Summary of Contents for VTech vt2423
-
Page 2: Table Of Contents
About Caller Identification ... 2 Parts Check List ... 2 INSTALLATION ...3 Before You Install ... 3 Table/Desk Installation ... 4 TELEPHONE OPERATION ... 5 Make a Call... 5 Answer a Call ...5 End a Call ... 5 Program/Channel...5 Redial ...5 Handset Volume ... -
Page 3: Important Safety Instructions
13. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lighting. 14. Do not use the telephone to report a gas leak in the vicinity of the leak. SAVE THESE INSTRUCTIONS... -
Page 4: Before You Begin
There are fees for Caller ID services, and they may not be available in all areas. This product can provide information only if both you and the caller are in areas offering Caller ID service, and if both telephone companies use compatible equipment. Parts Check List: 1. -
Page 5: Installation
INSTALLATION Before You Install 1. Choose a location for the Base near an electrical outlet and a telephone jack. This phone requires a modular telephone jack and a standard electrical outlet (110v AC) not controlled by a wall switch. Plug the AC power adaptor into the electrical outlet and the DC connector to the jack on the bottom of the Base Unit. -
Page 6: Table/Desk Installation
Place the handset in the base. Charge the battery for at least 12 hours the first time. 4. Check for dial tone After the batteries are charged, connect the modular telephone cord between a live phone jack and the jack located on the bottom of the Base Unit. Pick up the Handset and press PHONE. -
Page 7: Telephone Operation
TELEPHONE OPERATION... -
Page 8: Page/Handset Locator
TELEPHONE OPERATION Message Waiting Indicator If you subscribe to telephone company voice mail with a visual message waiting signal, this light will flash when you have new voice mail. In addition, the Handset displays: MESSAGE WAITING. NOTE: The visual MESSAGE WAITING... -
Page 9: Handset Ringer Style/Battery Save
Temporary Tone Dialing If you have dial pulse (rotary) service, you can change from dial pulse to touch tone dialing during a call by pressing signals for access to telephone banking or long distance services. 1 Dial the number. 2 Press TONE. -
Page 10: Operating Range
TELEPHONE OPERATION Operating Range This cordless telephone operates within the maximum power allowed by the Federal Communications Commission (FCC). Even so, this handset and base can communicate over only a certain distance — which can vary with the locations of the base and handset, the weather, and the construction of your home or office. -
Page 11: Telephone Memory
TELEPHONE MEMORY This cordless phone can store 10 telephone numbers with names, each up to 16 digits long in memory locations you assign (0-9). Note: Press OFF at any time to exit memory dial mode. Store a Number and Name in Memory 1 Press PROG/CHANNEL, then press 2 Press MEM. -
Page 12: Edit A Number/Name Stored In Memory
TELEPHONE MEMORY 8 Press to change the setting. Choose (for Yes) if you wish the phone to alert you to calls from this number by changing to a distinctive ringing pattern after the first ring. Choose (for NO) for a normal ringing pattern. -
Page 13: Telephone Directory
TELEPHONE DIRECTORY This cordless phone can store 40 telephone numbers with names, each up to 16 digits long. Entries are stored alphabetically. For consistency with Caller ID entries, you may wish to enter last names first. Note: Press OFF at any time to exit directory. -
Page 14: Edit A Number/Name Stored The Directory
TELEPHONE DIRECTORY 8 Press SELECT or PROG/CHANNEL to confirm your selection. If you chose , a will be displayed with the directory entry. NOTE: When memory is full the screen displays and you will not be able to store a new number until you delete a stored number. -
Page 15: Memory
For each call that comes in, the screen displays the following information between the first and second rings: • Your caller’s name (15 letters are sent by your telephone company) • The caller’s area code and telephone number • The time and date of the call •... -
Page 16: Dial A Displayed Number
CALLER ID OPERATION 4 Press until 5 Press SELECT. You will hear a series of beeps confirming the deletion. NOTE: If there are new CID records not yet reviewed , the “ ALL” option will not be displayed as a selection. Dial a Displayed Number 1 Locate the record in call history that you want to dial. -
Page 17: Batteries
5 The new battery pack must be charged before using the phone. Place the Handset in the base and allow it to charge at least 12 hours for the first time. The telephone might operate before that, but for best performance, let the battery pack charge fully. -
Page 18: In Case Of Difficulty
• Make sure the AC adapter is plugged into an outlet not controlled by a wall switch. • Make sure the telephone line cord is plugged firmly into the base unit and the modular jack. • Make sure the base antenna is fully upright. - Page 19 • Press PROG/CHANNEL to change to another channel. • Disconnect the base from the modular jack and plug in a corded telephone. If you still hear other calls, the problem is probably in your wiring or local service. Call your local telephone service company.
-
Page 20: Maintenance
Avoid water Your telephone can be damaged if it gets wet. Do not use the Handset outdoors in the rain, or handle it with wet hands. Do not install your Base Unit near a sink, bathtub or shower. -
Page 21: Warranty Statement
Warranty Statement What does this limited warranty cover? The manufacturer of this product warrants to the holder of a valid proof of pur- chase (“Consumer” or “you”) that the product and all accessories provided in the sales package (“Product”) are free from material defects in material and workmanship, pursuant to the following terms and conditions, when installed and used normally and in accordance with operation instructions. - Page 22 (product model) and the date of purchase or receipt; and Provide your name, complete and correct mailing address, and telephone number. Other Limitations This warranty is the complete and exclusive agreement between you and the manufacturer. It supersedes all other written or oral communications related to this Product.
-
Page 23: Fcc Regulations
Your telephone company may discontinue your service if your equipment causes harm to the telephone network. They will notify you in advance of disconnection, if possible. During notification, you will be informed of your right to file a complaint with the FCC. - Page 24 This equipment may not be used on coin service provided by the phone company or Party Lines. The REN is useful in determining the number of devices you may connect to your telephone line and still enable the devices to ring when you receive a call. The general rule is that the REN value should not exceed 5.0A total;...
-
Page 25: The Rbrc Seal
Base : MEMORY Speed Dial: 10 Memory locations, 16 digits per location. CID : Alpha Numeric Display Memory locations Directory: 40 telephone numbers with names in the directory. SPECIFICATIONS ARE TYPICAL AND MAY CHANGE WITHOUT NOTICE. 9V DC @ 400mA... - Page 26 Printed in China 91-5809-10-00 ISSUE 0...
