Vizio HDX20L User Manual

Vizio HDX20L User Manual

20” lcd television
Hide thumbs Also See for HDX20L:
Table of Contents

Advertisement

Quick Links

Download this manual
VIZIO
HDX
20L
WHERE
VISION
MEETS
VALUE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDX20L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vizio HDX20L

Summary of Contents for Vizio HDX20L

  • Page 1 VIZIO WHERE VISION MEETS VALUE...

  • Page 2: Table Of Contents

    1.10.1 - Key Remote Control Functions ...10 1.10.2 - Insertion of Batteries in the Remote Control...12 1.10.3 - Remote Control Range...13 1.10.4 - Precautions for the VIZIO™ HDX Universal Remote Control ...13 Chapter 2 - Connecting Components...14 2.1 - Which Video Connection Should I Use? ...14 2.2 - Connecting Your DVD Player...15...

  • Page 3: Chapter 1 - Introduction

    Chapter 1 - Introduction 1.1 - Before Use Congratulations on your VIZIO™ HDX 20L 20” LCD Television purchase. Thank you for your support of V, Inc. and its LCD Television product line. The 20L is a precise electronic product and you should read the following instructions carefully to maximize the performance of the product.

  • Page 4: Opening The Package

    1.3 - Opening the Package • The VIZIO™ HDX 20L is packaged in a carton together with other standard accessories. Any optional accessories such as wall mounts are packed separately in another carton. • Never place the unit on a surface with the glass facing downwards unless it is on protective padding.

  • Page 5: Important Safety Guidelines

    Do not turn on the 20LL LCD TV immediately after this to avoid causing fire, electric shock or component damage. • Do not place the 20LL LCD TV on an unstable cart, stand, or table. If the 20LL LCD TV falls, it can injure a person and cause serious damage to the appliance. •...

  • Page 6: Television Antenna Connection Protection

    1.6 - Television Antenna Connection Protection External Television Antenna Grounding If an outside antenna or cable system is to be connected to the LCD TV, make sure that the antenna or cable system is electrically grounded to provide some protection against voltage surges and static charges.

  • Page 7: Package Contents

    1.7 - Package Contents V, Inc. VIZIO™ HDX Universal Remote Control IMPORTANT: Save the original box and all the packing material for future shipping needs. Note: Your product may also include various other accessories depending on region of purchase. Version - 2/21/2005 V, Inc.

  • Page 8: Basic Controls

    AV2 Component, the 20LL will automatically switch to AV2 In Video. Power - Switch the TV on by pressing the button once. Press the button again to turn the TV off. Remote Control Sensor – This is the window that passes all of the remote signals to the sensor.

  • Page 9: Side Panel Connections

    8. AV1 in S-Video - Connect the S-Video to external video device such as VCR, DVD and video games. 9. RF (TV Input) - Connect to the antenna, satellite or cable service. The AC In is located on the rear panel right hand.

  • Page 10: Vizio™ Hdx Universal Remote Control

    1.10 - VIZIO™ HDX Universal Remote Control The VIZIO™ HDX Universal Remote Control is a comprehensive remote that can be used to control up to four different components. The remote control button functions are explained on the following pages. VIZIO™ HDX Universal Remote Control Button Description Version - 2/21/2005 www.vizioce.com...

  • Page 11: Key Remote Control Functions

    CBL – This button selects a programmed cable TV set-top box or selects a programmed satellite TV set-top box. VCR – This button selects a programmed VCR. TV – This button selects a programmed TV. Pre-programmed for the VIZIO™ HDX 20L LCD TV. Number Button Pad – These buttons select a channel or password.
  • Page 12 120 minutes. VGA – This button selects a programmed VGA display. TV – This button selects a programmed TV. Pre-programmed for the VIZIO™ HDX 20L LCD TV. Note: The remote control layout is for reference only.

