Summary of Contents for Texas Instruments bq24153A

  • Page 1: Table Of Contents

    One-Cell, Li-Ion Charger With Full USB Compliance and USB-OTG Support EVM The bq24153A/56A/57B/58/59 evaluation module is a complete charger module for evaluating compact, flexible, high-efficiency, USB-friendly, switch-mode charge management solution for single-cell Li-ion and Li-polymer batteries used in a wide range of portable applications.
  • Page 2: The Bq24153A/56A/57B/58/59 Evaluation Module Is A Complete Charger Module For Evaluating Compact

    • Jumpers available. Easy-to-change connections. General Description The bq24153A/56A/57B/58/59 evaluation module is a complete charger module for evaluating compact, flexible, high-efficiency, USB-friendly, switch-mode charge management solution for single-cell Li-ion and Li-polymer batteries used in a wide range of portable applications.
  • Page 3: Recommended Operating Conditions

    Definitions This procedure details how to configure the HPA697 evaluation board. The following naming conventions are followed. See the bq24153A/56A/57B/58/59EVM (also know as HPA697) schematic for details. VXXX : External voltage supply name (VADP, VBT, VSBT)
  • Page 4: Recommended Test Equipment Setup

    HPA256-002 (-LED-) ON (-HI-) ON (-LO-) ON (bq24156A) bq24153A/56A/57B/58/59 Fully Integrated, Switch-Mode, One-Cell, Li-Ion SLUU453A – November 2010 – Revised February 2012 Charger With Full USB Compliance and USB-OTG Support EVM Submit Documentation Feedback Copyright © 2010–2012, Texas Instruments Incorporated...
  • Page 5: Charging Function Test Setup

    Figure SLUU453A – November 2010 – Revised February 2012 bq24153A/56A/57B/58/59 Fully Integrated, Switch-Mode, One-Cell, Li-Ion Charger With Full USB Compliance and USB-OTG Support EVM Submit Documentation Feedback Copyright © 2010–2012, Texas Instruments Incorporated...
  • Page 6: Recommended Test Procedure

    4. For the bq24156A and bq24159EVMs only, ensure that the SLRST pin, connected to JP2, is pulled HI. 5. Turn on PS#1. bq24153A/56A/57B/58/59 Fully Integrated, Switch-Mode, One-Cell, Li-Ion SLUU453A – November 2010 – Revised February 2012 Charger With Full USB Compliance and USB-OTG Support EVM Submit Documentation Feedback Copyright ©...
  • Page 7 6. Check Disable Charger. Turn off PS#1, turn off Load #2, and disconnect. 2.4.3 Boost Function for bq24153A, bq24157B and bq24158 Versions Only 1. Adjust PS#1 output to 3.7 V, and disable the output. Connect the PS#1 in series with a current meter (multimeter) to J2 (BAT+, BAT–).
  • Page 8: Printed-Circuit Board Layout Guideline

    The PGND pins must be connected to the ground plane to return current through the internal low-side FET. bq24153A/56A/57B/58/59 Fully Integrated, Switch-Mode, One-Cell, Li-Ion SLUU453A – November 2010 – Revised February 2012...
  • Page 9: Bill Of Materials, Board Layout, And Schematics

    PCB, 2.0 In x 2.0 In x 0.031 In HPA697 SLUU453A – November 2010 – Revised February 2012 bq24153A/56A/57B/58/59 Fully Integrated, Switch-Mode, One-Cell, Li-Ion Charger With Full USB Compliance and USB-OTG Support EVM Submit Documentation Feedback Copyright © 2010–2012, Texas Instruments Incorporated...
  • Page 10 Count RefDes Value Description Size Part Number bq24153A/56A/57B/58/59 Fully Integrated, Switch-Mode, One-Cell, Li-Ion SLUU453A – November 2010 – Revised February 2012 Charger With Full USB Compliance and USB-OTG Support EVM Submit Documentation Feedback Copyright © 2010–2012, Texas Instruments Incorporated...
  • Page 11: Board Layout

    HPA697-005 BQ24159EVM-697 Board Layout Figure 5. Top Layer SLUU453A – November 2010 – Revised February 2012 bq24153A/56A/57B/58/59 Fully Integrated, Switch-Mode, One-Cell, Li-Ion Charger With Full USB Compliance and USB-OTG Support EVM Submit Documentation Feedback Copyright © 2010–2012, Texas Instruments Incorporated...
  • Page 12: Bottom Layer

    Bill of Materials, Board Layout, and Schematics www.ti.com Figure 6. Bottom Layer Figure 7. Top Assembly bq24153A/56A/57B/58/59 Fully Integrated, Switch-Mode, One-Cell, Li-Ion SLUU453A – November 2010 – Revised February 2012 Charger With Full USB Compliance and USB-OTG Support EVM Submit Documentation Feedback...
  • Page 13: Schematic

    Bill of Materials, Board Layout, and Schematics www.ti.com Schematic SLUU453A – November 2010 – Revised February 2012 bq24153A/56A/57B/58/59 Fully Integrated, Switch-Mode, One-Cell, Li-Ion Charger With Full USB Compliance and USB-OTG Support EVM Submit Documentation Feedback Copyright © 2010–2012, Texas Instruments Incorporated...
