Encore Hartco Han-D-Ringer Operating Manual

Han-D-Ringer
Sturdy molded plastic body
n
Light, well balanced, durable design
n
ensures effortless handling
n Easy loading
Single action operation
n
Manually powered
n
LATCH
AREA
MAGAZINE

OPERATING INSTRUCTIONS

1 2
3
2018-0125
PUSHER
• Pull pusher to the back of tool (Figure 1).
• Slide the pusher all the way into the latch area
until it latches (Figure 2).
• To load rings onto the magazine (Figure 3), feed
one end of the strip of rings underneath the
magazine, making sure to place the flat side
of D-ring strip against the tool and the legs of
rings are pointing away from the tool.
• Slide rings all the way to the front of the tool.
• Release the pusher from the latch and allow it
to rest against the rings (Figure 4).
4
www.encorehartco.com
info@encorehartco.com
Northbrook, IL 60062 U.S.A.
Phone: (224) 723-5524
Fax: (224) 723-5526
OPERATING
MANUAL
ENCORE HARTCO
HAN-D-RINGER
(RAM1001)
Manual Ringer for Closure
of 9/16" D-Rings
BLACK Housing
and Magazine
Uses Encore Hartco 9/16"
D-Rings:
RD1005 -
Galvanized steel, blunt tip
RD1006 -
Stainless steel, blunt tip
RD1007 -
Galvanized steel, sharp point
RD1008 -
Stainless steel, sharp point
Works with:
WA Machine 9/16" Rings
SAFETY
INFORMATION
READ THE ENTIRE
MANUAL BEFORE
OPERATING THE TOOL.
SAFETY GLASSES should
always be worn while
operating, maintaining
or repairing a tool.
KEEP HANDS AND BODY
AWAY from the jaw
mechanism area of the
tool. Keep others at a
safe distance from the tool while it
is in operation, as tool movement
at startup may occur, possibly
causing injury.
INJURY PREVENTION—
Never point the tool
toward yourself or
anyone else. When
testing tool, always cycle tool away
from work to insure proper ring
closure.
For safety reasons, an
improperly functioning
tool MUST NOT be used.
