Intelligent UV & OZONE Disinfection Bar ULTIMATE
UVP201R
UVC Light germicidal system intends for use in general purpose
UVC LED
REV-ODS
Reverse Obstacle
Detection System
2cm
7.3V/4000 mAh
Sensor distance
500 g
275nm UVC
UV: 2.5-3h
Li-ion
O3: 9-10h
Input
Output
5V
2A
MAX 11W
45°
Center Irradiance:
13500 W/cm²
4.5-5h
Type C
HBS
Human body
sensing system
5mg/min
Sensor angle 80°
Sensor distance 3m
IP20
38x33x320mm
Work light specifications
(In Bag)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for UVPLUS UVP201R
Summary of Contents for UVPLUS UVP201R
- Page 1 Intelligent UV & OZONE Disinfection Bar ULTIMATE UVP201R UVC Light germicidal system intends for use in general purpose (In Bag) Human body sensing system UVC LED 275nm UVC 45° Center Irradiance: 5mg/min Sensor angle 80° 13500 W/cm² Sensor distance 3m...
- Page 2 Product Features: • Dual-effect disinfection combination, fully reflects the high efficiency of ULTRAVIOLET disinfection and 360° no blind angle of OZONE disinfection • A multi-purpose machine that not only can be used independently by hand held, but also used in the confined space by being fixed with 3M adhesive and magnet accessories •...
- Page 3 Operation Instruction: I. In handheld mode, there are “handheld manual" mode and “handheld automatic" mode: 1. “handheld manual” mode • In any state, long press the hand-held mode switch for more than 1.5 seconds without releasing your hand, enter the hand-held manual mode •...
- Page 4 bar will automatically switch off 4. During the fixed-mode usage, the ozone disinfection will automatically stop after working for 60 minutes, and automatically start the ultraviolet UVC to perform the ozonolysis for 10 minutes. 5. If “ ” on the screen disappears and the time displays the green number 0, the disinfection work is completed.
- Page 5 NOTES: 1. The design of this product based on IEC 62471:2006 Photobiological safety of lamps and lamp systems and other international standards 2. This product utilizes the ultraviolet rays LED , which emits UV-C rays with peak value wave length at 275nm to disinfect 3.
- Page 6 found the problem. 16. Because of the instability of ozone, ultraviolet light accelerates the decomposition of ozone and converts it back to oxygen. After the ozone work is completed, the equipment switches to UV mode to quickly reduce the ozone concentration in the equipment. The user must never open the cabinet doors before the device has completed the ozone disinfection operation (before the end of the timer countdown in the monitor) 17.
- Page 7 60 minutes at a time using ozone concentrations of 35PPM. 4. After 10 tests of six different leather material colors samples, the results show color fading and hardening of the material, especially the brighter samples, whose fading was more pronounced 5.
- Page 8 WARNING HARMFUL OZONE may be created by this product. Follow installation and operating instructions. WARNING UV-C emitted from this product. Avoid eye and skin exposure to unshielded product. Follow installation instructions and user manual. www.uvpluss.com AEC Lighting Solutions Co., Ltd Add.: 2548 Bao’an Highway, Jiading District, Shanghai 201801, China Tel.: 400-083-8757 www.aeclight-reel.com...
