Technical Manual
Object Server VisuControl Easy II [VC-EASY.03]
"one button: send value" causes the same value to always be sent. This can be, for example, a defined
"off" command when leaving the house. The status is displayed in the app after feedback is received from
the actuator with the polarity selected in "Value for status: ...".
The symbols displayed in the app are assigned for each light type and cannot be changed.
The table shows the available communication objects:
Number Name/Object function
116 F1: – Switch
116 F1: – Toggle
117 F1: – Status: On/Off, Status: Toggle
Table 17: Communication objects – Function type: Light On/Off
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
Length Usage
1 Bit Switching function to the actuator.
1 Bit Toggle function to the actuator.
For "one button: toggle".
1 Bit Receive the switching status from the
actuator.
