picture varies and depends
on the scene complexity.
•

System Requirement

OS: Microsoft Win98SE/2000/ME/XP
Mac V9.x/X.x*
Hard Disk Space: 200MB or above
Memory: 32MB RAM or above
USB interface and CD-ROM
Color Monitor (at least 800x600 24 bits or above)
*Driver for Mac OS can be downloaded at:
http://www.vupointsolutions.com
•

Functional Parts of the Camera

Shutter button
Viewfinder
Battery Door
Digital Still Camera
Video Capturing
Conferencing (Web cam)
CMOS Sensor
CIF 352x288 Pixels
QCIF 176x144 Pixels
24 bits
F2.8, f =6.2mm
1.6 ft. ~ Infinity
Built-in 16Mb SDRAM
40-80 pictures (Compressed CIF)
18 pictures (CIF 352x288)
120-200 pictures (compressed
QCIF)
70 pictures (QCIF 176X144)
1 AAA Alkaline battery
USB
Shutter button
Lens
LCD
USB
Mode button
Buzzer
•

Get started

1. Load the battery according to the correct polarity indicated on
the battery door.
2. Turn the camera on by pressing the MODE button.
Precaution:
While the camera is connected to the USB cable, it is
unnecessary to use a battery. The camera uses the power
supplied from computers USB interface.
Before using the PC-Cam function, please download all photos
in the camera onto your computer to avoid any missing
photos.
Warning:
1. If you don't use the camera for a period of time, please
remove the battery. Photos will be lost if the battery is
removed or if the battery has no power.
2. Please follow local regulations when disposing used batteries.
3. If the camera is not used in 30 seconds, it will enter standby
mode automatically to save the battery energy. You may press
the mode button to restart the camera operation again.
•

Software installation

Attention:
Make sure you install all the necessary software in your
computer before you connect the camera to a computer.
1. Close all opened software applications on your computer
before installing the software.
2. Insert the CD-ROM into the computer CD-ROM drive, it will
automatically install the camera driver. Please follow the
instructions on screen to finish the installation process.
Important:
For Windows98, Microsoft® DirectX 8.0 a higher version is
required to be installed before driver installation. If there is not
DirectX 8.0 in your PC, please install it first. The DirectX 8.0
is included in the CD supplied under the "DirectX" folder, you
can run the dxsetup.exe to install it.
If the XP warning dialogue box pops up during driver installation,
please click "Yes" button to continue.
