Techno THP387 Manual

TH387
IP68 3bar
MADE IN ITALY
TH387
Installazione a pannello
Panel-mounting installation
2-3-4-5 POLES
Plug a parete
Plug panel-mounted
2
4
PLUG
Techno s.r.l. Via Bancora e Rimoldi, 27 - 22070 Guanzate (CO) ITALY
tel +39 031 976445 fax +39 031 976680 web www.techno.it email info@techno.it
1
20mm
3
Ø 7.0 ÷ 9.0 mm
Ø 9.0 ÷ 12.0 mm
ADAPTER HOLE
Ø 9.0 mm
≤ Ø 6.0 ÷ 7.0 mm
Versione perforazione isolante
Piercing terminals version
Code: THP.XXX.XXX
2-3-4-5
POLES
1 1
2 2
3 3
Versione a vite standard
Screw terminals
4 4
Code: THB.XXX.XXX (THR.XXX.XXX)
5 5
For further information please refer to product data sheet on our web-site www.techno.it
2-3-4-5
POLES
6mm
1 1
2 2
3 3
SOCKET
4 4
5 5
3
.a
3
.c
5
20mm
No sguainatura
No unsheathing
6mm
20mm
Versione perforazione isolante
Piercing terminals version
Code: THP.XXX.XXX
20mm
No sguainatura
No unsheathing
Versione a vite standard
Screw terminals
Code: THB.XXX.XXX (THR.XXX.XXX)
6mm
20mm
3
.b
3
.d
Chiave speciale di fissaggio rapido
Quick-fixing special tool
