Important Safety Instructions

When using your telephone equipment, basic safety precautions should always be followed
to reduce the risk of fire, electric shock and injury, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol
cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water (for example, near a bath tub, kitchen sink or
swimming pool).
5. Do not place this product on an unstable surface, such as a table, shelf, or stand.
The product may fall, causing serious damage.
6. Slots and openings in the back or bottom of the Base Unit and Handset are provided
for ventilation. To protect them from overheating, these openings must not be
blocked by placing the product on a soft surface such as a bed, sofa or rug. This
product should never be placed near or over a radiator or heat register. This
product should not be placed in any area where proper ventilation is not provided.
7. This product should be operated only from the type of power source indicated on
the marking label. If you are not sure of the type of power supply in your home, consult
your dealer or local power company.
8. Do not allow anything to rest on the power cord. Do not install this product where
the cord may have anyone walking on it.
9. Never push objects of any kind into this product through slots in the Base or Handset
as they may touch dangerous voltage points or short out parts that could result in
a risk of fire or electric shock. Never spill liquid of any kind on the product.
10. To reduce the risk of electric shock, do not disassemble this product, but take it to
an authorized service facility. Opening or removing parts of the Base or Handset
other than specified access doors may expose you to dangerous voltages or other
risks. Incorrect reassembling can cause electric shock when the product is
subsequently used.
11. Do not overload wall outlets and extension cords as this can result in the risk of fire
or electric shock.
12. Unplug this product from the wall outlet and refer servicing to an authorized service
facility under the following conditions:
A. When the power supply cord or plug is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions, as
improper adjustment of other controls may result in damage and often requires
extensive work by an authorized technician to restore the product to normal
operation.
E. If the product has been dropped and the Base and/or Handset has been damaged.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the gz 2438 and is the answer not in the manual?

Questions and answers

Related Manuals for VTech gz 2438

Summary of Contents for VTech gz 2438

  • Page 1: Important Safety Instructions

    Important Safety Instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product.
  • Page 2 15. Only put the Handset of your telephone next to your ear when it is in normal talk mode. WARNING: To insure your safety from possible electric shock, only use the enclosed VTech Audio Patch Cable to record custom ring tones. Do NOT leave the Audio Patch Cable attached to the Handset while charging in its cradle.

  • Page 3: Before You Begin

    2. Base Unit 3. Color Handset and Base Platesr 4. AC Power Adapter 5. Belt Clip To purchase replacement batteries, call VTech Communications Inc. at 1-800-595-9511. In Canada, call VTech Telecommunications Canada Ltd. at 1-800-267-7377. Handset AC Power Adapter User’s Manual 6.

  • Page 4: Getting Started

    Setup Connecting Power to Base Unit Choose a location for the base near an electrical outlet and a telephone jack. This phone requires a modular tele- phone jack and a standard electrical outlet (110V AC) not controlled by a wall switch. Plug the AC power adap-...

  • Page 5: Check For Dial Tone

    ON. You should hear a dial tone. Tone/Pulse Selection Your gz 2438 is preset for tone dialing. See Telephone Operation for details. CAUTION: Use only the VTech power supply provided with your telephone. IMPORTANT! FOR MAXIMUM PERFORMANCE OF YOUR CORDLESS TELEPHONE SYSTEM: 1.

  • Page 6: Basic Operation

    Handset Features (CID) • When phone is not in use, press to display Caller ID information. • During a call, press to decrease listening vol- ume. A double beep will sound when you reach the lowest setting. ON/FLASH • Press this button then dial the number to make a call.

  • Page 7: Base Features

    Base Features PAGE Press to page the Handset. Press again, press OFF, or place the Handset in its base to cancel the page. IN USE/CHARGING Indicator • Flashes when Handset is in use. • Flashes in unison with an incoming call’s ringing. •...

  • Page 8: Telephone Operation

    6. Press SELECT to save the displayed mode. Message Waiting Your gz 2438 is designed to work with most local and regional telephone service provider Voice Messaging systems, providing alerts on both the Handset and Base Unit when new messages are received.

