CIS VCC-12CL4M Product Specification & Operational Manual

Camera link i/f 12m pixels cmos b/w camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Rev.905-0109-01
Camera Link I/F
12M Pixels CMOS
B/W Camera
VCC-12CL4M
Product Specifications
& Operational Manual
CIS Corporation
©2017 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-12CL4M and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VCC-12CL4M

Summary of Contents for CIS VCC-12CL4M

  • Page 1 Rev.905-0109-01 Camera Link I/F 12M Pixels CMOS B/W Camera VCC-12CL4M Product Specifications & Operational Manual CIS Corporation ©2017 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    User Data SAVE/Read-out Function ......................... 29 11.1. Save User Data ............................29 11.2. Reading Out of User Data ........................30 Factory Settings ............................. 30 Sensor Optical Axis Accuracy .......................... 31 Dimensions ..............................32 Case for Indemnity ............................33 ©2017 CIS Corporation. All rights reserved.
  • Page 3 VCC-12CL4M Rev.905-0109-01 CMOS Pixel Defect ............................33 Product Support ............................33 Ordering Information ............................. 33 Licensing ..............................33 ©2017 CIS Corporation. All rights reserved.

  • Page 4: Handling Precautions

    [About heat dissipation] For heat dissipation, CIS recommends M42 Mount and F Mount Lens to be used with VCC-12CL4M by attaching conversion rings. Installing the camera to a heat radiating metal by fixing its front with 4 x M4 screws is also recommended.

  • Page 5: Product Outline

    Rev.905-0109-01 Product Outline VCC-12CL4M is a Camera Link interfaced and 12M resolution B/W camera module. 12.29M pixels, 1.1 type (diagonal length 17.6mm) B/W CMOS sensor is utilized. Entire pixels can be read out at 1/53s with Full Configuration output. Features □Global shutter CMOS sensor...

  • Page 6: Specifications

    (100G) for ±X,±Y, and ±Z, 6 directions. (21) Operational environment Operation 5 ~ +45℃ Humidity 20 ~ 80%RH with no condensation guaranteed temperature (22) Storage environment -25 ~ +60℃ Humidity 20 ~ 80%RH with no condensation ©2017 CIS Corporation. All rights reserved.

  • Page 7: Camera Input And Output Signals Specifications

    (Condition: Gain 0dB) +5.0V( VCC) 100Ω FVAL Output LVAL Output DVAL Output HD74LV1GT32 ACME(RENESAS) Exposure Output Voh:3.8V(Min) Vol:0.55V( Max) 100Ω Trigger Input HD74LV1GT14 ACME(RENESAS) Vt-:0.5(Min) Vt+:1.9V(Max) IO Interface of 12pins Circular connector at rear ©2017 CIS Corporation. All rights reserved.

  • Page 8: Cmos Spectral Response

    4.3. CMOS Spectral Response ※The lens characteristics and illuminant characteristics are excluded. 4.4 Video Output Format (1) 2tap Base Configuration mode : 13.324fps 4096pixel ・・・ (2) 4tap Medium Configuration mode : 26.674fps 4096pixel ・・・ ©2017 CIS Corporation. All rights reserved.
  • Page 9 VCC-12CL4M Rev.905-0109-01 (3) 8tap Full , 8tap10bit Configuration mode : 53.294fps 4096pixel ・・・ (4) 10tap8bit Configuration mode : 62.984 fps 4100pixel ・・・ ©2017 CIS Corporation. All rights reserved.

  • Page 10: Camera Function Settings

    Output image horizontal flip Normal When in operation, the cursor is reset Horizontal flip to (0, 0). Output image vertical flip Normal When in operation, the cursor is reset Vertical flip to (0, 0). ©2017 CIS Corporation. All rights reserved.
  • Page 11 Indicate only the list of the registered data by the user. 3 at set up Indicate the registered number of the defect pixels per reed. 4 at set up Line up and indicate the registered number of the defect pixels per reed. ©2017 CIS Corporation. All rights reserved.

  • Page 12: The List Of Preset Shutter

    The maximum setting value: 200ms (approximate value) ・ ※With long exposure setting, bright spot may be noticeable. Setting unit: Per 1μs (approximate value) ・ ※Slight differences may occur since it is generated by 74.25MHz clock. ©2017 CIS Corporation. All rights reserved.

  • Page 13: Notes For Function Settings

    ※ When gain is set to over +36dB, image quality deterioration is inevitable. Please evaluate first. External Connector Pin Assignment 6.1. 12pins Circular Connector HR10-10R-12PA(73) (HIROSE) or equivalent Pin No. Description Power Input (DC+12V) LVAL Output FVAL Output Exposure Output DVAL Output TRIGGER Input ©2017 CIS Corporation. All rights reserved.

  • Page 14: Camera Link Connector 12226-1100-00Pl (Sumitomo 3M)

    ※ Please note that there is a mode that the power consumption exceeds the standard value of power feeding (4.0W). We recommend to feed power via both cables CL1 and CL2 when using PoCL, or to feed power via 12pins circular connector. ©2017 CIS Corporation. All rights reserved.

  • Page 15: Timing Chart

    Effective Line Video Out FVAL Out LVAL Out DVAL Out V Blanking : 62H Effective Line : 3000H Appr 1Frame = 3062H 56Ｈ SP Out(Exposure Out) Exposure Time 1H = 24.512us 2Tap Configuration mode :13.324fps ©2017 CIS Corporation. All rights reserved.

  • Page 16: Horizontal Sync. Timing (4Tap Configuration Mode)

    Video Out FVAL Out LVAL Out DVAL Out V Blanking : 62H Effective Line : 3000H Appr 1Frame = 3062H 56Ｈ SP Out(Exposure Out) Exposure Time 1H = 12.256us 4Tap Configuration mode : 26.647fps ©2017 CIS Corporation. All rights reserved.

