Silverline 140810 Manual

Welding Goggles Clear / No. 5 Green
FR Lunettes de soudeur
DE Schweißerbrille
ES Gafas para soldar
IT Occhiali di protezione per saldatura
NL Lasbril
PL Okulary spawalnicze
The rating plate on your tool may show symbols. These represent important information about the product or instructions on its use. / La plaque signalétique figurant sur votre produit peut présenter des symboles. Ces symboles constituent des informations importantes relatives
au produit ou des instructions concernant son utilisation. / Auf dem Typenschild des Werkzeugs sind möglicherweise Symbole abgebildet. Sie vermitteln wichtige Informationen über das Produkt oder dienen als Gebrauchsanweisung. / Los siguientes símbolos pueden aparecer
en la placa de características de su herramienta. Estos símbolos representan información importante sobre el producto o instrucciones relativas a su uso. / La targhetta sul vostro prodotto può mostrare simboli. Questi rappresentano informazioni importanti riguardanti il prodotto
o istruzioni sul suo utilizzo. / Op het typeplaatje van uw product kunnen symbolen voorkomen. Deze vertegenwoordigen belangrijke informatie met betrekking tot het product of instructies met betrekking tot het gebruik ervan. / Tabela znamionowa zawiera symbole dotyczące
Wear hearing protection
Wear eye protection
Wear breathing protection
Wear head protection
Wear hand protection
Conforms to relevant
legislation and safety
Read instruction manual
Manual available online
1883
Notified body number
0321
Approved body number
EN
Specification
Materials .................. Ocular safety plate:....Polycarbonate
........................... Welding filter:............Polycarbonate
........................... Frame:..........................PVC / ABS
Standards: .............................................EN 166:2001, EN 169:2002, EN 175:1997
PPE Regulation 2016/425/EU
Regulation 2016/425 on personal protective equipment as brought into UK law and amended
For Declaration of Conformity please visit www.silverlinetools.com
Markings
• The eye and face protection may be marked on both frame and lens
• If markings are not the same, the lowest marking must be used as the rating
Marking on the Ocular safety plate Explanation
Silverline Manufacturer's identification
1 Optical Class
F Protection against high speed particles in low
energy impacts
CE CE certification
UKCA United Kingdom Conformity Assessed
Marking on the Goggle frame Explanation
Silverline Manufacturer's identification
EN 166 Conforms to EN 166:2001
F Protection against high speed particles in low
energy impacts
CE CE certification
UKCA United Kingdom Conformity Assessed
Marking on the Welding filter Explanation
5 Scale number
Silverline Manufacturer's identification
1 Optical Class
F Protection against high-speed particles in
Medium-energy impacts
CE CE certification
UKCA United Kingdom Conformity Assessed
Description of Symbols / Description des symboles / Symbolerklärung / Descripción de los símbolos
Descrizione dei simboli / Beschrijving van de symbolen / Opis symboli
produktu. Stanowią one istotne informacje o produkcie lub instrukcje dotyczące jego stosowania.
EN FR
Gehörschutz tragen
Port de protections auditives
Schutzbrille tragen
Port de protections oculaires
Port de protections respiratoires
Atemschutz tragen
Port du casque
Kopfschutz tragen
Port de gants Schutzhandschuhe tragen
Conforme aux réglementations Erfüllt die einschlägigen
et aux normes de sécurité Rechtsvorschriften und
standards pertinentes Sicherheitsnormen
Bedienungsanleitung sorgfältig
Lire le manuel d'instructions
Manuel d'instructions Gebrauchsanweisung online
disponible en ligne verfügbar
Caution! Attention ! Achtung, Gefahr!
Kennzeichen der benannten
Numéro de l'organisme notifié
Kennzeichen der
Numéro de l'organisme agréé
Zulassungsstelle
WARNING: If protection against high speed particles at extremes of temperature is required
then the user should select eye protection marked with the letter 'T' immediately after the impact
rating letter. If the letter 'T' is not present, then the eye protector should only be used for high
speed particles at room temperature.
Selecting Eye Protection for Welding
Great care should be taken when selecting personal protective equipment for welding. The
information supplied in this sheet is basic information only and more information and training
may be required for this product's effective use.
Consider the factors including the following when selecting PPE for welding:
• The position of the operator in relation to the flame or the arc
• Ambient work area lighting
• Operator limitations and preferences
Suitable gas welding tasks for filters marked with scale number 5
Task
Gas and braze welding
Oxygen cutting
Note: These goggles are not suitable for arc welding except for low current micro-plasma
applications.
Safety Instructions
For your own protection please read and thoroughly understand all safety instructions before
use.
Keep these instructions with the product for future reference. Ensure all people who use this
product are fully acquainted with these safety instructions.