  • Page 9: Set Language

    Telephone Operation You can retrieve your voicemail messages from any telephone. If the indicators remain on after all new messages have been reviewed, you can turn them off manually: 1. Make sure the Handset is OFF. 2. Press PROG. 3. Press until the screen displays MESSAGES WAITING.

  • Page 10: Display Screen Messages

    There is a call coming in. The Handset is waiting for dial tone. The Handset is in use. You have recieved telephone company voicemail. The Base is paging the Handset. There is a call on hold. The battery needs to be recharged.

  • Page 11: Speed Dial

    Speed Dial You can store as many as nine telephone numbers with names (up to 15 characters and 24 digits in each location) you dial frequently into the Speed Dial memory locations you assign in the Handset. NOTES: 1. The entries you store in Speed Dial memory will be marked 01 through 09 in the telephone directory.

  • Page 12: Edit A Number/Name Stored In The Speed Dial Memory

    Speed Dial -OR- Press REDIAL/PAUSE to display the last number dialed. 8. Press SELECT or PROG. The screen displays DISTINCT RING? and the current setting. 9. Press to change the setting. Choose Y (for yes) if you wish the phone to alert you to calls from this number by changing to a distinctive ringing pattern after the first ring.

  • Page 13: Delete A Number/Name Stored In The Speed Dial Memory

    Speed Dial edit the Distinctive Ring and Animation setting. Follow steps 9 through 13 in Store a Number/Name in Speed Dial Memory. Delete a Number/Name Stored in Speed Dial Memory 1. Press and hold the memory location key (1 through 9) of the entry you wish to delete.

  • Page 14: Telephone Directory

    Telephone Directory This cordless phone can store 50 telephone numbers with names (including nine Speed Dial entries), each up to 15 characters for the name and 24 digits for the number. NOTE: Press OFF at any time to exit directory.

  • Page 15: Edit A Number/Name Stored In The Directory

    Telephone Directory 8. Press SELECT or PROG to confirm your selection. If you chose Y, the screen displays: NOTE: If you chose N, skip to Step 10. 9. The ringer name will blink. Press SELECT or PROG to confirm. The screen displays: 10.

  • Page 16: Delete A Number/Name Stored In The Directory

    Telephone Directory Delete a Number/Name Stored in the Directory 1. Press ). The screen displays DIRECTORY. 2. Press to scroll alphabetically through entries. -OR- Press the dial pad key for the first letter of the entry you want to delete.

  • Page 17: Caller Id Operation

    For each call that comes in, the screen displays the following information between the first and second rings: • Your caller’s name (up to 15 letters are sent by your telephone company). • The caller’s area code and telephone number.

  • Page 18: Store A Call History Record In The Directory

    Caller ID Operation 4. Press SELECT again. The number is automatically dialed. -OR- When the number is correctly displayed for dialing, press ON. Store a Call History Record in the Directory 1. Locate the record in the call history you want to store in the directory. 2.

  • Page 19: Recordable Ringer

    Recordable Ringer In addition to four traditional ringer options and ringer OFF, your gz 2438 Handset has five musical ringers, plus the option for you to record another 2 personal ringers, using the Ringer Recording feature. Traditional Ring Options: Pre-programmed Melodies: Recordable Ringer You can record your personal ringers with either the provided Audio Patch Cord or with the Handset microphone.

  • Page 20: Headset Operation

    Headset, which is compatible with the gz 2438. For best results, use a VTech 2.5mm headset. To purchase a Headset, call VTech Customer Service at 1-800-595-9511. Once you have a compatible 2.5mm Headset, locate the Headset Jack on the gz 2438 Handset.