  • Page 17: Horizontal Sync. Timing (8Tap Configuration Mode)

    Video Out FVAL Out LVAL Out DVAL Out V Blanking : 62H Effective Line : 3000H Appr 1Frame = 3062H 56Ｈ SP Out(Exposure Out) Exposure Time 1H = 6.128us 8Tap Configuration mode : 53.294fps ©2017 CIS Corporation. All rights reserved.

  • Page 18: Horizontal Sync. Timing (10Tap Configuration Mode)

    Video Out FVAL Out LVAL Out DVAL Out V Blanking : 62H Effective Line : 3000H Appr 1Frame = 3062H 56Ｈ SP Out(Exposure Out) Exposure Time 1H = 5.185us 10Tap Configuration mode : 62.984fps ©2017 CIS Corporation. All rights reserved.

  • Page 19: Fixed Trigger Shutter Mode

    Trigger input during exposure time shall be ignored in the camera. (Refer to (A) in the drawing below). □ Note that a trigger shorter than 1 frame cycle shall not be used. ©2017 CIS Corporation. All rights reserved.

  • Page 20: Fast Fixed Trigger Shutter Mode

    □ There is an exposure time period for approx. 14.26μs at the edge right after exposure output. Trigger input while outputting images cannot be accepted. □ Trigger input during exposure time and video outputting shall be ignored in the camera. (Please refer to (A) and (B) in the drawing below). ©2017 CIS Corporation. All rights reserved.

  • Page 21: Pulse Width Trigger Shutter Mode

    Triggers can be accepted while outputting video output images. However, please be noted that a trigger signal to □ start the next video outputting should not be input before completion of outputting the prior images. (Please refer to (A) in the drawing below). ©2017 CIS Corporation. All rights reserved.

  • Page 22: Fast Pulse Width Trigger Shutter Mode

    There is an exposure time period for approx. 14.26μs at the edge right after exposure output. □ □ Trigger input during readout time shall be ignored in the camera. (Please refer to (A) in the drawing below). ©2017 CIS Corporation. All rights reserved.
  • Page 23 Exposure Out Exposure Time LVAL Out DVAL Out FVAL Out Effective Line : 3000H Exposure Time Delay① Exposure Time Delay② Trigger input ignore period TRIG IN ① ② Exposure Out (SP Out) Exposure time delay ©2017 CIS Corporation. All rights reserved.

  • Page 24: Partial Scan Mode

    Partial effective lines 1 + Partial effective lines 2 + ・・・ + Partial effective lines 8 Note that sum total of partial effective line count from 1~8 (except V blanking lines) has to be less than 3000. V blanking lines at partial mode is 62H. ©2017 CIS Corporation. All rights reserved.
  • Page 25 *Especially at fixed trigger shutter mode and pulse width trigger shutter mode, input a dummy trigger □ first, and use the next trigger as an actual video signal. ©2017 CIS Corporation. All rights reserved.

  • Page 26: Serial Communication Function

    (4) Setting Examples 【Example of Get Command】 To get the information of the address 21 [Send] GU[sp]21[¥r] or[¥n] [Returned value] 50[¥r] [¥n] [Acquired data+Linefeed] [¥r]=CR(0x0D) [Returned value] [¥r] [¥n] [Linefeed] [¥n]=LF(0x0A) [Returned value] >[sp] [Prompt+Space] [sp]=Space(0x20) ©2017 CIS Corporation. All rights reserved.

  • Page 27: Pixel Defect Correction

    These data can be erased anytime. Pixel defect correction data for normal mode and for vertical flip mode are saved separately. □ (Pixel defect position and number are different at normal mode and at vertical flip mode). ©2017 CIS Corporation. All rights reserved.
  • Page 28 When 1 is specified, only newly detected white defects data will be added to the old data registered by that time. Even when the Additional Flag 0 is specified, the added data with the Address 101 would not be deleted.  ©2017 CIS Corporation. All rights reserved.
  • Page 29 3 kinds of lists can be indicated by parameters. Parameter 1: Entire lists, both ex-factory data, and the added and registered data by the users, are shown. Parameter 2: Only the list added and registered by the users is shown. ©2017 CIS Corporation. All rights reserved.

  • Page 30: User Data Save/Read-Out Function

    The maximum 4 of 1 byte (0~255 or 0x00~0xFF) data can be set with space partitions. If more numbers than the address were set, error would occur. 【Send】SU[sp]200[sp]Write Address[sp]Data[sp]Data[sp]Data[sp]Data [Note] Please make sure to insert [sp] one by one. 【Returned value】[¥r][¥n] 【Returned value】>[sp] ©2017 CIS Corporation. All rights reserved.

  • Page 31: Reading Out Of User Data

    Horizontal Flip of the Output Image Normal Vertical Flip of the Output Image Normal Defective Pixel Correction Serial Communication Baud Rate 9600baud Gain Shutter Vertical Partial Mode OFF (3000line) Factory setting for rear switch Power Selection CL side ©2017 CIS Corporation. All rights reserved.

  • Page 32: Sensor Optical Axis Accuracy

    VCC-12CL4M Rev.905-0109-01 13. Sensor Optical Axis Accuracy ©2017 CIS Corporation. All rights reserved.

  • Page 33: Dimensions

    VCC-12CL4M Rev.905-0109-01 14. Dimensions ©2017 CIS Corporation. All rights reserved.

  • Page 34: Case For Indemnity

    CIS Corporation, at its option, repairs or replaces it at no charge to you. Products out of warranty period will be subject to charge. CIS repairs the products as long as it is repairable. CIS shall be exempted from taking responsibility and held harmless for damages or losses incurred by the following cases.
