Intelligent UV & OZONE Disinfection Box ULTIMATE
UVP101R
UVC Light germicidal system intends for use in general purpose
UVC LED
REV-ODS
Reverse Obstacle
Detection System
2cm
7.4V/2600 mAh
Sensor distance
1.2kg
275nm UVC
120°
UV: 3-3.5h
Li-ion
O3: 15-16h
Input
Output
5V
2A
MAX 11W
Center box
Hand-held
Irradiance:
Irradiance:
240 W/cm²
5000 W/cm²
3-4h
IP20
Type C
5mg/min
245x155x121mm
Work light specifications
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for UVPLUS ULTIMATE UVP101R
Summary of Contents for UVPLUS ULTIMATE UVP101R
- Page 1 Intelligent UV & OZONE Disinfection Box ULTIMATE UVP101R UVC Light germicidal system intends for use in general purpose Center box UVC LED 275nm UVC 120° Hand-held 5mg/min Irradiance: Irradiance: 240 W/cm² 5000 W/cm² REV-ODS Reverse Obstacle Detection System 7.4V/2600 mAh UV: 3-3.5h 3-4h IP20...
- Page 2 Product Features: • Double-effect disinfection combination, fully reflect the high efficiency of ULTRAVIOLET disinfection and 360° no blind angle of OZONE disinfection. • A multi-purpose box can meet the using demands of whole family along with realizing the classified disinfection and mobile disinfection.
- Page 3 Operation Instruction: • After starting the machine, please select language: short press “ ”to select English • Long press both of “ ” and “ ” for more than 5 seconds, the unit will automatically switch off and reset the language selection, you can reselect language in the next use I.
- Page 4 • If REV-ODS system detects the articles to be disinfected, unit will automatically resume the disinfection work, and screen will display “Disinfecting…”, and unit will continue the previous work for time countdown 4. In the progress of disinfection, double-click “ ”...
- Page 5 CAUTION: UVC-Equipment Damage Hazard. 1. Ultraviolet light can cause color shift or structural degradation of plastic materials 2. Ultraviolet light can cause color shift or structural degradation of resin materials 3. Ultraviolet light can cause color shift or structural degradation of leatherwear 4.
- Page 6 temperature, has a half-life of about 16 minutes in 1% of ozone solution and about 25 minutes in the air. 11. Pure ozone, if receives impact or friction, will explode and decompose. High concentrations of ozone when heated is also prone to explosion. But as long as care is taken, such accidents are rather rare. Ozone should not have high concentrations of flammable and explosive gases at the disinfection site when it is used for air disinfection.
- Page 7 2. If the equipment is stopped in the middle of the operation, the disinfection effect cannot be guaranteed, a new disinfection session from the start will be necessary. The reminding of damage about the disinfect objects: 1. The effects of ozone on a variety of substances vary considerably. Glass, stainless steel, butyl rubber, silicone, polycarbonate, and ABS plastics are better at ozone resistance, but nylon, zinc, glass-fibre-added plastics, and natural materials such as natural rubber and leather, are less resistant to ozone.
- Page 8 WARNING HARMFUL OZONE may be created by this product. Follow installation and operating instructions. WARNING UV-C emitted from this product. Avoid eye and skin exposure to unshielded product. Follow installation instructions and user manual. www.uvpluss.com AEC Lighting Solutions Co., Ltd Add.: 2548 Bao’an Highway, Jiading District, Shanghai 201801, China Tel.: 400-083-8757 www.aeclight-reel.com...
