- Page 1 XL NO-TOUCH | WALL MOUNT INSTALLATION GUIDE & PARTS LIST PATENT PENDING WM-NT600 | WM-NT600W Please read all pages prior to installation!
-
Page 2: Parts List
Installation Guide PARTS LIST PART NAME PART NAME XL No-Touch Mount Universal Controller Power Supply Interface Arms Input: AC 100-240 V (50-60Hz) VESA 1000mm Extension Arms Output: 12V-2A M8 x 10mm Screws Controller Button M8 Washers x 2mm USB Male To Male... - Page 3 www.purelink.de INTERFACE KIT PART NAME PART NAME M6 x 16mm Screws M8 x 5mm Spacers M6 x 25mm Screws M8 x 13mm Spacers M6 x 40mm Screws M8 x 25mm Spacers M8 x 16mm Screws M6 Washers (for parts A-C) M8 x 25mm Screws M8 Washers (for parts D-F) M8 x 40mm Screws...
-
Page 4: Installation Safety Instructions
Installation Guide INSTALLATION SAFETY INSTRUCTIONS This mount is intended for use with flat screens that do not exceed the maximum weight indicated of 135Kgs (300lbs.). Exceeding this weight limit will result in instability, causing possible injury. Do not attempt to install this product until all instructions and warnings have been read and properly understood. Please keep these instructions for future reference. -
Page 5: Installation Tools Required
www.purelink.de Some products have moving parts and the potential to cause injury through the crushing or trapping of fingers or other body parts, exercise care and read all warnings. Pay close attention to all moving parts, especially when assembling, installing and servicing. Immediately after installation, double check that the work done is safe and secure. - Page 6 Installation Guide WARNING PureLink GmbH recomienda que un instalador de audio y video profesional u otra persona debidamente cualificada instalen este producto. PureLink GmbH, sus distribuidoresy concesionarios no se hacen cargo ni se responsabilizan de ningún daño o lesión provocados por una instalación inapropiada. Este producto se debe montar en una estructu- ra adecuada y se debe utilizar soportando solamentre hasta el peso máximo indicado.
-
Page 7: General Recommendations
www.purelink.de General recommendations Check the wall structure being mounted to. Use a level to ensure the wall is flat and note areas of concern. Use washers, shims or spacers between the wall and the mount to create a flat surface for mounting. A flat mount will make adjustments much easier and faster when aligning screens. -
Page 8: Installation Instructions
Installation Guide INSTALLATION INSTRUCTIONS Unpack and check all parts Step 1 Open top and bottom handwheels on Interface Arms (closed for shipment). Check depth and lateral adjustment knobs are centered in adjustment range. Control Box Center Open top and bottom Handwheels Center Keep area below... - Page 9 How to use Universal Controller to operate the Mount The PureLink XL No-Touch Mount, allows the screen to move OUT and IN, without the need to touch the screen. Position the control wand approximately 150 mm/6” to the right of center of the mount (see below). The mount will slowly start to move OUT.
- Page 10 Installation Guide Move Universal Controller with the Mounts Movement Once the Universal Controller is positioned below the light beam, the Mount will start moving. To keep the Mount moving, make sure you sync the Universal Controller with this movement. If you remove the controller from the right spot, the Mount will STOP.
- Page 11 www.purelink.de Position of the light beam X = Depth of the screen Y = 75mm Z = X + Y + 10mm Z* = Depth controller needs to be from front of screen to operate the Mount. * some users mark the controller to show this distance for easier use Attach the Interface Arms to the screen (Landscape or Portrait) Step 5...
- Page 12 Installation Guide Connect screen to Mount Step 6 At slight angle, hook arms onto top of frame, then flatten screen onto Mount base until it clicks into position. Make Adjustment (See below) Step 7 A : Height adjustment D: Lateral micro adjustment B: Corner depth adjustment E: Locking handwheels C: Lateral macro adjust...
- Page 13 www.purelink.de Each time you add a screen to the video wall make needed adjustments. Locking handwheels *Note: Locking handwheels must be loosened before any adjustments can be made. Once all adjustments are done, the locking handwheels can be tightened. 1) unlock lateral Smart-Lock, 2) slide screen into position, 3) slide Smart-Lock to interface arm, 4) lock Smart-Lock.
- Page 14 Installation Guide Height adjustment Corner depth adjustment...
- Page 15 www.purelink.de RECESS FLAT SCREEN INSTALLATION Make a rectangular hole on the wall using the dimensions of the chosen screen by fol- Step 1 lowing the instructions below. • Please ensure minimum gaps between the screen and four edges of the recessed box is 2mm and that corners and four angles are 90 degrees.
