CIS VCC-5CXP3R Product Specification & Operational Manual

Coaxpress i/f 5.3m cmos color (raw) camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VCC-5CXP3R
Rev. 905-0052-00
English
CoaXPress I/F
5.3M CMOS Color (RAW) Camera
VCC-5CXP3R
Product Specifications
& Operational Manual
CIS Corporation
©2017 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-5CXP3R and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VCC-5CXP3R

Summary of Contents for CIS VCC-5CXP3R

  • Page 1 VCC-5CXP3R Rev. 905-0052-00 English CoaXPress I/F 5.3M CMOS Color (RAW) Camera VCC-5CXP3R Product Specifications & Operational Manual CIS Corporation ©2017 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    Trigger Mode ..........................22 Burst Mode ..........................23 Index Mode ..........................24 Setting Items for Sequence Control ................... 25 Sequence Information Output ....................26 Dimensions ............................. 29 11.1 Optical Axis Accuracy ........................ 29 11.2 Camera Dimension........................30 ©2016 CIS Corporation. All rights reserved.
  • Page 3 VCC-5CXP3R Rev. 905-0052-00 Case for Indemnity (Limited Warranty) ..................... 31 ・ Product Support ............................31 ©2016 CIS Corporation. All rights reserved.

  • Page 4: Handling Precautions

    Do not disassemble the camera. The camera once disassembled shall be out of warranty.  Product Outline VCC-5CXP3R is a CoaXPress interfaced small Color camera utilizing a 1 type, 5.3M pixels CMOS image sensor. Features □ 29mm x 29mm x 55mm in size □...

  • Page 5: Specifications

    ※Performance guaranteed: All the specifications specified in this manual is guaranteed under performance guaranteed temperature. ※Operation guaranteed: All the camera functions operate normally under operation guaranteed temperature. (24) Storage Environment Storage Temperature: -25 ~ +60℃, Humidity: 20 ~ 80%RH with no condensation. ©2016 CIS Corporation. All rights reserved.

  • Page 6: Camera In/Output Signal Specifications

    FVAL, LVAL, 1 can be output. Uplink Trigger (After decode) 5V output 4.3 Spectral Response ※The lens characteristic and the illuminant characteristics are excluded. ※Please refer to RED, GREEN, and BLUE in the graph below. ©2016 CIS Corporation. All rights reserved.

  • Page 7: External Connector Pin Assignment

    Timing signals inside the camera can be output. Output signal can be set by LineSource at Digital IO Control. Please refer to the 8. Function Settings for the details. ・ 5.0V CMOS logic level output ・ Output voltage Low: 0.55Vdc (Max), High: 3.8Vdc (Min) ©2016 CIS Corporation. All rights reserved.

  • Page 8: Pins Trigger_In Circuit

    CXP-1. However, as long as you do not execute UserSetSave, the setting values will not be saved. If you wish to save the setting values, execute UserSetSave. Setting values will be saved to the memory in the camera and will operate with the saved settings at next start-up. ©2016 CIS Corporation. All rights reserved.

  • Page 9: Camera Operation Mode

    This command generates trigger in the camera, and captures 1 frame. Please note that this trigger does not have the time accuracy like the trigger generated by TriggerSource. Only valid Acquisition Control mode is TriggerSelectorAndActivation --- FrameStartRisingEdge Mode ©2016 CIS Corporation. All rights reserved.

  • Page 10: Internal Sync Mode (Free Run Mode)

    FVAL turns to “L” at the timing of the end of exposure. If the camera stops operating, or cannot output image data without malfunctions, please execute “SensorReset” command after quitting trigger input to start the operation again. ※If the camera does not start its operation, please execute the restoration of power. Device Control (Execute) SensorReset ©2016 CIS Corporation. All rights reserved.
  • Page 11 ※Please refer to Exposure delay time (A) in the timing chart below. ※ Delay time will depend on the settings of frame rate and exposure time, but will not fluctuate in a fixed condition. ©2016 CIS Corporation. All rights reserved.
  • Page 12 Video Out Exposure Out Exposure time Image Image Cxp Stream Idle Stream data Idle Stream data Idle Header Header LVAL FVAL Trigger input forbidden period Readout time Exposure delay time (A) Exposure delay time (B) ©2016 CIS Corporation. All rights reserved.
  • Page 13 Effective Line Effective Line Video Out Exposure Out Exposure time Image Image Cxp Stream Idle Stream data Idle Stream data Idle Header Header LVAL FVAL Readout time Exposure delay time (A) Exposure delay time (B) ©2016 CIS Corporation. All rights reserved.

  • Page 14: Function Settings

    When preset value is set, it will be reflected to the manual gain setting value. Magnification dB corresponding value PresetGainX Gain_x1 Gain_x1_5 x1.5 3.5dB Gain_x2 Gain_x3 9.5dB Gain_x4 12dB Gain_x6 15.6dB Gain_x8 18dB Manual gain ・Gain: Any preferred values from x1 to x32 can be set per x0.25. ©2016 CIS Corporation. All rights reserved.

  • Page 15: Exposure Time Settings

    Pattern7 4750 2370 2370 1160 1160 4750 2370 2370 1160 1160 8Bit 10Bit CXP1 CXP2 CXP3 CXP5 CXP6 CXP1 CXP2 CXP3 CXP5 CXP6 Subsampling 14190 7080 7080 3520 3520 14530 7260 7090 3630 3550 ©2016 CIS Corporation. All rights reserved.