  • Page 13: Insertion Of Batteries In The Remote Control

    1.10.2 - Insertion of Batteries in the Remote Control Insert two AA batteries into the remote control. Make sure that you match the (+) and (-) symbols on the batteries with the (+) and (-) symbols inside the battery compartment. Re-attach the battery cover.

  • Page 14: Remote Control Range

    The effective range of the remote control is approximately 32 feet (10 meters) from the front of the receiver window, 30º to the left and right, 20º up and down. 1.10.4 - Precautions for the VIZIO™ HDX Universal Remote Control •...

  • Page 15: Chapter 2 - Connecting Components

    Chapter 2 - Connecting Components 2.1 - Which Video Connection Should I Use? The VIZIO™ HDX 20L LCD TV has four different ways to connect your video equipment from a basic one to the most advanced for digital displays. Connection Quality...

  • Page 16: Connecting Your Dvd Player

    2.2 - Connecting Your DVD Player You have several options for connecting your DVD player to your new 20L LCD TV –Component, S-Video and Composite inputs. Based on your home theater configuration, you can decide which option is the right one for you.

  • Page 17: Using Composite Video

    DVD player, you can connect the DVD player to the Video input within the AV2 connections (yellow band). 2.3 - Connecting Your HDTV Set-Top Box You have the option for connecting your HDTV set-top box to your new 20L LCD TV through the RGB or Component connection. 2.3.1 - Using RGB Video Installation: 1.

  • Page 18: Using Component Video

    5. Turn on the power to the LCD TV and HDTV set-top box. 6. Select Component using the INPUT button on the front of the LCD TV. Note: Refer to your HDTV Set-Top Box user manual for more information about the video output requirements of the product.

  • Page 19: Connecting Coaxial (Rf)

    2.5 - Connecting Coaxial (RF) There are several options for connecting your antenna or cable to your new 20L LCD TV - directly to the TV or through your VCR. Based on your home theater configuration, you can decide which option is the right one for you.

  • Page 20: Chapter 3 - Getting Started

    3.2 - Installation of Wall Mount (Optional) If you would like to mount your 20L LCD TV to the wall, you can contact V, Inc. directly or your local dealer to obtain the appropriate wall mounting kit. To convert your LCD TV from a desk- mounted to a wall-mounted display, follow the instructions below: 1.

  • Page 21: Adjusting Basic Lcd Tv Settings

    TV Channels To step up through the available TV channels, press the CH + button on the front panel or remote control once for the next channel or hold it depressed until the desired channel is reached.

  • Page 22: Using The On-Screen Display (Osd)

    3.4 - Using the On-Screen Display (OSD) The remote control or the bottom control keys on the front panel of the LCD TV can control all the function settings. The on-screen display (OSD) allows you to adjust and save contrast, brightness and other settings.

  • Page 23: Osd Menus And Options

    3.4.2 - OSD Menus and Options The OSD Menu includes seven sub menus: Picture Adjust, Input Setup, TV Tuner Setup, Audio Adjust, Parental Controls and Special Features. With each input source, there will be a corresponding change in the OSD menu.
  • Page 24 Balance – Adjusts the left and right speaker balance. Loudness – Boosts the bass at low audio output levels. Mute – Used to turn the sound of the TV on and off. 3.4.2.5 – Parental Controls Note: This option is not available when using component video.
  • Page 25 Brightness - Adjusts the black levels of the picture. Users may need to readjust the brightness after the LCD TV warms up. Contrast - Adjusts the white levels of the picture. Clock – Removes any vertical distortion and clears or sharpens the displayed characters.

  • Page 26: Using The Parental Controls

    The Parental Controls feature prevents viewers from watching programs that are not age- appropriate, such as programs containing violence or adult language. 1. Press the TV component button. 2. Press the MENU button on the remote control and the Main Menu will be displayed on the screen.

  • Page 27: Setting A Password

    You control access to the Parental Control features with a password. The default password is “0 0 0 0”. You can change the password to any four-digit number. To change the password: 1. Press the TV component button. 2. Press the MENU button on the remote control and the Main Menu will be displayed on the screen (see figure 3.4.5.a).

