FEATURES:
• Two Independent Compressor/Limiter/Gates in a 1RU Roadworthy Housing
• Unique (IKC) Circuitry Intelligently Combines 'Hard Knee' and 'Soft Knee' Compression Styles,
Providing Excellent Inaudible and Program Music Compression
• Fully Automatic or Manually Variable Attack/Release Times, Compression Ratios and Threshold
Levels Allow Both the Novice and the Experienced User Full Effective Use All Processing Controls
• Dual 12-stage Gain Reduction and 8-stage Input/Output Meters for Accurate, Reliable Metering
• Dual-Mono or Stereo Operation for a Multitude of Live, Studio or Recording Applications
• Built-In Adjustable Dynamic Enhancer Selectively Replaces High-End Loss Even During Severe
Compression Produced by High-energy or Low-End Content So Processed Vocals Remain Vibrant
• IRC (Interactive Ratio Control) Expander/Gate Automatically Adjusts Expansion Per the Program
Material, Eliminating the Noise Floor During Quiet Sections or Music Pauses
• 1/4" and XLR-TRS Input/Outputs Provide for Balanced and Unbalanced Integrations to External Devices
• Auto-mode Allows for "Hands-Free" Operation of CLG-600, Allowing Users to Focus on Other Aspects of
the Show, Recording or Broadcast
