MDT Technologies Object Server VisuControl Easy II Technical Manual page 57

Technical Manual
Object Server VisuControl Easy II [VC-EASY.03]
ETS text
The following general settings are available for "1 Bit functions"
Presentation format
Value for ...
Value
Value for status:
„X / Y"
Symbols
The following general settings are available for functions with "1/2/3/4/14 Byte"
Presentation format
Minimum/maxi-
mum value
Step width
Value
Scene number
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
Dynamic range
[Default value]
two buttons
■
one button: toggle
■
one button: send value
■
Selects the polarity according to
the function selection
0
■
1
■
„X" = 0 / „Y" = 1
■
„X" = 1 / „Y" = 0
■
Fixed symbols according to
the set function selection
Input field
■
one button with fixed value
■
slider
■
Enter a value according to
the function selection
Enter a value according to
the function selection
Enter a value according to
the function selection
1 ... 64
[1]
Comment
Settings, how the function is to be
displayed in the app.
Sets which value is to be sent for
the corresponding function.
For "two buttons" and "one
button: toggle" formats.
Sets the value to be sent.
For "one button: send value"
format.
Sets how the status is to be
displayed.
"X" and "Y" stand for the options
corresponding to the function
selection.
Displays the symbols that are
shown in the app.
Settings, how the function is to be
displayed in the app.
Input of minimum or maximum
possible values.
Enter the step width to increase/
decrease the value to be sent.
Only with "Slider" format.
Enter a fixed value to be sent.
Only with "one button with fixed
value" format.
Enter a scene number.
Only when selecting "Scene
number" or "Scene control".
57 / 84