  • Page 21: Additional Information

    In Case of Difficulty If you have difficulty operating your phone, the suggestions below should solve the problem. If you still have difficulty after trying these suggestions, call VTech Communica- tions at 1-800-595-9511. In Canada, call VTech Telecommunications Canada Ltd. at 1-800-267-7377.
  • Page 22 You hear other calls while using your phone • Disconnect your Base Unit from the telephone jack, and plug in a regular telephone. If you still hear other calls, the problem is probably in your wiring or local service. Call your local telephone company.

  • Page 23: Maintenance

    Avoid water Your telephone can be damaged if it gets wet. Do not use the Handset outdoors in the rain, or handle it with wet hands. Do not install your Base Unit near a sink, bathtub, or shower.

  • Page 24: Warranty Statement

    3. Product to the extent that the problem experienced is caused by signal conditions, network reliability or cable or antenna systems; or 4. Product to the extent that the problem is caused by use with non-VTech electrical accessories; or 5. Product whose warranty/quality stickers, Product serial numbers plates or electronic serial numbers have been removed, altered or rendered illegible;...
  • Page 25 • If the Product failure is not covered by this limited warranty, or proof of purchase does not meet the terms of this limited warranty, VTech will notify you and will request that you authorize the cost of repair prior to any further repair activity. You must pay for the cost of repair and return shipping costs for the repair of Products that are not covered by this limited warranty.

  • Page 26: Fcc, Acta And Ic Regulations

    This equipment is compatible with inductively coupled hearing aids. Should you experience trouble with this telephone equipment, please contact: VTech Communications Inc. CUSTOMER SERVICE at 1-800-595-9511. In Canada, call VTech Telecommunications Canada Ltd. at 1-800-267-7377 for repair/warranty information. The telephone company may ask you to disconnect this equipment from the line network until the problem has been corrected.
  • Page 27 2. Connection and use with the nationwide telephone network The plug and jack used to connect this equipment to the premises wiring and the telephone network must comply with the applicable Part 68 rules and technical requirements adopted by ACTA.
  • Page 28 The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of all the devices does not exceed five.

  • Page 29: The Rbrc

    RBRC centers. Please call 1-800-8-BATTERY™ for information on Ni-Cd battery recycling and disposal bans/restrictions in your area. VTech’s involvement in this program is part of its commitment to protecting our environment and conserving natural resources. RBRC ®...

  • Page 30: Technical Specifications

    Technical Specifications FREQUENCY CONTROL Crystal controlled PLL synthesizer TRANSMIT FREQUENCY Base: 2410.2 - 2418.9 MHz Handset: 912.75 - 917.10 MHz RECEIVE FREQUENCY Base: 912.75 - 917.10 MHz Handset: 2410.2 - 2418.9 MHz CHANNELS 30 Channels NOMINAL EFFECTIVE RANGE Maximum power allowed by FCC and IC. Actual operating range may vary accord- ing to environmental conditions at the time of use.
  • Page 31 VTECH TELECOMMUNICATIONS LTD. A member of THE VTECH GROUP OF COMPANIES. Distributed in the U.S.A. by VTech Communications, Inc.; Beaverton, Oregon, 97008. Distributed in Canada by VTech Telecommunications Canada Ltd., 200-7671 Alderbridge Way, Richmond, B.C. V6X 1Z9. Copyright 2004 for VTECH TELECOMMUNICATIONS LTD.

  • Page 32: Table Of Contents

    Removable Face Plate and Base Plates ... 5 Basic Operation ... 6 Handset Features ... 6 Base Features ... 7 Telephone Operation ... 8 Set Handset Ringer Style ... 8 Set Date and Time ... 8 Set the Dial Mode ... 8 Message Waiting ...
  • Page 33 AND THE US VIRGIN ISLANDS. NO DELIVERY TO PO BOXES OR APO ADDRESSES. METHOD OF PAYMENT: DO NOT SEND CASH CHECK MASTERCARD Checks and Money Orders should be made payable to VTech Communications, Inc. BILLING INFORMATION CREDIT CARD # _________________________________________________________ EXPIRATION DATE ____________________ SECURITY CODE* ____________________ CARDHOLDER’S SIGNATURE _______________________________________________...