• This product is designed for eye protection but is not unbreakable.
• Never alter or modify this product.
• A damaged lens reduces vision and protection and should be replaced immediately.
• It is the responsibility of the user to acquaint themselves with the hazards to be encountered
and select the correct level of eye protection for use in the hazardous area.
• The materials that come into contact with skin may cause allergic reactions to susceptible. If a
reaction occurs, leave the area, remove the goggles and seek medical advice.
• This product will only provide eye protection. If necessary, select other safety wear
appropriate for the task.
WARNING: Wearing spectacles under safety glasses increases the risk of impacts being
transmitted by the goggles
WARNING: These goggles are designed for protecting the eye with the following uses; gas,
plasma, oxyacetylene or oxy-fuel welding, cutting, brazing, soldering and grinding. They are fitted
with a shade 5 filter which will not provide eye protection for more intense uses including most arc
welding. Check suitability before use.
• Ensure the Welding Filter is in place over the clear lens before you carry out any welding or
similar procedure.
WARNING: Filters made of toughened mineral glass may only be fitted in conjunction with an
additional clear backing lens.
DE ES
Lleve protección auditiva Indossare una protezione acustica
Lleve protección ocular Indossare una protezione per gli occhi
Lleve protección respiratoria Indossare una protezione respiratoria
Lleve un casco de seguridad Indossare un casco protettivo
Lleve guantes de seguridad Indossa una protezione per le mani
Conforme a las normas de
Conforme agli attuali standard
seguridad y la legislación
legislativi e di sicurezza
correspondiente
Lea el manual de
Leggere il manuale delle istruzioni
lesen instrucciones
Manual disponible online Manuale disponibile online
¡Peligro! Attenzione!
Número de organismo
Numero di organismo notificato
Stelle notificado
Número de organismo
Numero dell'organismo autorizzato
autorizado
Gas flow in Ltr/h (q)
70 < q ≤ 200
900 < q ≤ 2000
IT NL
Należy nosić środki ochrony słuchu
Draag gehoorbescherming
Należy nosić okulary ochronne
Draag een veiligheidsbril
Należy nosić środki ochrony dróg
Draag een stofmasker
Draag een veiligheidshelm
Należy używać kasku ochronnego
Draag handschoenen Należy nosić rękawice ochronne
Voldoet aan de Urządzenie zgodne z odpowiednimi
relevante wetgeving en przepisami i normami
veiligheidsnormen bezpieczeństwa
Należy w całości przeczytać instrukcję
Lees de handleiding
Handleiding online
Instrukcja obsługi dostępna online
beschikbaar
Voorzichtig!
Aangemelde instantie
Numer jednostki notyfikowanej
nummer
Erkende instantie nummer Numer organu zatwierdzającego
Intended Use
Filtered welding goggles with polycarbonate lenses, flexible frames and elasticated strap for light
duty welding.
Note: This eye protection is designed for your personal safety and must be worn for the duration
of exposure to hazards.
Note: For adult use only.
Maintenance
General inspection
• Check that lenses and frame are in good condition before use.
• Carefully inspect welding filters before each use. Cracked, pitted or scratched filter glass or
protection plates can seriously impair protection and reduce vision. Check for cracks in the
shield and look for light leaks. All damaged components must be replaced before the goggles
may be used.
• Maintenance and repairs not covered by this manual must be carried out by an authorised
Silverline service centre.
Cleaning
• Do not clean with abrasive materials. Clean with warm soapy water and dry with soft cloth.
Storage
• Store carefully in a secure, dry place out of the reach of children.
Disposal
At the end of its service life, this product must be disposed of according to local laws and
regulations.
• DO NOT dispose of welding equipment with household waste. Contact your local waste disposal
authority for information on the correct way of disposal.
• DO NOT dispose of welding lenses with household waste. DO NOT incinerate.
Contact
Legal Manufacturer: Toolstream Ltd
For technical or repair service advice, please contact the helpline on (+44) 1935 382 222
Web: www.silverlinetools.com
UK Address: Toolstream Ltd, Boundary Way, Lufton Trading Estate, Yeovil, Somerset BA22 8HZ,
United Kingdom
Approved body number: 0321
Approved body: SATRA Technology Centre, Wyndham Way, Telford Way, Kettering,
Northamptonshire, NN16 8SD, United Kingdom
EU Address: Toolstream B.V., Hogeweg 39, 5301 LJ Zaltbommel, The Netherlands
Notified body number: 1883
Notified body : ECS GmbH – European Certification Service, Augenschutz und Persönliche
Schutzausrüstung, Laserschutz und Optische Messtechnik, Hüttfeldstraße 50, 73430 Aalen,
Germany
silverlinetools.com
140810
Version date: 18.01.2024
