CIS VCC-HD3 Product Specification & Operational Manual

G-sdi/hd-sdi full hd cmos color
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VCC-HD3
Rev. 905-0051-00
English
3G-SDI/HD-SDI
FULL HD CMOS Color
VCC-HD3
Product Specifications
& Operational Manual
CIS Corporation
©2016 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-HD3 and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VCC-HD3

Summary of Contents for CIS VCC-HD3

  • Page 1 VCC-HD3 Rev. 905-0051-00 English 3G-SDI/HD-SDI FULL HD CMOS Color VCC-HD3 Product Specifications & Operational Manual CIS Corporation ©2016 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    11.2. Indication of OSD Menu ..........................21 11.3. OSD Menu..............................21 Factory Settings ............................... 27 Dimensions ..............................28 Cases for Indemnity (Limited Warranty) ......................29 CMOS Pixel Defect ............................29 Product Support ............................... 29 ©2016 CIS Corporation. All rights reserved.

  • Page 3: Handling Precautions

    Do not apply excessive voltage. (Use only the specified voltage.) Unstable or improper power supply  voltage may cause damages or malfunction of the camera assembly. Since VCC-HD3 is a highly-dense camera module, appropriate heat dissipation shall be considered.  We recommend using a metal base or others to install the camera.

  • Page 4: Product Outline

    VCC-HD3 Rev. 905-0051-Z00 Product Outline VCC-HD3 is a full HD color camera module utilizing a 1/1.8 type global shutter CMOS sensor. Video output 1080 60p/59.94p/50p (3G-SDI), 1080 60i/59.94i/50i/30p/29.97p/25p/24p/23.97p (HD-SDI), 720 60p/59.94p/50p (HD-SDI) are corresponded. Features CIS own designed Image Signal Processor, “Clairvu ”...

  • Page 5: Specifications

    *Same as MANUAL, shutter speed slower than 1/60s will be limited by the frame rate corresponding to the video output format. AUTO, AUTO (Outdoor), ATW, 7 different Preset, MANUAL, User Preset 1~5, and One Push (17) White balance adjustment Preset: range Daylight(5500K),Cloudy(6500K),Shade(8000K),Tungsten(3200K),Fluorescent(White), Fluorescent(Neutral White), Fluorescent(Daylight) ©2016 CIS Corporation. All rights reserved.
  • Page 6 Some 3G-SDI receivers correspond to either Level A or B, whereas other receivers correspond to both Levels, so please set the camera mode to match your 3G-SDI receiver. ©2016 CIS Corporation. All rights reserved.

  • Page 7: Part Names And Functions

    Connecting to such equipments may cause malfunction. ⑥ Screw Holes for camera installation 4 screw holes to install the camera. Please be noted that the depth of the front screw holes and the rear screw holes are different. ©2016 CIS Corporation. All rights reserved.

  • Page 8: External Connector Specifications

    φ3.5mm 4 poles (RS-232C) connector Model Name Pin No. Power(+5V) *For optional TXD(Camera) RXD(Camera) Connection of φ3.5 (4 poles) Connector (RS-232C) N.C. N.C. 9 p in D -S u b(f e m ale ) ©2016 CIS Corporation. All rights reserved.

  • Page 9: Genlock

    LTC IN terminal, it will be switched to the external time code. With this situation, if no signal is input into the LTC IN terminal, it starts self-running from the set time code. ･ Signal Format: SMPTE Time code Signal Level: 0.5 ~ 2[Vp-p] ･ ©2016 CIS Corporation. All rights reserved.

  • Page 10: Defective Pixel Correction

    How to execute “Defective Pixel Correction” Execute “INIT” to return to the factory settings. ・ Attach the bundled cap to the lens mount for light-blocking, then wait for about 5 seconds.. ・ Execute “Defective Pixel Correction” and SAVE. ・ ©2016 CIS Corporation. All rights reserved.

  • Page 11: Serial Communication

    To set 30 to the Command No.10 [Send] SU[sp]10[sp]30[¥r]or[¥n] [Returned value] [¥r] [¥n] [Line feed] [Returned value] >[sp] [Prompt + space] 【Example of SAVE Command】 [Send] SAVE[¥r]or[¥n] [Returned value] [¥r] [¥n] [Line feed] [Returned value] >[sp] [Prompt + space] ©2016 CIS Corporation. All rights reserved.