  • Page 28: Remote Control Operation

    3. Press and hold the SETUP button until the LED LIGHT flashes twice. 4. Find the programming code for your TV in the code list in the back of this book and enter it using the Number Buttons. If the code is accepted, the LED flashes twice after the last digit is entered.
  • Page 29 3.5.1.3 - Programming for Cable Box 1. Manually turn on the Cable Box. 2. Press the CBL button on the remote control. 3. Press and hold the SETUP button until the LED LIGHT flashes twice. 4. Find the programming code for your Cable Box in the code list in the back of this book and enter it using the Number Buttons.

  • Page 30: Searching For Component Codes

    You can reassign the component buttons on the remote control if you have more than one of the same types of component. For example, if you are using the remote to control the cable (CBL), CD, DVD, TV and two VCRs, you can reassign the AV2 button as a second VCR button. To reassign component buttons: 1.

  • Page 31: Chapter 4 - Maintenance And Troubleshooting

    Chapter 4 - Maintenance and Troubleshooting 4.1 - Maintenance Important 1. Make sure that the power cable is removed from the socket before cleaning the display. 2. Do not use volatile solvent (such as toluene, rosin and alcohol) to clean the display. Such chemicals may damage the housing, screen glass and remote control, and cause the paint to peel.

  • Page 32: Telephone & Technical Support

    Check your audio connection. Press MUTE on the remote control again, so that MUTE disappeared from the screen. Check your audio settings, your TV audio may be set to SAP or minimum. Press the Volume + (Up) key on your remote control.

  • Page 33: Compliance

    2. Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits. 3. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modification to this equipment. It is the responsibilities of the user to correct such interference.

  • Page 34: Appendix A: Limited Product Warranty

    Service Labor During a period of one (1) year from the effective warranty date, VIZIO will provide, when needed, service labor to repair a manufacturing defect at its designated Service Center. To obtain warranty service in the Untied States, you must first call our Customer Support at (714) 668-0588, 7:30 am –...

  • Page 35: Appendix B: Component Program Codes

    Appendix B: Component Program Codes SETUP CODES FOR CURRENT VIZIO PRODUCTS *Note: Please use these codes to program the VIZIO products to existing Universal remote controls for products such as cable and satellite boxes. VIZIO L13 0864 VIZIO L6 0885...
  • Page 36 SETUP CODES FOR LASER DISK Denon 0059 Mitsubishi 0059 0059 Optimus 0059 Pioneer 0059 Sony 0193, 0201 SETUP CODES FOR MISC. AUDIO Jerrold 0459, 0520 Scientific Atlanta 0460 Starcom 0459 SETUP CODES FOR RECEIVERS 0531 Aiwa 0158, 0189, 0121, 0405 Capetronic 0531 Carver...
  • Page 37 SETUP CODES FOR TELEVISION 0030, 0019 Admiral 0093, 0463 Aiko 0092 Akai 0030 Alaron 0179 America Action 0180 Ampro 0751 Anam 0180 Audiovox 0451, 0180, 0092, 0623 Baysonic 0180 Belcor 0019 Bell & Howell 0154, 0016 Bradford 0180 Brockwood 0019 Broksonic 0236, 0463 0180...
  • Page 38 SETUP CODES FOR VCR Admiral 0048,0209 Adventura 0000 Aiko 0278 Aiwa 0037, 0000 Akai 0041 America Action 0278 American High 0035 Asha 0240 Audiovox 0037 Beaumark 0240 Bell & Howell 0104 Broksonic 0184, 0121, 0209, 0002 0072, 0278 Calix 0037 Canon 0035 Carver...
  • Page 39 WHERE VISION MEETS VALUE BRAVO, VIZIO and the V Logo are trademarks of V, Inc. Product specifications are subject to change without notice or obligation. © 2004 V, inc. All rights reserved.