  • Page 16: Roi (Region Of Interest)

    799.0 799.0 10bit 183.1 399.5 399.5 799.0 799.0 ・Information below in selected ROI area can be readout. ImageFormatControl Width Height OffsetX OffsetY ・Cutting out of ROI area is the center-standard of the image sensor. ©2016 CIS Corporation. All rights reserved.

  • Page 17: Sub-Sampling

    ・Please refer to the chart below for the frame rate at free run mode with sub-sampling operation. Configuration Frame rate (fps) 8bit 10bit CXP-1 64.6 57.8 CXP-2 138.6 135.4 CXP-3 138.6 138.6 CXP-5 277.1 270.4 CXP-6 277.1 277.1 ©2016 CIS Corporation. All rights reserved.

  • Page 18: Defective Pixel Correction

    VCC-5CXP3R Rev. 905-0052-00 8.5 Defective Pixel Correction CIS compensates the noticeable CMOS pixel defects found at the shipping inspection prior to our shipment. Defective pixel correction can be set to OFF. AnalogControl True DefectivePixelCorrection False 8.6 Shading Correction This is a function to correct the peripheral brightness lowering caused by the lens and others used.

  • Page 19: Indicator Led Lighting Control

    ROI or sub-sampling function while grabbing image. Please execute power restoration or Device Control --- SensorReset to revert camera to normal lighting condition. ©2016 CIS Corporation. All rights reserved.

  • Page 20: Camera Timing Output

    Please execute while the achromatic object is on the entire screen. We recommend you to execute is with approx. 50% of signal level. Red value, Green value, and Blue value after executed can be read out from BalanceWhiteOnePushGainRed and BalanceWhiteOnePushBlue. ©2016 CIS Corporation. All rights reserved.

  • Page 21: Sequence Control Function

    AcquisitionControl AquisitionMode [TriggerSelectorAndActivation] SequencerControl 【Sequence Operation Mode】 【シーケンス動作モード】 [SequencerActivation] Trigger Mode 　　トリガーモード FrameStartPredfined ◎ ◎ ◎ ◎ 　　インデックスモード Index Mode FrameStartIndexselector ◎ ◎ ◎ ◎ FrameBurstStartEdge Burst Mode 　　バーストモード FrameBurstStartLevel ◎ FrameBurstStartSoftware ©2016 CIS Corporation. All rights reserved.

  • Page 22: Basic Operation

    This mode shall be executed by equivalent of free run at internal sync. mode. Sequence shall be started by trigger, repeat count of Index will be sum up automatically by internal trigger, and the specified parameter set shall be applied to the camera. ©2016 CIS Corporation. All rights reserved.

  • Page 23: Trigger Mode

    ・The exposure time (①,②) for each frame shall be controlled by sequence parameter set which is set beforehand. ・Sequence performance will end after the sequence loop count of image output, and the performance will stop. ©2016 CIS Corporation. All rights reserved.

  • Page 24: Burst Mode

    ・The exposure time (①) and output frame time (②) for each frame shall be controlled by sequence parameter set and image size which are set beforehand. ・Sequence performance will end after the completion of sequence loop count of image output. After that, the performance will stop. ©2016 CIS Corporation. All rights reserved.

  • Page 25: Index Mode

    Index #0 Index #1 Index #2 Index #3 Index #１5 Applying param Applying param Applying param Applying param Applying param Sequence Index Parameter Index Number Combination of each Index RegisterModeIndexNumber Index Selector and parameter set ©2016 CIS Corporation. All rights reserved.

  • Page 26: Setting Items For Sequence Control

    : To set sequence control at the use of burst mode. ・FrameBurstStart ◇Shifting to sequence mode SequencerControl FrameStartPredefined FrameStartIndexSelector SequencerActivation FrameBurstStartEdge FrameBurstStartLevel FrameBurstStartSoftware : To set to start trigger mode and burst mode ・FrameStartPredefined : To set to start Index mode ・FrameStartIndexSelector ©2016 CIS Corporation. All rights reserved.

  • Page 27: Sequence Information Output

    To indicate loop count of executing Index no. RepeatNumberStatus To indicate loop count of executing sequence ※If the indication of loop count is set to infinite, the indication of max. loop count is 1023. LoopNumberStatus ©2016 CIS Corporation. All rights reserved.
  • Page 28 2bit at LSB side shall always be “00” at 10bit image. Index no. [3:0] pix0 “00” “0000” “00” Loop count[7:0] “00” pix1 “00” Loop count[9:8] “00” pix2 “00” “000000” Loop no.[7:0] “00” pix3 “00” Loop no.[9:8] “00” pix4 “00” “000000” ©2016 CIS Corporation. All rights reserved.
  • Page 29 The same value as Index Index0Count～Index15Count All 1 SequencerLoopCount ActiveIndexNumber ActiveIndexModeIndexNumber SequencerExposureTime 1000.0 (Selector 0-15) SequencerGain (Selector 0-15) TransportLayer CxpLinkConfiguration CXP_X1 ※The values of factory settings is the same as of those commands for UserSetDefault. ©2016 CIS Corporation. All rights reserved.

  • Page 30: Dimensions

    VCC-5CXP3R Rev. 905-0052-00 11 Dimensions 11.1 Optical Axis Accuracy ©2016 CIS Corporation. All rights reserved.

  • Page 31: Camera Dimension

    VCC-5CXP3R Rev. 905-0052-00 11.2 Camera Dimension ©2016 CIS Corporation. All rights reserved.
  • Page 32 If you use the product properly and discover a defect during the warranty period, and if that was caused by designing or manufacturing, CIS Corporation, at its option, repairs or replaces it at no charge to you. Products out of warranty period will be subject to charge. CIS repairs the products as long as it is repairable.