  • Page 12: Command List

    To set video format. 6: 1080i 60fps 7: 1080i 59.94fps 8: 1080i 50fps 9: 1080p 30fps 10: 1080p 29.97fps 11: 1080p 25fps 12: 1080p 24fps 13: 1080p 23.97fps 14: 720p 60fps 15: 720p 59.94fps 16: 720p 50fps ©2016 CIS Corporation. All rights reserved.
  • Page 13 Max > Min is set. 0x4D * Refer to 10.4. Quick Reference Matrix for Exposure time (77) Settings. [sec]×0x100000 1/25s ～ 1/13600s 0： Average 1： Center-Weighted Metering 2： Spot To set metering mode. Mode 3： Backlight Compensation ©2016 CIS Corporation. All rights reserved.
  • Page 14 ※Note 1: There may be gap (small differences) between the set shutter value and the actual shutter value. For the actual shutter value, please refer to Section 10.4.3. Actual Shutter Value limited by output format. ※Note 2: Flicker cancel function becomes invalid at 50fps, 25fps, 24fps, and 23.97fps regardless of its settings. ©2016 CIS Corporation. All rights reserved.
  • Page 15 To set R gain when WB mode is at Manual Red Gain 0～800(%) and at Preset. (Write Only) One Push 1: Trigger Start None To start operation when WB mode is at One Trigger Push. ©2016 CIS Corporation. All rights reserved.
  • Page 16 Noise Reduction To set the Noise Reduction. 1 : Noise reduction ON 0: Auto 1: Standard Color Correction To set color correction. 2: Fluorescent light 3: Tungsten lamp 0～7 Color Suppression To set color suppression. ©2016 CIS Corporation. All rights reserved.
  • Page 17 3: Magenta If the same color as the menu Select Color 4: Green color is specified, it will be an error, 5: Cyan because the selected letters 6: Yellow cannot be recognized. 7: White ©2016 CIS Corporation. All rights reserved.
  • Page 18 None None The letter strings such as 0.1 shall be 2: FPGA’s version responded. To start detection of pixel defects. Please refer to the Section 9, SDDW None Defective Pixel Correction, for the details. ©2016 CIS Corporation. All rights reserved.

  • Page 19: Quick Reference Matrix For Settings

    2965821 002D413D 50.797 34.117 3329021 0032CBFD 57.018 35.120 3736700 0039047C 64.000 36.124 4194304 00400000 71.838 37.127 4707947 0047D66B 80.635 38.130 5284492 0050A28C 90.510 39.134 5931642 005A827A 101.594 40.137 6658043 006597FB 114.035 41.141 7473400 007208F8 ©2016 CIS Corporation. All rights reserved.

  • Page 20: Shutter Settings

    000016C1 1/250 4194 00001062 1/350 2995 00000BB3 1/500 2097 00000831 1/725 1446 000005A6 1/1000 1048 00000418 1/1500 000002BB 1/2000 0000020C 1/3000 0000015D 1/4000 00000106 1/6000 000000AE 1/8000 00000083 1/9600 0000006D 1/11200 0000005E 1/13600 0000004D ©2016 CIS Corporation. All rights reserved.

  • Page 21: Actual Shutter Value Limited By Output Format

    1/6172 1/6800 1/6800 1/6794 1/7237 1/6412 1/7562 1/7555 1/8000 1/7562 1/8508 1/8306 1/8010 1/8003 1/8306 1/9600 1/9745 1/9736 1/9745 1/9745 1/9736 1/11200 1/11389 1/11379 1/11787 1/11389 1/11379 1/11787 1/13600 1/13701 1/13690 1/14911 1/13701 1/13689 ©2016 CIS Corporation. All rights reserved.

  • Page 22: How To Operate The Camera With Osd Function

    Select video format with button, ／ 1080i 60fps then push the CENTER button to confirm. 1080i 59.94fps 1080i 50fps 1080p 30fps 1080p 29.97fps 1080p 25fps 1080p 24fps 1080p 23.97fps 720p 60fps 720p 59.94fps 720p 50fps ©2016 CIS Corporation. All rights reserved.
  • Page 23 1/500 Shutter Value format. 1/600 ※Note 1 1/700 ※Note 2 1/840 ※Note 3 1/1000 1/1200 1/1400 1/1700 1/2000 1/2400 1/2800 1/3400 1/4000 1/4800 1/5600 1/6800 1/8000 1/9600 1/11200 1/13600 ©2016 CIS Corporation. All rights reserved.
  • Page 24 When a high luminance object is shot with DC iris function, hunting could occur under some conditions. ※Note 5: In such cases, adjust DC Iris Response Speed or Exposure Compensation Value to try to reduce it. ©2016 CIS Corporation. All rights reserved.
  • Page 25 One Push None Execute One Push WB with the CENTER Start button. Select the preset number with the Set Preset 1～5 button, and push the CENTER ／ Number button to save the current WB value. ©2016 CIS Corporation. All rights reserved.
  • Page 26 Tungsten lamp Color 0～7 To set color suppression. Suppression ON/OFF LTC ON/OFF. Set LTC Reset None To reset LTC with the CENTER button. ※Note 3：The values 0～200 can be set via serial command. ©2016 CIS Corporation. All rights reserved.
  • Page 27 To execute SAVE or NOT SAVE, then get back to the Enter None original screen. To call up the data of the selected preset number and Get Save Data 0～3 reflect it on the screen with the CENTER button. ©2016 CIS Corporation. All rights reserved.

  • Page 28: Factory Settings

    Manual Blue Gain Color Correction Standard Color Suppression Color Saturation Edge Enhancement Noise Reduction Contrast Standard Master Pedestal Pedestal(RGB) Color Balance (RGB) OSD Menu Color White OSD Select Color Cyan H Flip V Flip ©2016 CIS Corporation. All rights reserved.

  • Page 29: Dimensions

    VCC-HD3 Rev. 905-0051-Z00 Dimensions 935-0065-00 (Unit：㎜) ©2016 CIS Corporation. All rights reserved.

  • Page 30: Cases For Indemnity (Limited Warranty)

    CIS Corporation, at its option, repairs or replaces it at no charge to you. Products out of warranty period will be subject to charge. CIS repairs the products as long as it is repairable. CIS shall be exempted from taking responsibility and held harmless for damages or losses incurred by the following cases.
