Intelligent UV & OZONE Disinfection Case MINI
UVP301R
UVC Light germicidal system intends for use in general purpose
UVC LED
UV: 2.5-3h
O3: 15-16h
Output
MAX 18W
275nm UVC
4.5-5h
IP65
Type C
120
Center box
Irradiance: 380 W/cm²
226x182x92mm
60mg/m³
7.4V/4000 mAh
27ppm
Li-poly
Input
1.2kg
5V
Work light specifications
2A
Advertisement
Table of Contents
Related Manuals for UVPLUS UVP301R
Summary of Contents for UVPLUS UVP301R
- Page 1 Intelligent UV & OZONE Disinfection Case MINI UVP301R UVC Light germicidal system intends for use in general purpose UVC LED 275nm UVC Center box 60mg/m³ 7.4V/4000 mAh Irradiance: 380 W/cm² 27ppm Li-poly Input UV: 2.5-3h 4.5-5h IP65 226x182x92mm 1.2kg O3: 15-16h...
- Page 2 Product Features: • Double-effect disinfection combination, fully reflect the high efficiency of ULTRAVIOLET disinfection and 360° no blind angle of OZONE disinfection • The inner upper cover and bottom of disinfection case are respectively equipped with 4pcs UVC LEDs so as to realize the overall disinfection of articles •...
- Page 3 Operation Instruction: 1. Short press “ ” to start the machine. If not performing any operation after starting the machine, it will automatically switch off after 30 seconds for the energy conservation and environment protection. 2. Design of Hall Switch. If the screen displays “ ”...
- Page 4 Suggested Time for Disinfection 1. Time suggestion for ultraviolet disinfection: As for the ordinary small-sized articles, such as mobile phone, watch, pen, key chain etc., it is • suggested to disinfect for 1 minute As for the ordinary middle-sized articles, such as mask, milk bottle etc., it is suggested to disinfect for 2 •...
- Page 5 NOTES: 1. The design of this product based on IEC 62471:2006 Photobiological safety of lamps and lamp systems and other international standards 2. This product utilizes the ultraviolet rays LED , which emits UV-C rays with peak value wave length at 275nm to disinfect 3.
- Page 6 quickly reduce the ozone concentration in the equipment. The user must never open the cabinet doors before the device has completed the ozone disinfection operation (before the end of the timer countdown in the monitor) 15. Users are advised to equip users with ozone concentration detection instruments to regularly detect whether the leaked ozone value of the equipment exceeds the safe value: long term populated enclosed spaces, such as houses, apartments, hospitals and offices, ozone must be less than 0.1PPM in English.
- Page 7 5. The same conditions were tested on stainless steel, aluminum, gold-plated PIN needles, silicone, cotton pads, cotton and ABS plastics, and no significant decomposition was found 6. It is recommended to avoid ozone disinfection of brightly colored leather, silk and other items. Some highly aged items, such as natural rubber, are also recommended to not undergo ozone disinfection.
- Page 8 WARNING HARMFUL OZONE may be created by this product. Follow installation and operating instructions. WARNING UV-C emitted from this product. Avoid eye and skin exposure to unshielded product. Follow installation instructions and user manual. www.uvpluss.com AEC Lighting Solutions Co., Ltd Add.: 2548 Bao’an Highway, Jiading District, Shanghai 201801, China Tel.: 400-083-8757 www.aeclight-reel.com...
