OWNER'S MANUAL
DRYER
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
RH10V9AV2W
MFL71712145
Rev.00_092222
Copyright © 2022 LG Electronics Inc. All Rights Reserved.
Scan the QR code to see the manual.
www.lg.com

Advertisement

Table of Contents
loading

Related Manuals for LG RH10V9AV2W

Summary of Contents for LG RH10V9AV2W

  • Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH RH10V9AV2W www.lg.com MFL71712145 Rev.00_092222 Copyright © 2022 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    Operation Overview..................16 Preparing the Clothes..................17 Control Panel ....................19 Programme Table ....................21 Extra Options and Functions ................25 SMART FUNCTIONS LG ThinQ Application ..................28 Smart Diagnosis ....................30 MAINTENANCE Cleaning after Every Dry .................31 Cleaning the Appliance Periodically ..............33 TROUBLESHOOTING Before Calling for Service................36...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risks.
  • Page 4 SAFETY INSTRUCTIONS • Children should be supervised to ensure that they do not play with the appliance. • Do not dry unwashed items in the appliance. • Fabric softeners, or similar products, should be used as specified by the fabric softener instructions. •...
  • Page 5 SAFETY INSTRUCTIONS could result in fire. Remove clothes immediately after drying, and then hang or lay the clothes flat to cool. • This appliance is intended to be used in household only. Maximum Capacity • The maximum capacity in some cycles for clothes to be dried is 10 kg (Dry).
  • Page 6 SAFETY INSTRUCTIONS • This appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on the opposite side to that of the appliance, in such a way that a full opening of the appliance door is restricted.
  • Page 7 Improper use can cause fire or explosion. • In case of flood, disconnect the power plug and contact the LG Electronics customer information centre. • Do not push down on the appliance door when it is open.
  • Page 8 SAFETY INSTRUCTIONS • Dispose of all packaging materials (such as plastic bags and styrofoam) away from children. The packaging materials can cause suffocation. • Remove the door before disposing of or discarding this appliance to avoid the danger of children or small animals getting trapped inside.

  • Page 9: Installation Parts And Specifications

    Front View Water Container Control Panel Door Drain Tube Available Accessories Please contact LG Electronics Customer Information Centre or visit the LG Website at http://www.lg.com for purchase. Condensing Drain Hose Drain Hose Holder Elbow Bracket for Securing Drain Hose Dry Rack...
  • Page 10 • The included accessories vary depending on the model you purchased. Specifications Asterisk(s) means model variant and can be varied (0-9) or (A-Z). Description Value Model RH10V9AV2W Power supply 220 - 240 V~, 50 Hz Product weight 56 kg Allowable temperature 5 - 35 ℃...
  • Page 11 INSTALLATION Index Dimension (mm) 1115...

  • Page 12: Installation Location Requirements

    INSTALLATION Installation Location • With the appliance installed, adjust all four feet using a spanner to ensure the appliance is Requirements stable, and a clearance of approximately 20 mm is left between the top of the appliance and the Before installing the appliance, check the following underside of any work-top.

  • Page 13: Leveling The Appliance

    • Outlet socket must be within 1.5 meters of either Stacking Instructions side of the location of the appliance. The appliance can be placed on top of an LG front NOTE load washing machine and securely fixed with a • Always unplug the appliance after use.
  • Page 14 INSTALLATION Stacking Kit information of your washing machine at the label.) In order to stack the appliance, an LG stacking kit is required. How to align LG stacking kit to the appliance Type A Type B 550 mm 600 mm...
  • Page 15 INSTALLATION • In case of that the depth of the washing Separate the anti-backflow lid and the water machine is 550 mm or more and 599 mm or container hose from the connecting elbow less or T piece. • In case of that the depth of the washing machine is 600 mm or more and 650 mm or Attach the anti-backflow lid to the head of...

  • Page 16: Operation Operation Overview

    OPERATION OPERATION Operation Overview • All strings and attached belts of clothes should be well tied and fixed before being put into the drum. Using the Appliance Before the first cycle, set the appliance to dry for 5 Press the Power button to turn the appliance minutes to warm up the drum.

  • Page 17: Preparing The Clothes

    OPERATION Preparing the Clothes • The frequency of cleaning condenser may vary depending on the size and the initial moisture amount of the clothes. NOTE • For the best drying performance and most efficient energy usage, do not overload the After the drying programme has finished, open appliance.
  • Page 18 OPERATION Woollens Symbol Description • Dry woollens on the Wool programme. Be sure to follow fabric care label symbols first. Wool Gentle / Delicate may not be completely dried from the cycle, so do not repeat drying. Pull woollens to their Do not Tumble Dry original shape and dry them flat.

  • Page 19: Control Panel

    • To use the extra functions, press and hold the corresponding button for 3 seconds. The corresponding symbol lights up in the display. Remote Start • With the LG ThinQ app, you can use a smartphone to control your appliance remotely. • In order to use the Remote Start function, refer to SMART FUNCTIONS. Wi-Fi •...
  • Page 20 OPERATION Description Time and Status Display • The display shows the settings, estimated remaining time, options, and status messages. When the appliance is turned on, the default settings in the display will illuminate. Time and Status Display Description Drying progress indicator •...

