Eurotramp Winam Double-Minitramp Assembly Instructions

Assembly instructions anti-slip plates Double-Minitramp
185 cm
1
Process:
• Carefully clean the surface on which the DMT is to stand
(free of dust and grease).
• Apply the double-sided tape over the entire surface of a
clean side of the assembled multiplex board (e.g. in
longitudinal strips).
• Pull the protective backing off of the tape and adhere
the multiplex board to the clean surface.
• Align the Double-Minitramp to the multiplex board and set
it at the specified height relative to the floor (not the
wooden board).
©2021 EUROTRAMP - WINAM- 84 961610202 - info@eurotramp.com.vn
2
3
4
•
•
•
Parts list:
• 12 mm multiplex board, 3-part with puzzle
connection: 2x 112,3x185 cm + 1x 116,4x185 cm =
total 341x185 cm (Fig.1)
• 8 pc. Mounting block type 1 (Fig. 2)
• 4 pc. Mounting block type 2 (Fig. 3)
• 76 pc. Wood screws 3.5*25 (Fig. 4)
• 5 m² double-sided tape (z.B. 4*50 mm roll of 25 m
EAN 4042448388704)
Check the chain tension and adjust as necessary.
Screw 2 pc. type 1 mounting blocks onto the front and
rear feet from above as pictured. The foot protector of the
trampoline should be surrounded as closely as possible
without play.
Use the type 2 mounting blocks to fix the centre feet to
the front and rear.
