Encore Hartco Eclipser 2800/2500 Operating Manual

Encore Hartco
Eclipser 2800/2500
and Continuous Coil (CC) Clipping System
Eclipser 2500
shown with Black
Housing (HR Color
Style) and Standard
Anvil
Eclipser 2800
with Black Housing
("HR" Color Style)
and Double-Ended
Anvil
7-18-2023/BW © 2023 Encore Hartco
PNEUMATIC CLINCH CLIP CLOSURE TOOL
Green Housing
"EA" Color Style
For best results, use
genuine Encore Hartco
E-Clips sold in rolls
Red Housing
"
SN" Color Style
BEFORE
Encore Hartco
Continuous Coil
(CC) Clipping
System
on pages
5-6
MADE IN THE U.S.A.
AFTER
www.encorehartco.com
info@encorehartco.com
Northbrook, IL 60062 U.S.A.
Phone: (224) 723-5524
Fax: (224) 723-5526
It is the employer's responsibility to assure
this manual is read and understood by all
personnel assigned to use this tool, and this
manual is kept on hand for future reference.
SAFETY
WARNING
READ THE ENTIRE MANUAL
BEFORE OPERATING THE TOOL.
SAFETY GLASSES (ANSI A87)
should always be worn by all in
the work area while operating,
maintaining or repairing a
tool. Wear personal protective
equipment as required.
NEVER use oxygen, carbon
dioxide or any other bottled gas
as a power source for this tool, as
it will explode and cause serious
injury.
BEFORE using tool, check work
area for hidden electric cables,
utility lines, gas pipes, etc. that
can cause a hazard if damaged
by the tool.
INSPECT TOOL BEFORE EACH
USE. Make sure bolts and cap
screws are tight and trigger
moves freely. Never use a tool
that leaks air, has missing parts, is damaged, or
needs repair.
Do not modify this tool without consulting with
an ENCORE HARTCO tool specialist rst.
Use only parts, fasteners and accessories
recommended and sold by ENCORE HARTCO and
its authorized distributors.
TO PREVENT SERIOUS
INJURY:
•
Do not use the tool when you are tired or
under the in uence of drugs, alcohol or
medication.
•
Remove all fasteners from tool BEFORE
connecting air.
KEEP HANDS AND FINGERS
AWAY FROM BLADE AND ANVIL
AREA when connecting air
supply and operating tool.
•
DISCONNECT THE AIR SUPPLY when
mechanically clearing a jam, performing
maintenance or repairs, and whenever the
tool is not in use.
•
NEVER POINT THE TOOL TOWARD YOURSELF
OR ANYONE ELSE.
•
ALWAYS KEEP YOUR FINGER OFF THE
TRIGGER unless actually applying a clip.
Unintended pressure on trigger could cause
tool to eject a fastener.