  • Page 21: Programme Table

    OPERATION Programme Table Sensor Drying Programme Guide Program Cotton Max. Load Capacity 10 kg Descripti Use for drying all normal items such as cotton, linen, shirts, jeans or mixed loads, except delicate fabrics such as wool or silk. Dry Level Default : Cupboard Available : All Program...
  • Page 22 OPERATION Program Sportswear Max. Load Capacity 2 kg Dry Level Not adjustable Program Allergy Care Max. Load Capacity 4.5 kg Descripti Use this programme helps to reduce allergens such as dust mites. Dry Level Not adjustable Program Duvet Max. Load Capacity 2.5 kg Descripti Use this programme for drying blankets or bulky items such as pillows, blankets,...
  • Page 23 OPERATION Timed Drying programme Guide Programme Rack Dry Max. Load Capacity – Description Use this programme to dry clothes without tumble action. It is suitable for all fabrics that need refreshing. Dry Level Not adjustable Programme Cool Air Max. Load Capacity –...
  • Page 24 OPERATION Programme Dry Mode Programme Dry Level Energy Normal Time Speed 30 – Towels – Shirts Cupboard Iron Wool – Sportswear – Allergy Care – Duvet – Bedding – Refresh Down Jacket – Refresh Rack Dry – Cool Air – Warm Air –...

  • Page 25: Extra Options And Functions

    OPERATION Extra Options and Dry Level Functions It allows you to select a dryness level for the drying programme. Delay End • Extra: For thick and quilted fabrics • Cupboard: For fabrics that do not need to be It allows you to delay the finishing time of the ironed drying cycle from 3 hours to 19 hours.
  • Page 26 • Press the More Time button to increase the your model. Please contact LG Electronics selected programme time by 5 minutes. Customer Information Centre or visit the LG • Press the Less Time button to decrease the Website at http://www.lg.com for purchase.
  • Page 27 OPERATION • The dryer rack does not move, but the drum will rotate. Close the door. Turn power on and select Rack Dry. Press the Start/Pause button. NOTE • Check the lint filter and remove any lint accumulated from items dried on the rack. •...

  • Page 28: Smart Functions

    LG ThinQ application. • If the distance between the appliance and • If you enable this function in the LG ThinQ the wireless router is too far, the signal application and turn on the dryer after using the strength becomes weak.
  • Page 29 Use a smartphone to control your appliance wireless router manual. remotely. You can also monitor your cycle • LG ThinQ is not responsible for any network operation so you know how much time is left in the connection problems or any faults, cycle.

  • Page 30: Smart Diagnosis

    SMART FUNCTIONS • Launch the LG ThinQ application and select the NOTE Smart Diagnosis feature in the menu. Follow the instructions provided in the LG ThinQ • Only one downloaded cycle can be stored on the application. appliance at a time.

  • Page 31: Maintenance

    MAINTENANCE MAINTENANCE WARNING • Remove the power plug when you clean the appliance. Not removing the plug may result in electric shock. Cleaning after Every Dry Clean the inner filter Pull out the inner filter from the outer filter and Cleaning the Lint Filter then open the inner filter.
  • Page 32 MAINTENANCE Clean the outer filter Close the outer filter while pushing the side of the filter. Remove the dust or lint around the filter inlet. CAUTION • When the lint drops into the filter inlet, it may NOTE cause degradation of drying performance and increase in drying time.

  • Page 33: Cleaning The Appliance Periodically

    MAINTENANCE Empty the water container after every use. Not Press the Start/Pause button. doing so will affect the drying performance. Cleaning the Appliance NOTE Periodically • If the water container is full, the icon glows and a chime will sound while the appliance is operating.
  • Page 34 MAINTENANCE NOTE NOTE • Adequate room ventilation should be provided • Use the water container if the optional drain to avoid the back flow of gases into the room hose is installed or the appliance is stacked on from units burning other fuels, such as open the washing machine.
  • Page 35 MAINTENANCE Empty the water container after the function Turn on the appliance. has finished. Press and hold the Condenser Care button for NOTE 3 seconds. • When the optional drain hose is installed, there is no need to empty the water container. Press the Start/Pause button to start the cleaning of the condenser.

  • Page 36: Troubleshooting

    Errors and malfunctions may occur when operating the appliance. The following tables contain possible causes and notes for resolving an error message or malfunction. Read the tables below carefully in order to save time and money before calling the LG Electronics service centre. Before Calling for Service Your appliance is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage.
  • Page 37 The door is closed while clothes or foreign substance is caught in the door. • Check if clothes or foreign substance is caught in the door before using the appliance. If water leaks continuously, contact the LG Electronics Customer Information Centre. Appliance runs and This is how the anti crease option works.
  • Page 38 TROUBLESHOOTING Symptoms Possible Cause & Solution Clothes take too long Appliance controls are not set properly. to dry. • Use the appropriate control settings for the type of load you are drying. Some loads may require an adjustment of the dry level setting for proper drying.
  • Page 39 TROUBLESHOOTING Symptoms Possible Cause & Solution Clothes are wrinkled. Clothes have dried too long (overdried). • Over drying a load of clothes can lead to wrinkled clothes. Try a shorter drying time. Clothes have been left in the appliance for too long after cycle ends. •...
  • Page 40 TROUBLESHOOTING Symptoms Possible Cause & Solution Clothes have damp Very large load or very small load. Single large item such as a blanket or spots after a Sensor comforter. Dry programme. • If items are too tightly packed or too sparse the sensor may have trouble reading the dryness level of the load.
  • Page 41 • Find the Wi-Fi network connected to your smartphone and remove it, then connected to the Wi-Fi register your appliance on LG ThinQ. network. Mobile data for your smartphone is turned on. • Turn off the Mobile data of your smartphone and register the appliance using the Wi-Fi network.
  • Page 42 Memo...
  • Page 43 Memo...