- Page 16 Installation Guide Locate the mount’s back wall plate by using tape ruler and bubble level. Step 2 Important: The VESA holes position of a monitor is pre-defi ned by the manufacturer. • Must use Electric Wall Scanner to locate the position of electric wires before drilling into the wall. 2.1 If H1=H3, the position of the mount will be in the middle of the recessed box (H1, H3: See on pages 15).
- Page 17 www.purelink.de 2.2 If H1<H3, the center of mount will be higher than the center of the recessed box.(H1, H3: See on pages 15). • Calculate and mark the retangular box for the position of back wall plate by 3 dimensions as bellow A1, A2, B (Size of back wall plate HxW=468x480 mm) =>...
- Page 18 Installation Guide 2.3 If H1<H3, the center of mount will be lower than the center of the recessed box.(H1, H3: See on pages 15). • Calculate and mark the retangular box for the position of back wall plate by 3 dimensions as bellow A1, A2, B (Size of back wall plate HxW=468x480 mm) =>...
- Page 19 www.purelink.de CONNECTIVITY There are several different ways to control the mount 1. Universal Controller 2. USB 3. Wifi 4. Ethernet 5. Bluetooth Control box...
- Page 20 Installation Guide 1. Universal Controller To see how to control the mount using Universal Controller, go to pages 9-11. 2. USB There are 2 ways to control the mount via USB Port (USB button and PC via USB port) 2.1 USB Button •...
- Page 21 www.purelink.de 2.2 PC via USB Port • Plug one connector of the USB cable Male to Male to PC/USB port. • Plug the other connector side to PC Important: • Don’t put the cable into the X-arm movement at center. •...
- Page 22 Installation Guide 3. Wifi • The Mount connects to the Wireless Access Point via wireless connection. • Wireless Access Point connects to the Internet Server. • Laptop, PC or other devices connect to the Internet Server. Important: The Wireless Access Point needs to be as near the mount as possible Mount 02 Mount 01 Control box...
- Page 23 www.purelink.de 3. Ethernet 3.1 Local Network Controller (Without internet) • The Mount connects to the Switch • The Switch connects to computers/laptops. Note: Secure the LAN cable in place by tightening it to the hole panel. Mount 02 Mount 01 Control box Control box LAN cable...
- Page 24 Installation Guide 3.2 Internet connection • The Mount connects to the Switch • The Switch connects to the Internet Server • Laptop, PC or other devices connect to the Internet Server Note: Scure the LAN cable in place by tightening it to the hole panel. Mount 02 Mount 01 Control box...
- Page 25 www.purelink.de 4. Bluetooth You can only connect one mount to one device at once. • The Mount connects to smartphone via bluetooth. Control box Bluetooth Smartphone...
-
Page 26: Disclaimer Of Liability
Installation Guide Disclaimer of Liability PureLink GmbH will not be held liable, nor provide any warranty for damage resulting from improper installation, assembly and use of the product, or failure to observe the operating instructions and/or safety instructions. CONFIRMATION OF CE CONFORMITY PureLink GmbH hereby declares that the device type WM- NT600 is in conformity with the Directives 2014/30/EU, 2019/1782/EU, 2011/65/EU, 2015/863/EU and 2014/35/EU... -
Page 27: Self Help Guide
www.purelink.de Self help guide Issues Solutions Controller not remaining in correct location - if the Controller is on the edge of the light beam, as the controller moves forward and backward with the moving mount, it can move out of the beam and stop. Move the controller left and right to check the beam location. -
Page 28: Product Dimensions
Installation Guide PRODUCT DIMENSIONS 39.9 ” 11.4 ’’ (+/-0.3) 3.8’’ (+/-0.3) 1012.5 mm 290 mm (+/-10mm) 97.5 mm (+/-10mm) 18.4’’ 468mm 29.5 ’’ 748.8 FRONT SIDE VIEW OPEN SIDE VIEW CLOSED 39.9 ’’ 39.4 ’’ 1012.5 mm 1000 mm 35.4 ’’ 900 mm 39.4 ’’... - Page 29 www.purelink.de...
- Page 30 Installation Guide...
- Page 31 www.purelink.de...
- Page 32 PureLink GmbH Von-Liebig-Str. 10 D - 48432 Rheine Germany +49 (0)5971 800 299-0 www.PureLink.de PureLink UK LTD. Carpenter Court 1 Maple Road Bramhall, Stockport Cheshire SK7 2DH United Kingdom All information without responsibility for errors in photography and typography. Specifications are subject to change without notice. ©...
