LOWES FRAMES
ASSEMBLY INSTRUCTIONS
ITEM
60" x 74" frame
48" x 74" frame
10" x 10" feet
BRACKET CORNER
ASSY
PLEASE NOTE
Please inspect and verify your kit. If you are missing items, have received damaged items or you require additional
items, please reorder in ISV and or spend management.
REORDER#
F250134
F250265
F250266
CHANNEL 48 LG
CHANNEL 74 LG
PLEASE NOTE
Page 1
CHANNEL 60 LG
PLATE, NUT, CORNER
BACK VIEW
10 x 10 FOOT BASE
PLEASE NOTE
PLEASE NOTE
PLATE, BRACKET, CORNER
PLEASE NOTE
P1405_Lowes Frames_INST_REVC.ai
FRONT VIEW
SCREW
5.12.16 pj
